- Page 1 Controller Product Introductions APM-202B APM-302B APM-302C APM-352B ASA TOOLS ENTERPRISE CORP 2F-1., NO. 346, Sec 6, Nanjing E. Rd., Neihu Dist., Taipei city, Taiwan, 11470 Tel: +886-2-27900535 Fax: +886-2-27949952 Email: asaswdvr@ms16.hinet.net Website: www.asa-tool.com...
-
Page 2: Table Of Contents
Table of Content Special Thanks to our customer ■ Thank you for choosing our light and powerful electric screwdrivers. To ensure the tool fully utilizes its maximum performance and extend its life, please read this manual before use. -Table of Content- General Safety Warnings ..................... -
Page 3: General Safety Warnings
General Safety Warnings ■General Safety Warnings WARNING: Read all safety warnings and instructions Failure to follow the warnings and instructions may result in electric shock, fire and/or serious injury. Save all warnings and instructions for future reference. ■Work area safety -Keep work area clean and well lit. - Page 4 General Safety Warnings ■ Use and Maintenance of power tool - Please choose proper power tool according to the fastened object. Proper selected power tool gets better efficiency. - Do not use the power tool whenever power switch is faulty. Any power tool with faulty power switch is dangerous and must be repaired.
-
Page 5: Read Before Use
Read before use Read before use ■Please read the following notices before use: ‧Set-up Notice -The controller should be used indoor and in dry place without the presence of dust and iron grindings. -The controller should be positioned on a stable surface to avoid falling caused by vibration. -The controller should be kept away from high voltage sources and noise generating sources to avoid electromagnetic interference. - Page 6 Read before use ‧Safety notice -If notice smog, smell anything unusual, or hear any unusual noise from the controller, please stop using to avoid any hazard. Turn off the power immediately and contact your nearest sales agent after no more smog is found.
-
Page 7: Declaration Of Conformity Ce/Ukca/Service
Declaration of Conformity CE/UKCA/Service ■Declaration of Conformity CE We (ASA TOOLS Enterprise Corporation) declare under our sole responsibility that the products controller described under this manual are in conformity with the following Directives/ or standardization documents: Low Voltage Directive 2014/35/EU and EMC Directive 2014/30/EU. ■Declaration of Conformity UKCA We (ASA TOOLS ENTERPRISE CORPORATION) The subject equipment under declaration is in conformity with the UK-GB Regulation(s) below: Statutory Instruments 2016 No. -
Page 8: Product Information
- With output terminal for connecting to External controller for integrated control. -Digital identified system: When power supply connects to screwdriver and power is On, it will detect the type of screwdriver automatically. Specification ■ Model APM-202B APM-302B APM-302C APM-352B Item Input Voltage 100~240V 、... -
Page 9: Operation
Operation ■INSTALLATION While connecting DC cable Turn the power supply ON after DC cable is required to connect between between screwdriver and screwdriver is well connected screwdriver and power supply. Please power supply (refer to with it. The LED will flash kindly note the minimum bend radius(r) drawing below), please Orange 3 times and stay in Green... - Page 10 Operation ‧Soft-start setting (EXCEPT APM-202B) -Change the two-stage switch on the side of the power supply by hand. -Switch to SLOW mode 0 1 sec. The speed gradually increases from slow to constant faster speed. -Switch to FAST mode 0 0 sec. Constant speed without change.
- Page 11 Operation Two-stage Switch Top of the Power Supply AC input socket (C13 specification)
- Page 12 Operation ‧Indicator Light Model APM-202B APM-302B APM-302C APM-352B Item After switching on, flash Orange light three times, then ◎ ◎ ◎ ◎ Green turn to Green light. light Brakes No light No DC voltage output ◎ ◎ ◎ ◎ ◎...
- Page 13 Operation ‧Output (DC) Plug -Provide power to the electric screwdriver. -Plug specification Bottom of the Power Supply 5P connection 6P connection ‧OUTPUT-A: Signal output terminal (see picture 1) -A3 & A4: Switch on signal output. A3 and A4 will export no-voltage conduct signal when the electric screwdriver switched on.
- Page 14 Operation ‧JP-A: Terminal for External Controller -A5、A6: After completing following steps, make short-circuit for A5 and A6 to trigger the electric screwdriver (forward rotation only). STEP 1: STEP 2: STEP 3: STEP 4: Connect the cable to the Connect the Press and hold the buckle Switch the Power Supply ON, wait power supply.
-
Page 15: Troubleshooting
Troubleshooting ■Troubleshooting If the screwdriver does not work properly, follow the check-list below to examine your power supply. If none of the scenarios can apply to the problem you encountered, do not open the power supply. Contact your local sales agent immediately for further guidance. ‧The screwdriver is out of operation -Please check the LED indicator on the power supply -Please check whether the power plug is correctly and firmly plugged into the designated power source. - Page 16 Troubleshooting While connecting DC cable Turn the power supply ON after DC cable is required to connect between between screwdriver and screwdriver is well connected screwdriver and power supply. Please power supply (refer to with it. The LED will flash kindly note the minimum bend radius(r) drawing below), please Orange 3 times and stay in Green...
-
Page 17: Assembly Drawing
Assembly Drawing... -
Page 18: Parts List
PART NO. ITEM DESCRIPTION AVAILABLE MODEL 6Z2072-1 PLASTIC HOUSING UPPER COVER APM series 6Z2074-1 APM series PLASTIC HOUSING LOWER COVER 7L1920 APM-202B 7L1921 APM-302B MODEL LABEL APM series 7L1922 APM-302C 7L1923 APM-352B 2A2980 PCB SUB ASS'Y 2A2980-MP PCB SUB ASS'Y... - Page 19 Parts List No. PART NO. ITEM DESCRIPTION AVAILABLE MODEL 8 6B3020 Ø6.5*3.0 FOOT 7L1930 APM-202B SAFETY LABEL 7L1931 APM-302B SAFETY LABEL APM series 7L1932 APM-302C SAFETY LABEL 7L1933 APM-352B SAFETY LABEL 10 8T2663 M2.5*L:6 SCREW SWITCH 11 2A7092 APM series...
