SV1 GNSS Receiver

User Manual

V2.0_202307

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SV1 and is the answer not in the manual?

Questions and answers

Summary of Contents for Stec SV1

  • Page 1: User Manual

    SV1 GNSS Receiver User Manual V2.0_202307...

  • Page 2: Table Of Contents

    SV1User Manual Contents User Manual ............................1 1. Introduction ..........................3 1.1 Appearance ........................... 3 1.2 Indicator ..........................3 1.3 Interface..........................4 1.4 Power button ......................... 5 2. Web User Interface ........................5 2.1 Position ..........................6 2.2 Satellites ..........................7 2.3 Modules ..........................

  • Page 3: Introduction

    SV1 User Manual 1. Introduction This is the user manual for STEC SV1GNSS receiver. It gives basic description and operation guide which may help user to operate device properly. 1.1 Appearance STEC SV1 main body is designed with magnesium alloy material to provide durable usage and better heat dispersion as well as light weight 695g.

  • Page 4: Interface

    SV1 User Manual 1.3 Interface STEC SV1 GNSS receive bottom interface is shown as below.

  • Page 5: Power Button

    SV1 User Manual 1.4 Power button The main function as below: Long press button for five seconds until hear one Power On beep and see all lights on to power on receiver. Long press button for three seconds then release, will hear the voice “Please release button, short...

  • Page 6: Position

    SV1 User Manual 2.1 Position View basic position information, satellite number, PDOP and time. In static mode, can start and stop recording here.

  • Page 7: Satellites

    SV1 User Manual 2.2 Satellites View satellite list and satellite map, set cut-off angle. 2.3 Modules View receiver information: firmware version, GNSS board, and network module. 2.4 Working Mode Configure working mode: base, rover or static. Also can configure data-link parameters.

  • Page 8: Satellite Setting

    SV1 User Manual 2.5 Satellite Setting Configure the satellites to be used. 2.6 System Para Configure receiver settings. - User can set time zone and sensor update rate. - Smart voice broadcast can be activated or not according to client need.

  • Page 9: Output

    SV1 User Manual 2.7 Output Configure NMEA data output through Bluetooth. 2.8 Raw Data Download raw data or convert data to RINEX format. User can use check box, then click “Download choose” button to download multiple files. The default static file type is *.dat, if users want to convert the file type to Rinex format, you can select one file, then press “Modify”...
  • Page 10 SV1 User Manual Backup data The points collected in SurPad4.x will be backup in receiver storage automatically to avoid data loss. Can restore the data to SurPad software.

  • Page 11: Log

    SV1 User Manual 2.9 Log The log files can be used to diagnose issues. Click “download” to download the files.

  • Page 12: Management

    SV1 User Manual 2.10 Management User can update receiver and GNSS firmware as well as register device, format internal disk, restore factory setting, restart device. To update the firmware, click “Choose File” to import the firmware, then click “Upload File” to start updating.
  • Page 13 SV1 User Manual System Operation In this menu, users can make the four kinds of operation, selfcheck, format disk, restart device, factory reset.

  • Page 14: Basic Operation

    This part shows user some basic operations to start work. 3.1 Insert SIM card SV1 supports network working mode. Open the cover and insert SIM card. 3.2 Charge the battery SV1 is equipped with Type-C charger which support maximum 45w PD quick charge.

  • Page 15: Imu Sensor

    SV1 User Manual 3.4 IMU Sensor STEC SV1 is integrated with powerful calibration-free IMU sensor to give better experience in the real field work. 3.4.2 IMU Tilt Survey To initialize the IMU sensor, receiver must be in Fixed solution. In SurPad4.0 software, connect device and click “Device” ->...

  • Page 16: Ar Stakeout

    SV1 User Manual 3.5 AR Stakeout STEC SV1 is integrated with high resolution camera to support AR stakeout function, which give very useful guide for stakeout in the real field work. Caution: Intended for sale and application in a business environment.
  • Page 17 Model No.: SV1 guangzhou star information technology co.,ltd hereby declares that this [Name: GNSS RECEIVER, Model: SV1] is in compliance with the essential requirements and other relevant provisions of Directive 2014/53/EU. The full text of the EU declaration of conformity is available at the internet address: www.think2stec.com...
  • Page 18 SV1 User Manual FDD-LTE Band 20: 23.47dBm, TDD-LTE Band 38: 23.03dBm, TDD-LTE Band 40: 22.85dBm Bluetooth Bluetooth Version: Bluetooth V4.1 Frequency Range: 2402-2480MHz Max.RF Output Power: 4.57dBm (EIRP) Wi-Fi(2.4GHz) 2412-2472MHz for 802.11b/g/n(HT20) Frequency Range: 2422-2462MHz for 802.11n(HT40) Max.RF Output Power: 17.46dBm (EIRP)
  • Page 19 FCC Warning: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
