Summary of Contents for PIZZELL Cart Pro
- Page 1 Three-Shelf Dining Cart Table Assembly Instructions...
-
Page 2: Warranty
Contents Index Warranty . . y ........ -
Page 3: Parts List
Parts List 2PCS Screw M6*12 8PCS Nut M10 2PCS Screw M6*16 8PCS Nut M10 2PCS Screw M6*40 6PCS Screw M10*85 2PCS Hook 4PCS... - Page 4 Assembly Instructions Step 1 If you buy the cart with stainless steel tabletop, you need to remove the protective film of the stainless steel tabletop. If you buy the black one, skip it. ATTENTION When installing, we suggest you can assemble it on the carton which come with the product, or any other clean floor to avoid the desktop being scratched.
- Page 5 Step 3 Assemble the leg A to the top plate with 4pcs screw P. A Leg P Screw M6*12 4PCS Step 4 Assemble the leg B to the top plate with 4pcs screw P. B Leg P Screw M6*12 4PCS...
- Page 6 Step 5 Attach 2 wheels F to the leg B using screw V, and lock with nut U and T. F Wheels T Nut M10 2PCS U Nut M10 2PCS V Screw M10*85 2PCS Step 6 Assemble the middle plate D to the legs with 4pcs screw Q. D Middle plate Q Screw M6*16 4PCS...
- Page 7 Step 7 Assemble the bottom plate E to the legs with 4pcs screw R. E Bottom plate 1PC R Screw M6*40 4PCS Step 8 Assemble the gas bottle hook for gas bottle G on side beam with 2pcs screw R. Assemble the gas bottle support H on bottom plate with 2 pcs screw Q.
- Page 8 Step 9 Assemble the trash bag support. L Trash bag support 1PC Inserting the trash bag support into the small pins on the sides and tighten the screws on them. Step 10 Assemble the rest accessories to meet your needs. Spice Station 1PC K Bracket S Hook...
