  • Page 1 SECURITY ALARM SYSTEM INSTALLER MANUAL MODEL: S25V V : 3.3...
  • Page 2: Table Of Contents

    Contents Introduction The Secura Security Alarm System ---------------------------------- [4] LCD Display Description -------------------------------------------------------------- [4] Master / User Codes ------------------------------------------------------------------- [4] Info Key --------------------------------------------------------------------------------- [5] Installer Code --------------------------------------------------------------------------- [5] Arming ---------------------------------------------------------------------------------- [5] Instant Stay Arming ------------------------------------------------------------------- [5] Instant Arming -------------------------------------------------------------------------- [6]...
  • Page 3 System Call Out / Call In To System - With Voice Module ----------------------- [21] Technical Specifications ------------------------------------------------------------------ [22] Reset To Default Procedure -------------------------------------------------------------- [22] General Mounting Diagram For System Board --------------------------------------- [23] Automation / External Module Connection --------------------------------------------- [24] Warranty Of Secura Security Alarm System ------------------------------------------- [27] Note -------------------------------------------------------------------------------------------- [27]...
  • Page 4: Introduction The Secura Security Alarm System

    INTRODUCTION THE SECURA SECURITY ALARM SYSTEM The Secura Security Alarm System is manufactured to the highest specification and will provide many years of service if correctly installed and maintained. The unit is designed for simple operation to provide the maximum protection for you, your family or business.
  • Page 5: Info Key

    INFO KEY – [ ? ] [▲] [▼] User can press the INFO KEY [?] and use arrow key to browse a quick key reference as below. Press [#] key to exit. website *0 – Quick Arm *1 – Quick I / S Arm *2 –...
  • Page 6: Instant Arming

    INSTANT ARMING – [INST][CODE] In this arming mode, the zone programmed as entry / exit (delayed) type and zones that have the Stay attribute enabled by programming will trigger the alarm as soon as they are violated. STAY ARMING – [STAY][CODE] In this arming mode, the entry / exit type (delayed) will function as usual.
  • Page 7: System Troubles Display - [*][4

    SYSTEM TROUBLES DISPLAY – [*][4] The system permanently monitors several internal conditions for its proper functioning, such as: Item System Troubles Battery low voltage AC power loss Unsuccessful phone communication Date and time not programming Bell trouble If any system trouble, “S” shown on LCD display and will be disappeared all problems are fixed.
  • Page 8: Erasure Of All User Codes (Except The Master Code)

    ERASURE OF ALL USER CODES (EXCEPT THE MASTER CODE) – [*][7][MASTERCODE][3][1] After entering the commands, the “Erase All Users * to confirm?” is displayed followed by 3 beeps then press [*] key to erase all users code in system. Exit the Master Setup Number by pressing [#] key. CANCELLATION OF PHONE COMMUNICATION –...
  • Page 9: Keypad Special Alarms (By Pressing 2 Keys)

    KEYPAD SPECIAL ALARMS (BY PRESSING 2 KEYS)– [1]+[3], [4]+[6] AND [7]+[9] System will send a reporting code to the CMS and phone call with a voice message or synthesis sounds, according to these events: Panic Alarm [4]+[6], Medical Alarm [1]+[3], Fire Alarm [7]+[9] by pressing a combination of keys from keypad.
  • Page 10 After 2 digits number corresponding to the desired zone type has been entered, the displaying of the attributes 1 to 8 can be enabled / disabled based on the corresponding numbers on / off status. Zone attributes table: Attribute Descriptions Audile alarm Silent alarm An alarm triggered by an audible zone activates the siren,...
  • Page 11: Section [07]: Zone Response Time

    Note: 1) “√” the value set by programming for the respective attribute is available for the corresponding zone type. 2) “-“ the value set by programming for the respective attribute is not applicable to the respective zone type, although programmed as enabled. Default values of the zone types for zone 1 to 12.
  • Page 12: Section [08]: Set Of Option

    SECTION [08]: SET OF OPTION – [*][8][INSTALLER CODE][0][8] After entering the commands, the “System Option#08” and number 1 to 8 will be displayed followed by 3 beeps accordingly to the table bellow: Number Keypad lockout after 10 invalid codes. * Disable keypad lockout after 10 invalid codes. * Siren beep when key-switch arm / disarm.
  • Page 13: Section [10]: Set Of Option

    SECTION [10]: SET OF OPTION – [*][8][INSTALLER CODE][1][0] After entering the commands, the “System option#10” and number 1 to 8 will be displayed followed by 3 beeps accordingly to the table bellow: Number CMS reporting * Disable CMS reporting. Phone calls reporting. * Disable Phone calls reporting.
  • Page 14: Section [13]: Burglary / Fire Bell Cut Off Times - [*][8][Installer

    for exit time. The Maximum is 255 seconds. The exit / entry time sets the period of time permitted to arm the system and leaving the premises without triggering the alarm. The default entry time is 30 seconds and 60 seconds for exit time. Exit the Installer Setup Number by pressing [#] key.
  • Page 15: Section [17]: Modification Of The Master Code - [*][8][Installer

