Munters 36LTX-1PK Instruction Manual
Munters 36LTX-1PK Instruction Manual

Munters 36LTX-1PK Instruction Manual

Ltx housing for vortex fans 36”, 51”, 55”

Advertisement

Quick Links

Instruction Manual
51LTX
LTX Housing for Vortex Fans
Models: 36LTX-1PK • 36LTX-2PK • 36LTX-3PK• 51LTX-1PK •
51LTX-2PK • 51LTX-3PK • 55LTX-1PK • 55LTX-2PK •
55LTX-3PK
© Munters Corporation, November 2023
LTX Housing
for Vortex Fans
VX36, VX51 & VX55
51LTX w/ VX51
36", 51", 55"
Aerotech
QM1410r0
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the 36LTX-1PK and is the answer not in the manual?

Questions and answers

Summary of Contents for Munters 36LTX-1PK

  • Page 1 Instruction Manual VX36, VX51 & VX55 51LTX 51LTX w/ VX51 LTX Housing for Vortex Fans 36”, 51”, 55” Models: 36LTX-1PK • 36LTX-2PK • 36LTX-3PK• 51LTX-1PK • 51LTX-2PK • 51LTX-3PK • 55LTX-1PK • 55LTX-2PK • 55LTX-3PK © Munters Corporation, November 2023 QM1410r0...
  • Page 2 With the proper installation and maintenance it will provide many years of service. Please Note: To achieve maximum performance and insure long life from your Munters product it is essential that it be installed and maintained properly. Please read all instructions carefully before beginning installation. Warranty: For Warranty claims information see the “Warranty Claims and Return Policy”...
  • Page 3 LTX Housing Installation Fan Installation L.H. Door (48”) Assembly R.H. Door (36”) Assembly L.H. Door (48”) Installation R.H. Door (36”) Installation 3. Maintenance 4. Winterizing Winterizing Winter Weather Protection 5. Exploded View and Parts List 36-37 © Munters Corporation, November 2023 QM1410r0...
  • Page 4: Unpacking The Equipment

    Light Gap Cover, Darkout, GZ FA2147 Light Gap Cover Bracket, GZ FA2141 J-Hook Rod, 2 Ends, 0.25”D, 71”L, STL FA2142 J-Hook Rod, 2 Ends, 0.25”D, 66”L, STL FA2130 Reinforcing Plate, LTX Housing, 60”L., CTD-GZ Continued on next page © Munters Corporation, November 2023 QM1410r0...
  • Page 5 Grease Fitting, ¼ ”-28 UNF; ³³⁄₆₄”H, ZP KS2751 ⁵⁄₁₆”-18 x 4”L., Closed Eye Bolt, SS KN1004 ⁵⁄₁₆”-18 Hex Nut, SS HP1189 - Hardware Package TEK Screws One Door [D] 100 KS2254 ¼ ” x ¾ ” HXWSHR TEK Screw, ZP © Munters Corporation, November 2023 QM1410r0...
  • Page 6 43”H 51LTX VX51 ⁄ ”W 57 ⁄ ”H 55LTX VX55 60”W ⁄ ”H 1.3 LTX Housing and Fan Depth 74⅜ ” 77⅞ ” 82¼ ” 24½ ” 24½ ” 24½ ” VX36 VX51 VX55 © Munters Corporation, November 2023 QM1410r0...
  • Page 7: Installation Instructions

