Summary of Contents for Innon Link Touch LNK-T10-IP-SM
-
Page 1: Link Touch Surface Mount
Link Touch Surface Mount Manual... -
Page 2: Table Of Contents
Start the procedure via USB-C and a PC (screen password lost) ............... 26 Technical data ..............................27 Drawings ..............................27 Specifications.............................. 28 Guidelines for Disposal ..........................29 Innon Energy UK Ltd Registered address: Global House, 1 Ashley Avenue, Epsom, Surrey, KT18 5AD, United Kingdom Company number: 6740177 VAT Number: 941 2897 05... -
Page 3: Introduction
At Innon we believe on helping our clients achieving the best results, achieving greatness. We started with the very powerful Link Touch 10 and 15 inches Android panels with 6 cores CPUs flushed mounted, a pair of success stories in our industry. -
Page 4: Available Model
The integrated NFC reader and LoRa WAN gateway are not being used by the Link Touch app and there are currently no plans at Innon to use such features. The SDK is primarily designed to use LoRa WAN data only within the app itself and not to distribute to other networked devices. -
Page 5: Lnk-T10-Ip-Sm Connections
1) The back RGB LED light strips will need the blackout cover removed to be used 2) Please do not operate the reset button placed near the USB type C connection without consulting the manual carefully or checking with Innon. Operating the reset button wrongly might brick the device... -
Page 6: Wiring Power Supply
Internal speaker Link Touch is provided with an internal small mono speaker. The volume control is available also when using the Link Touch application. Innon Energy UK Ltd Registered address: Global House, 1 Ashley Avenue, Epsom, Surrey, KT18 5AD, United Kingdom... -
Page 7: Wall Installation
3) Connect the cables to the device and mount it carefully to the wall bracket, starting from the top 4) Fix the display using the 2 screws at the bottom of the wall mount bracket Innon Energy UK Ltd Registered address: Global House, 1 Ashley Avenue, Epsom, Surrey, KT18 5AD,... -
Page 8: Glass/Stickers Installation
2) Connect the cables to the device and mount it carefully to the wall bracket, starting from the top 3) Fix the display using the 2 screws at the bottom of the wall mount bracket Innon Energy UK Ltd Registered address: Global House, 1 Ashley Avenue, Epsom, Surrey, KT18 5AD,... -
Page 9: Vesa Mount Installation
VESA mount installation NOTE: VESA brackets are not provided by Innon. These brackets are standard and can be found on any retailer, including Amazon. Look for “VESA wall mount 75x75” or “VESA desk 75x75”. VESA arms can be also found, depending on the mounting requirements. -
Page 10: First Power Up From Factory: Select The Right Launcher
This will not be asked again on future reboots. If you accidentally selected the wrong launcher, you can factory default the screen from the Android settings to start again. Innon Energy UK Ltd Registered address: Global House, 1 Ashley Avenue, Epsom, Surrey, KT18 5AD, United Kingdom... -
Page 11: The Link Touch App
Note: the on/off button is disabled. Use the physical button on the back of the screen or remove power supply to power down the device. Innon Energy UK Ltd Registered address: Global House, 1 Ashley Avenue, Epsom, Surrey, KT18 5AD,... - Page 12 “Settings”. Allows the configuration of Link Touch • “About”. Provides information about the app release Innon Energy UK Ltd Registered address: Global House, 1 Ashley Avenue, Epsom, Surrey, KT18 5AD, United Kingdom Company number: 6740177 VAT Number: 941 2897 05...