    SECTION [17]: MODIFICATION OF THE MASTER CODE – [*][8][INSTALLER CODE][1][7] After entering the commands, the “Inst. Setup No#17”will be displayed followed by 3 beeps. To modify the master code enter a 4 or 6 digits new code to “Master#■■■■”. The default 4 digits code are “1234” and 6 digits code are “123400”. Exit the Installer Setup Number by pressing [#] key.
  • Page 16: Section [25]: Second Phone Number For Cms - [*][8][Installer

    Output Type Description [00] – Latch on alarm. When alarm and it is shut off when disarming. [01] – Follow system state. When arming and it is shut off when disarming. [02] – Entry delay. When during the entry delay. [03] –...
  • Page 17: Section [27]: Event For Cms Transmission

    SECTION [27]: EVENT FOR CMS TRANSMISSION – [*][8][INSTALLER CODE][2][7] After entering the commands, the “CS Event Code#27” will be displayed followed by 3 beeps. Enable / disable for each event from 1 to 10. * Arming / Closing * Restores Zones * Stay / Instant Stay Arming Tamper * Disarming / Opening...
  • Page 18: Section [29]: Event For Cms Transmission

    SECTION [29]: EVENT FOR CMS TRANSMISSION – [*][8][INSTALLER CODE][2][9] After entering the commands, the “CS Event Code#29” will be displayed followed by 3 beeps. Enable / disable for each event from 1 to 5. * AC Loss * Battery Low Voltage Bell Trouble Aux Overload System Date Time Not Programmed...
  • Page 19: Section [34]: Daily Test Time Setting

    SECTION [34]: DAILY TEST TIME SETTING – [*][8][INSTALLER CODE][3][4] After entering the commands, the “CS Daily#0000” is displayed followed by 3 beeps. To program / modify the time of the daily test by follow the format [hhmm]. Each 2 digits group represents the hours and minutes.
  • Page 20: Section [37]: Walk Test

    SECTION [37]: WALK TEST – [*][8][INSTALLER CODE[3][7] This command allows the Installer to verifying each zone open or close after installation. A pulse siren will be generated. Exit the Walk Test by pressing [#] key. SYSTEM CALL OUT / CALL IN TO SYSTEM – WITHOUT VOICE MODULE If alarm or AC power loss is generated, system will call user and announce a synthesis sound regarding AC power loss (Long Beep) or zone open (Police Siren), after synthesis has finished press the [#][Master code] or [#][User code] to access to the system, there will sound 3 beeps...
  • Page 21: System Call Out / Call In To System - With Voice Module

    SYSTEM CALL OUT / CALL IN TO SYSTEM – WITH VOICE MODULE If alarm or AC power loss is generated, system will call user and announce a synthesis sound, after synthesis has finished press the [#][Master code] or [#][User code] to access to the system, there will sound 3 beeps after correct code and a long beep for the wrong code, user must re- enter again after the long beep has finished.
  • Page 22: Technical Specifications

    TECHNICAL SPECIFICATIONS ◦ Up to 4 Keypads ◦ Maximum cable wire length for keypad and zone: 50 meter ◦ Number of zones: 12 zones ◦ Zone type: Programmable ◦ EOL Resistor: 10k ohm (Blue) for zone 1 to 6 and 4.7k ohm (Brown) for zone 7 to 12 ◦...
  • Page 23: General Mounting Diagram For System Board

    GENERAL MOUNTING DIAGRAM FOR SYSTEM BOARD BAT+ BAT- - Aux + PGM1 PGM2 Z1/7 COM Z2/8 Z3/9 COM Z4/10 Z5/11 COM Z6/12 PHONE LINE BELL 16Vac ▽16Vac Resistor 10K Resistor 4.7K Blue Brown SIREN / (Zone 1/6) (Zone 7/12) S. LIGHT ☏...
  • Page 24: Automation / External Module Connection

    AUTOMATION / EXTERNAL MODULE CONNECTION 1. Lighting Secura System Board - AUX + PGM1 PGM2 230V (L) +12V PGM1 COM1 Automation Module Lighting 230V (N) Note: [*8 2525 22] enter [15] for PGM1. 2. RF Remote Control Secura System Board...
  • Page 25 3. Panic / Emergency / Fire Secura System Board - AUX + Resistor 4.7K / 10K ◙ Panic / Emergency / Fire Button Note: [*8 2525 00][Zone number] select zone type for [11], [12] or [13]. 4. Smoke Detector Secura System Board...
  • Page 26 5. Phone Line Detection Module Secura System Board - AUX + Resistor 4.7K / 10K Earth Phone Line Detection Phone Line Input Module Note: [*8 2525 00][Zone Number][05]. 6. Voice Module VOICE MODULE SECURA SYSTEM BOARD CONNECTOR Note: [*8 2525 00][10] Enable number 3.
  • Page 27: Warranty Of Secura Security Alarm System

    Supply WARRANTY OF SECURA SECURITY ALARM SYSTEM Manufacturer guarantees all Secura security alarm systems against defective parts and workmanship for 12 months from date of purchase. This warranty applies only to defects in components and not to damage due to causes beyond the control of Manufacturer, such as incorrect voltage, lightning damage, mechanical shock, water damage, fire damage or damage arising out of abuse and improper application of the equipment.