    Installation Instructions 2.1 LTX Housing Installation Step 1 Construct the framed opening of 89¾ ”W. x 75¼ ”H.. See Figure 1. 89¾ ”W. Framing Figure 1 © Munters Corporation, November 2023 QM1410r0...
  • Page 8 Framing ¼ ” x 3½ " Lag Screws [A] Washer [C] LTX Housing INSIDE OUTSIDE Figure 2A Framing LTX Housing ¼ ” x 3½ " Lag Screws [A] Washer [C] Figure 2B © Munters Corporation, November 2023 QM1410r0...
  • Page 9 The 1st hole (bottom hole) should be ½ ” up, 2nd hole 5” up, 3rd hole 68” up, and 4th hole 72½ ” up. See Figure 3. ¾ ” ¾ ” Figure 3 © Munters Corporation, November 2023 QM1410r0...
  • Page 10 Make sure the Pin is facing up. See Figure 4. Hinge Pin Bracket 1 of 4 Pair of Holes in LTX Housing Flange, Washer [C] drilled in previous step ¼ ” x 3½ " Lag Screw [A] Figure 4 © Munters Corporation, November 2023 QM1410r0...
  • Page 11 The bolt head should be on the fan flange in the housing and the nut should be on the outside of the LTX Housing. See Figure 5. Flange Nut [G] Washer [C] Reinforcing Plate [FA2130] Bolt [F] Figure 5 © Munters Corporation, November 2023 QM1410r0...
  • Page 12 Make sure nothing runs across or is mounted in the shaded area shown the figure below. See Figure 6 . Figure 6 © Munters Corporation, November 2023 QM1410r0...
  • Page 13 LTX Door Panel [FA2106] LTX Door Hinge Panel [FA2103] LTX Door Hinge Panel [FA2103] Top/Bottom Corner Bracket [FA2119] LTX Door Hinge Panel [FA2103] L.H. Top/Bottom LTX Door Panel [FA2106] TEK Screw [D] Figure 7 © Munters Corporation, November 2023 QM1410r0...
  • Page 14 (4) TEK Screws [D] per bracket. See Figure 8 . The flat edge of the baracket should be facing the inlet side of the door. TEK Screw [D] 1/2 Darkout Bracket [FA2111] Figure 8 © Munters Corporation, November 2023 QM1410r0...
  • Page 15 Attach (1) Leaf Hinge [FA2120] to Top Corner Cap and one to the Bottom Corner Cap assembled in the previous step using (4) Bolts [E] and Nuts [G]. See Figure 9 . Nut [G] LTX Door Leaf Hinge [FA2120] Bolt [E] Figure 9 © Munters Corporation, November 2023 QM1410r0...
  • Page 16 See Figure 10 . L.H. Center Top Corner Bracket [FA2126] Light Gap Cover Plate [FA2114] TEK Screw [D] L.H. Center Door Panel [FA2107] Light Gap Cover Plate [FA2114] TEK Screw [D] Spring Latch [K] Figure 10 © Munters Corporation, November 2023 QM1410r0...
  • Page 17 Stand-off. See Figure 11B. LH Door Assembly Light Trap material Figure 11A Stand-off DO NOT nest here DO NOT nest here Figure 11B © Munters Corporation, November 2023 QM1410r0...
  • Page 18 Top Corner Bracket and (10) TEK Screws [D] in the Bottom Corner Bracket. See Figure 12 . TEK Screw [D] L.H. Center Top Corner Bracket [FA2126] L.H. Center Bottom Corner Bracket [FA2127] TEK Screw [D] Figure 12 © Munters Corporation, November 2023 QM1410r0...
  • Page 19 71”L. J-Hook Rod [FA2141] Slot in Top/Bottom Corner Bracket [FA2119] 71”L. J-Hook Rod [FA2141] Closed Eye Bolt [N] Nut [P] Hole in L.H. Center Bottom Corner Bracket [FA2127] L.H. Center Bottom Corner Bracket [FA2127] Figure 13 © Munters Corporation, November 2023 QM1410r0...
  • Page 20 72½ ”L., then peal the backing off of the Brush Seal and carefully stick them to the 4 sides of the door where they were cleaned. See Figure 14 . Brush Seal Area to be cleaned Area to be cleaned Brush Seal Figure 14 © Munters Corporation, November 2023 QM1410r0...
  • Page 21 TEK Screw [D] Bracket [FA2119] R.H. Top/Bottom LTX Door Panel [FA2104] LTX Door Hinge Panel [FA2103] LTX Door Hinge Panel [FA2103] LTX Door Hinge Panel [FA2103] Top/Bottom Corner Bracket [FA2119] TEK Screw [D] Figure 15 © Munters Corporation, November 2023 QM1410r0...
  • Page 22 (4) TEK Screws [D] per bracket. See Figure 16 . The flat edge of the baracket should be facing the inlet side of the door. TEK Screw [D] 1/2 Darkout Bracket [FA2110] Figure 16 © Munters Corporation, November 2023 QM1410r0...