-
Page 13: A Couple Of Notes About Security
Be aware that when proceeding with the factory default and deleting the app, Android will unlock completely allowing the installation of any app and removing all the layers of protection offered by the Link Touch system. Innon Energy UK Ltd Registered address: Global House, 1 Ashley Avenue, Epsom, Surrey, KT18 5AD, United Kingdom... -
Page 14: Navigation: Settings
Input the password and press “Confirm”. The settings menu is then available Innon Energy UK Ltd Registered address: Global House, 1 Ashley Avenue, Epsom, Surrey, KT18 5AD, United Kingdom... -
Page 15: Quick Settings: Volume And Brightness
“Set Colour & Brightness” button We are evaluating better use of this feature to make it controllable by networked devices, evaluating the best options for that. Innon Energy UK Ltd Registered address: Global House, 1 Ashley Avenue, Epsom, Surrey, KT18 5AD, United Kingdom... -
Page 16: Quick Settings: Schedule Reset
Note: for this function to perform correctly, make sure also that your Link Touch clock is set on the settings Innon Energy UK Ltd Registered address: Global House, 1 Ashley Avenue, Epsom, Surrey, KT18 5AD,... -
Page 17: Settings Password
If a password is set, you can also remove it allowing anyone to edit panels and settings, using the “Remove password” button that will be available. Innon Energy UK Ltd Registered address: Global House, 1 Ashley Avenue, Epsom, Surrey, KT18 5AD,... -
Page 18: System Settings
System settings opens the native Android Settings menu. Note that the Link Touch app removes some options from the settings to avoid corrupting the Link Touch. WiFi settings allows to discover and add connectivity to a WiFi network. Innon Energy UK Ltd Registered address: Global House, 1 Ashley Avenue, Epsom, Surrey, KT18 5AD, United Kingdom... - Page 19 To exit the settings, swipe up to show the buttons menu at the bottom of the screen and tap the “back” button until you get back to the main Link Touch app section Innon Energy UK Ltd Registered address: Global House, 1 Ashley Avenue, Epsom, Surrey, KT18 5AD,...
-
Page 20: Update Application
Make sure the Link Touch Surface Mount device is connected to your PC via USB. Run the file “updateLinkscreen.bat” and allow the screen to update DO NOT REMOVE POWER WHILE THE UPDATE PROCESS IS RUNNING Innon Energy UK Ltd Registered address: Global House, 1 Ashley Avenue, Epsom, Surrey, KT18 5AD, United Kingdom... -
Page 21: Navigation: Panels
Once you are in edit mode (or have no password configured), you can use the “+” button on the bottom right to add your new panels Innon Energy UK Ltd Registered address: Global House, 1 Ashley Avenue, Epsom, Surrey, KT18 5AD,... - Page 22 • Pinch zoom gesture, to allow users to use the pinch gesture to zoom in and out on a viewed page Innon Energy UK Ltd Registered address: Global House, 1 Ashley Avenue, Epsom, Surrey, KT18 5AD, United Kingdom...
-
Page 23: Panels View And Edit
Touch the “Enable Edit Mode” on the top right corner of the screen and insert the setting password. Innon Energy UK Ltd Registered address: Global House, 1 Ashley Avenue, Epsom, Surrey, KT18 5AD,... -
Page 24: Navigation: About
Link Touch Surface Mount Manual Document date: 1.0 29/11/23 Navigation: About The “About” screen provides information regarding the installed Link Touch application version, about Innon and our support useful links Remember: • http://support.innon.com/ to download the latest versions of software and documents •... -
Page 25: Factory Reset
Scroll down on the Android settings until you find the “Backup & reset” option, and select it From the options available, select “Factory data reset” Follow the instructions on screen to proceed. Innon Energy UK Ltd Registered address: Global House, 1 Ashley Avenue, Epsom, Surrey, KT18 5AD, United Kingdom... -
Page 26: Start The Procedure Via Usb-C And A Pc (Screen Password Lost)
Please allow the time for the screen to run through the factory process, do not power OFF the device until the screen has completed it. Innon Energy UK Ltd Registered address: Global House, 1 Ashley Avenue, Epsom, Surrey, KT18 5AD,... -
Page 27: Technical Data
Link Touch Surface Mount Manual Document date: 1.0 29/11/23 Technical data Drawings Innon Energy UK Ltd Registered address: Global House, 1 Ashley Avenue, Epsom, Surrey, KT18 5AD, United Kingdom Company number: 6740177 VAT Number: 941 2897 05... -
Page 28: Specifications
Output power 19dBm (470 MHz) /16dBm (868 MHz)/22dBm (915 MHz) Protocol V1.0.3 Class A/Class C Expansion Storage (optional) Internal micro SD Card slot (8GB/16GB/32GB/64GB/128GB) Innon Energy UK Ltd Registered address: Global House, 1 Ashley Avenue, Epsom, Surrey, KT18 5AD, United Kingdom Company number: 6740177 VAT Number: 941 2897 05... -
Page 29: Guidelines For Disposal
• In the event of illegal disposal of electrical and electronic waste, the penalties are specified by local waste disposal legislation. Innon Energy UK Ltd Registered address: Global House, 1 Ashley Avenue, Epsom, Surrey, KT18 5AD, United Kingdom Company number: 6740177 VAT Number: 941 2897 05...
