Door Reversal Instruction
•
Remove the top hinge cover.
•
Using Phillips Head Screwdriver, loosen and remove the screws holding the top hinge in place.
•
Remove top hinge and carefully lift off the door.
•
Remove the screw hole plugs from the opposite side and insert the plugs in the screw hole
openings of the just removed screws.
•
Remove any loose items in the refrigerator and carefully turn refrigerator on its back and place in
a secure area.
•
Loosen the screws holding the lower hinge bracket to the refrigerator and remove screws and
bracket.
•
Remove (2) screws from the other side and insert in the previously removed screw holes.
•
Remove door pin by turning counter clockwise and reinsert to the underside of the bracket and
tighten.
•
Align bracket and insert (2) remaining screws into the holes provided .
•
Align hole in the door with the door pin and washer and gently push down until firm.
•
Align upper hinge bracket with screw holes insert screws and partially secure, check that door
and cabinet are properly aligned and then secure tightly.
•
Replace hinge cap.
