Summary of Contents for Matrix Nexa
- Page 1 Nexa - Enclosed Mobility ▲Please read this manual carefully before riding...
- Page 2 Preface • Thank you for choosing Matrix Nexa! • Before driving, please read the User's Manual carefully and do not drive until you understand the characteristics of this vehicle. • If you want to transfer or give the vehicle to others, please attach this manual with the vehicle, because it is an important part of the vehicle;...
- Page 3 Important considerations * Vehicles are restricted to flat roads. If the technical specifications are changed, some pictures or contents of this Manual may be related to. We appreciate your understanding that there are differences in the actual situation of the vehicles. We reserve the right of final explanation.
-
Page 4: Table Of Contents
Catalogue Ⅲ、Maintenance and repair Maintenance method------- 21 Ⅰ. Safe driving rules for Simple troubleshooting -------23 vehicles-------04 Ⅱ. Vehicle Local Map and Description Suspension and steering system------- 24 Electronic control system -------25 Tail luminaire bitmap------- 05 Battery maintenance------- 26 Multimedia Instrument Diagram and Description -------08 Ⅳ、... -
Page 5: Ⅰ. Safe Driving Rules For Vehicles
Safe driving rules for vehicles Ⅰ、 Safe driving rules 1、 ♦ Electric vehicles are only suitable for those who hold a driver's license or have received training and training. If you operate electric vehicles for the first time, please connect Supervised by trained technicians to avoid accidents. - Page 6 （Nexa） Dipped headlight cornering lamp Side marker lamp Tigh beam light (driving lamp)
- Page 8 When the dimmer switch is turned to the "Multi D" position, the high and low beam indicators will not light up. (3) Temperature display lamp. NEXA (4) Volume adjustment indicator: adjust the volume. (5) Multimedia display.
- Page 9 (8) Total mileage/(km): record the total mileage of the vehicle; (9) Power meter: when the switch lock is opened, the battery power is displayed; Operating system name Inspection before driving: Before each driving, the vehicle shall be subject to a routine inspection to ensure good performance and safe driving.
- Page 10 Driving precautions When turning the steering wheel, it is not allowed to turn the steering wheel too hard or turn sharply. Do not turn the steering wheel after the vehicle stops, When driving on uneven roads, hold the steering wheel tightly with both hands; To prevent accidents due to uncontrolled steering.
-
Page 11: Adjustable Seat
Adjustable seat (Figure 2) Pull up the seat front and rear adjustment handle to adjust the seat front and rear position. Pull up the backrest Angle adjustment handle to adjust the seat back Angle. Front and rear Back rest adjustment of Angle seats adjustment... -
Page 12: Ignition Switch, Usb
USB interface (Figure 4) ⑴ USB interface, with an output current of 5V; ⑵ Through this socket inserted U disk, can play music, movies, photos, etc. in the U disk. Figure 4） （ multimedia Multimedia Use Guide (Figure 5) To turn on or off multimedia, long press the multimedia function key for three seconds;... - Page 13 Bluetooth connection Bluetooth connection, press the multimedia function key to switch to the Bluetooth channel, open the mobile phone Bluetooth search A0NEW device, click the connection Parking handbrake (Figure 6) Lock: pull up the parking lever, then the rear wheel lock the vehicle can not move.
