SMA8146-0178
1.6
(.063)
17
(.669)
Parts
Material
Ferrule
Contact Pin
Beryllium Copper
Insulator
Body
Weight: 3.08 g
Suitable Cables: RG178, RG196, RG178-FEP
This part number complies with RoHS.
Notice: JYEBAO reserves the right to make modifications deemed appropriate.
SMA Jack Crimp For Panel Receptacle
4.5
(.177)
9.1
(.358)
MOUNTING HOLE :
8.64
(.340)
Brass
Gold 5 Over Nickel 50 Over Copper 50
Gold 20 Over Nickel 50 Over Copper 50
Teflon
Brass
Gold 5 Over Nickel 50 Over Copper 50
8.64
(.340)
12.7 S.Q
(.500 S.Q)
4.32
(.170)
Plating (Micro-inch)
50Ω
Advertisement
Table of Contents
Summary of Contents for JYEBAO SMA8146-0178
- Page 1 Gold 20 Over Nickel 50 Over Copper 50 Insulator Teflon Body Brass Gold 5 Over Nickel 50 Over Copper 50 Weight: 3.08 g Suitable Cables: RG178, RG196, RG178-FEP This part number complies with RoHS. Notice: JYEBAO reserves the right to make modifications deemed appropriate.
- Page 2 Step 4: PUT COVER " B " ON BODY " A " . Step 5: SLIDE FERRULE " C " TOWARDS THE CONNECTOR " A " AND CRIMP IN " S ". This part number complies with RoHS. Notice: JYEBAO reserves the right to make modifications deemed appropriate.
