Summary of Contents for Genki GKS-200
- Page 1 G K S - 2 0 0 | U s e r M a n u a l...
- Page 3 Read all safety tips, warning messages, terms of use, and disclaimers carefully. Users take full responsibility for all usage and operations. Familiarize yourself with the related regulations in your area. You are solely responsible for being aware of all relevant regulations and using GENKIPWR products in a way that is compliant. GENKIPWR GKS-200...
-
Page 4: Table Of Contents
CONTENTS 1. Specifications 2. Safety Instructions 3. In The Box 4. How It Works 5. Speed Up Solar Charging 6. Solar Setup 7. Warranty... -
Page 5: Specifications
1. Specifications General Info GKS-200_20V GKS-200_40V Nominal Power 200W A-grade monocrystalline silicon solar cell Cell Type Cell Efficiency Maximum Power Current (lmpp) Maximum Power Voltage(Vmpp) Open-circuit Voltage(Voc) Short-circuit Current (lsc) 10.5A 5.25A Maximum System Voltage DC200V Output Tolerance ±5% DC Output-1 Direct output line+PV connector Cable 1：14AWG*1.5m +PV connectors... -
Page 6: Safety Instructions
2. Safety Instructions 1. The solar panel should be placed in direct sunlight and adjusted to the appropriate angle to receive the maximum power generation effect. 2. This product is suitable for mobile energy storage devices with a rated voltage of DC 24-28V (solar charging protection function is required) or for charging batteries. -
Page 7: In The Box
3. In The Box Side A Side B Solar Panel User Manual& Warranty Card XT60 Output Controller 4. How lt Works Solar panel (20V or 40V) AC input XT60 port 200W input (Not included in the accessory) GENKIPWR Portable Power (Not included in the accessory) -
Page 8: Speed Up Solar Charging
(Not included in the accessory) GENKIPWR Portable Power (Not included in the accessory) *Do not use three or more GKS-200 solar panels in parallel and connect them to GK-800/ GK-1200/GK-2000 and other GENKIPWR series products. The working voltage will exceed the limit. - Page 9 ① Open the solar panel ② Open the bracket to support the solar panel ③ Connect GENKIPWR with cables AC input XT60 port 200W input (Not included in the accessory) (Not included in the accessory)
- Page 10 ④ Adjust the angle of the solar panel to maximize sunlight absorption 90∠° 90∠° The performance of solar panels will vary depending on environmental conditions. The standard testing conditions are: * Irradiance: 1000W/m2 * Temperature: 25°C * AM: 1.5 * Power/Voltage/Current temperature coefficient: -0.35%/°C ;-0.272%/°C;+0.044%/°C.
-
Page 11: Warranty
Warranty 1. Claiming a warranty requires your receipt, invoice, or order number. We may need to confirm your information. 2. GENKIPWR provides by default for each power station product a 2-year warranty from the date of purchase. 3. Free repair or replacement is provided within the scope of the warranty during the warranty period. 4. - Page 12 www.dowellelectronic.com Dowell Technology Co.,Ltd.