  • Page 23 Attach (1) Leaf Hinge [FA2120] to Top Corner Cap and one to the Bottom Corner Cap assembled in the previous step using (4) Bolts [E] and Nuts [G]. See Figure 17 . Nut [G] Top/Bottom Corner Cap LTX Door Leaf Hinge [FA2120] Bolt [E] Figure 17 © Munters Corporation, November 2023 QM1410r0...
  • Page 24 Bracket using (4) TEK Screws [D] so that the Spring Latch will be on the same side of the of the door as the Leaf Hinge. See Figure 18 . TEK Screw [D] R.H. Center Top Corner Bracket [FA2124] R.H. Center Door Panel [FA2105] R.H. Center Bottom Corner Bracket [FA2125] Spring Latch [K] Figure 18 © Munters Corporation, November 2023 QM1410r0...
  • Page 25 Stand-off. See Figure 19B. Light Trap material RH Door Assembly Figure 19A Stand-off DO NOT nest here DO NOT nest here Figure 19B © Munters Corporation, November 2023 QM1410r0...
  • Page 26 Top Corner Bracket and (10) TEK Screws [D] in the Bottom Corner Bracket. See Figure 20 . R.H. Center Top Corner Bracket [FA2124] TEK Screw [D] R.H. Center Bottom Corner Bracket [FA2125] TEK Screw [D] Spring Latch Figure 20 © Munters Corporation, November 2023 QM1410r0...
  • Page 27 66”L. J-Hook Rod [FA2142] Slot in Top/Bottom Corner Bracket [FA2119] 66”L. J-Hook Rod [FA2142] Closed Eye Bolt [N] Nut [P] Hole in R.H. Center Bottom Corner Bracket [FA2125] L.H. Center Bottom Corner Bracket [FA2127] Figure 21 © Munters Corporation, November 2023 QM1410r0...
  • Page 28 72½ ”L., then peal the backing off of the Brush Seal and carefully stick them to the 4 sides of the door where they were cleaned. See Figure 22 . Brush Seal Area to be cleaned Area to be cleaned Brush Seal Figure 22 © Munters Corporation, November 2023 QM1410r0...
  • Page 29 Attach the Light Gap Cover Bracket [FA2147] to the left inlet edge of the R.H. Door and fasten in place using (4) TEK Screws [D]. See Figure 23 . R.H. Door Light Gap Cover Bracket [FA2147] TEK Screw [D] Figure 23 © Munters Corporation, November 2023 QM1410r0...
  • Page 30 Attach the L.H. Door to the LTX Housing by sliding each Leaf Hinge over the Hinge Pins mounted to the left side of the LTX Housing. See Figure 24. Leaf Hinge Hinge Pin Figure 24 © Munters Corporation, November 2023 QM1410r0...
  • Page 31 Attach the R.H. Door to the LTX Housing by sliding each Leaf Hinge over the Hinge Pins mounted to the right side of the LTX Housing. See Figure 25. Leaf Hinge Hinge Pin Figure 25 © Munters Corporation, November 2023 QM1410r0...
  • Page 32 DO NOT over tighten Grease Fitting as this may cause the hinge to bind on the pin. Leaf Hinge Grease Fitting [M] Spring Latch [K] Spring Latch Catch [L] Lag Screw [B] Figure 26 © Munters Corporation, November 2023 QM1410r0...
  • Page 33 Eye Bolt until the door opens and closes freely. Then tighten the upper nut back down. See Figure 27. Installation Complete. Continue with the Fan Installation per the manual for the fan. Figure 27 © Munters Corporation, November 2023 QM1410r0...
  • Page 34: Maintenance

    Use no more than 1 shot when greasing hinge. • A premium non-water based grease is recommended: Shell Alvania #2 - Mobil Mobilux #2 Exxon Unirex N2 - Texaco Premium RB Mobil 532 - Texaco Multifak #2 © Munters Corporation, November 2023 QM1410r0...
  • Page 35 Munters Product and System manufacturers recommendations. The supplier listing above is given Warranties do not cover cone or fan as a reference only. Munters does not endorse any specific snow guard product and no performance warranty is implied. damage from external sources.
  • Page 36: Exploded View

    Exploded View © Munters Corporation, November 2023 QM1410r0...
  • Page 37 Chapter 5 Parts List © Munters Corporation, November 2023 QM1410r0...
  • Page 38 LTX Housing for Vortex Fans is developed and produced by Munters Corporation, Lansing, Michigan U.S.A. 1-800-227-2376 Munters Europe AB, Isafjordsgatan 1, P.O. Box 1150, SE-164 26 Kista, Sweden. Phone +46 08 626 63 00, Fax +46 8 754 56 66.