-
Page 14: Power Off Switch
Power-off switch (Figure 7) When the power-off switch is pressed down, the power switch has been closed and the car can be operated; When the power-off switch is lifted down, the power switch has been disconnected, and the car cannot operate (Also an anti-theft setting);；... -
Page 15: Charging Connector
-------------------------------------- Charging interface (Figure 9) 1. When the instrument shows a low power level, the user needs to charge, open the flip cover of the charging port, and insert the external power supply into the charging port for charging; 2. The charging interface is only used for charging, and the power-on test drive is strictly prohibited;... -
Page 16: Door Lock
Charging precautions： The new car battery is not full state, the user needs to charge after driving, charging should pull off the key to pull the handbrake. Each charging time is strictly prohibited to exceed 12 hours, the vehicle should be charged once a month when in used. It is strictly prohibited to use a non-national standard charger to charge the vehicle. -
Page 17: Window Glass Lift
------------------------------ Window glass lift switch (Figure 12) In the car, open the door handle 1, The door can be opened; both sides of the vehicle with electric lift adjustment, through the glass lift switch 2 operation, press the button, push the window down; pull up the button, the window up Sunroof snap drawing (Figure 13) Open the sunroof buckle to allow for ventilation... -
Page 18: Driving Operations
Driving operation： Preparation before starting: open the vehicle parking lock, make sure that the power-off switch is in the figure closed state, insert the key into the ignition switch, and rotate Go to the ON " position. Turn the gear knob switch to "D" and lower the parking handbrake。 ♦Warning: Special care should be taken when driving on wet or soft roads and under rainy conditions, whether for braking, acceleration or steering. -
Page 19: Parking Operations
Parking operation: When parking, turn the gear knob switch to the "N" gear position, twist the ignition switch to the OFF position and pull up the parking pull rod; ♦Warning: Electric vehicles should be parked on hard and flat ground, otherwise, injuries or vehicle dumping. Anti-theft points: -Lock the door and pull the parking lever, never leave the car key in the ignition switch lock. -
Page 20: Maintenance Method
Ⅲ. Maintenance and maintenance The maintenance period is based on the mileage, which is the guiding basis for the implementation of regular maintenance and lubrication. If it is driving at high speed for a long time under harsh conditions, the number of maintenance must be increased. - Page 21 Note: In order to ensure the safety and reliability of electric vehicles, electric vehicles are not allowed to be modified. When repair or maintenance, replace our original parts or similar parts of equal quality. If other poor quality parts are used, it will affect the performance of the electric vehicles and the operation of the function；...
-
Page 22: Simple Troubleshooting
（1）Simple troubleshooting fault phenomenon failure cause Solution tire wear is uneven Tire pressure is too low Inlate to recommended pressure Direction column bearing lubricant solidification Inject an appropriate amount, interslip oil Loss of lubricant at the chain make-up oil The steering column is worn Replace the steering cylinder The steering is Tire inflation pressure is uneven... -
Page 23: Suspension And Steering System
（2）Suspension and steering system fault failure cause Solution phenomenon The key switch is in the OFF state or the gear knob Rotate the key to the ON position Select the exercise direction of the shift switch is in neutral position The battery has no electricity Recharge Battery wiring electrode is corroded or loose... -
Page 24: Electronic Control System
（3） electronic control system fault phenomenon fault phenomenon Solution The key switch is broken Repair or replacement The circuit connector is loose or open circuit Tighten the joints or connect the wires Turn on the key switch power display, no display, no The control circuit or the power-off switch is replace... -
Page 25: Battery Maintenance
Maintenance of the battery (as shown in Figure 16)： This model adopts closed lead-acid battery (no water added) Note: The top cover of the closed lead-acid battery electrolyte is absolutely not allowed to be opened. -When the vehicle is not in use for a long time, please remove the battery and store it in a cool, ventilated and dry place. -
Page 26: Ⅳ、Vehicle Storage
Ⅳ、Vehicle storage Keep in storage： -To store electric vehicles for a long time (for example in winter), several steps need to be taken to prevent any failure or damage caused by long-term unused electric vehicles. In addition, before preparing for storage, some maintenance work needs to be carried out, otherwise it is often forgotten when using the electric vehicle again. -
Page 27: Ⅴ、Vehicle Identification
Ⅴ、Vehicle identification Vehicle nameplate (Figure 15) shows: The vehicle nameplate bracelet connects to the right side of the driver's bucket. It contains the frame number, model, brand, vehicle quality, motor model, maximum output power, rated voltage, loading quality, production date and other information.。 Figure15 When repairing and replacing spare parts, the above frame number shall be provided. -
Page 28: Ⅵ、Electrical Schematic Diagram
Ⅵ、Electrical schematic diagram...
