Summary of Contents for VIAIR EVC23P
- Page 1 EVC23P RECHARGEABLE CORDLESS TIRE INFLATOR USER MANUAL It is essential that you and any other operator of the product read and understand the contents of this manual before using this product.
-
Page 2: Table Of Contents
CONTENTS: Important Safety Instructions ............1 Product Overview . -
Page 3: Important Safety Instructions
9. Only use the original charging cable and a power adapter supplied by a qualified manufacturer to charge this device. 10. If the battery becomes deformed, swollen or starts leaking during operation, stop use immediately and contact VIAIR for help at www.viaircorp.com or at 1-949-585-0011 if calling from the U.S. ®... -
Page 4: Product Overview
PRODUCT OVERVIEW: Air Hose Swivel-Ported Air Hose LED Light Type-C Port Heat Emission Holes Battery Indicator Pressure Unit Tire Pressure Actual Value Mode Indicator Tire Pressure Set Value LED Digital Screen Start Button + Button Light Button Mode Button - Button... -
Page 5: Inflation Modes
INFLATION MODES: This device is equipped with 5 inflation modes. Each mode has a default pressure value from the factory. Default pressure values can be changed by using the “+” or “ – “ buttons. The device will automatically memorize the preset values for each inflation mode next time it’s tuned on. ”... -
Page 6: Air Hose Installation & Storage
AIR HOSE INSTALLATION & STORAGE: Installation. Connect the male threaded end of the hose to the female threaded port on the top-right corner of the unit, tighten clockwise. Storage. After using the compressor, insert the swivel-ported end of the air hose into the storage compartment on the top-left corner of the unit. -
Page 7: Operating The Device
OPERATING THE DEVICE: Turning On The Device. 1. Press and hold the start “ ” button to start the device. 2. Press the mode “ ” button to switch to the desired inflation mode. 3. Adjust pressure to desired value by using the “+” or “ – “ buttons. Once turned on, the compressor will automatically stop when the pressure value is reached. -
Page 8: Inflating Tires
INFLATING TIRES: 1. Connect the air hose to the compressor. 2. Connect the air hose to the tire by screwing the swivel-ported end to the tire’s air nozzle. Applies to all vehicle and bicycle tires equipped with a Schrader-style inflation valves. 3. - Page 9 INFLATING TIRES ( CON'T ) : 4. Turn on the compressor and select desired inflation mode (refer to page 5) 5. Press the Start “ ” button to start inflating. When preset air pressure is reached, the device will automatically stop inflating. WARNING: AIR HOSE TEMPERATURE WILL BE HIGH AFTER INFLATION, BE CAREFUL WHEN DISASSEMBLING THE AIR NOZZLE.
-
Page 10: Inflating Recreational Equipment
INFLATING RECREATIONAL EQUIPMENT: 1. Connect the air hose to the compressor. 2. Select a suitable air nozzle and attach it to the swivel-ported end of the air hose. 3. The long nozzle is suitable for beach balls, floats, and other inflatable toys as well as for dust removal and cleaning. -
Page 11: Recommended Inflation Pressures
RECOMMENDED INFLATION PRESSURES: To ensure safety, check the manual of the object to be inflated for correct inflation pressure. In the absence of this information, please refer to the common recommended inflation pressure chart below to avoid injury caused by bursting due to over-inflation. Objects Classification Recommended... -
Page 12: Product Features
PRODUCT FEATURES: • Preset Pressure & Intelligent Memory • 5 Inflation Modes • 3 LED Light Modes • 3-piece Inflation Kit • USB-C to USB-A Charging Cord • Zinc Alloy Cylinder • High performance Lithium battery • Carry Bag... -
Page 13: Product Specifications
PRODUCT SPECIFICATIONS: Model EVC23P Battery Capacity 2500 mAh*2 (18 Wh) Battery Type Lithium-ion Charging Time 3 to 3.5 hrs Charging Interface USB-C Input 5V-2A Run Time ~30min Rated Working Pressure: 40PSI Max. Inflation Pressure 120PSI <100psi±1psi ≥100psi±2psi. Pressure Gauge Accuracy Working Temperature -4°F to 140°F when discharging 32°F... - Page 14 Corporation. ® Returns should be made within one year of the date of purchase, after a Return Goods Authorization (RGA) number has been assigned by VIAIR ® Corporation. To obtain RGA, fax a copy of your receipt to (949) 585-0188. For complete warranty details, please visit: www.viaircorp.com/warranty PLEASE NOTE: THIS WARRANTY COVERS PRODUCT DEFECTS ONLY;...
