KOO K A BUR RA COT IN ST R U CT IO N G U ID E

Advertisement

loading
Need help?

Need help?

Do you have a question about the JoEY KOOKABURRA and is the answer not in the manual?

Questions and answers

Summary of Contents for Koala JoEY KOOKABURRA

  • Page 1 KOO K A BUR RA COT IN ST R U CT IO N G U ID E...

  • Page 6: Care Recommendations

    RED NOSE RECOMMENDATIONS Red Nose Recommendations for babies aged 0-12 months to help reduce the risk of sudden infant death: 1. Always place baby on their back to sleep. 2. Keep baby’s face and head uncovered. 3. Keep baby smoke free, before and after birth. 4.
  • Page 7 Configuration A. High Configuration B. Low Configuration After reading the warnings, the red nose recommendations, and the care recommendations, scan the QR code to watch a video which demonstrates how to assemble the cot.
  • Page 8 What’s in the box End Panel x2 Retainer x4 Safety Bolt x4 Corner Spacer x4 Side Panel x2 Base Platform x1 Middle Spacer x2...
  • Page 9 Introducing the Koala safety bolt Ensure that cap is pressed up when rotating.
  • Page 10 Lay out the side and end panels on the floor with hooks facing upwards. Step 1: Align end panel hooks with the side panel slots. Push the side panel down to make sure they are locked in. Repeat steps for the other side. Ensure bracket holes align...
  • Page 11 Step 2: Assemble the end panel into position and secure with hooks. Note: The following steps are for the high configuration, for low configuration go to step 3B. Step 3A: Place the middle spacers into the centre pins and ensure they are upright.
  • Page 12 A. High Configuration Step 4A: For the baby configuration, fasten the threaded spacers to the retainer through the base panel. Repeat on all corners. A. High Configuration Step 5A: Lower the bed base with attached spacers onto the support brackets. Align the bottom hole of the spacers with the holes on the metal brackets.
  • Page 13 A. High Configuration Step 6A: Fasten the bed base down by screwing the safety bolts into the bottom of the corner spacers through the metal brackets. Note: All assembly fittings should always be tightened properly and fittings should be checked regularly and re-tightened as necessary. A.
  • Page 14 B. Low Configuration Step 3B: Lower the bed base onto the support brackets. Align the corner holes of the bed base with the holes on the metal brackets. Note: This configuration does not need corner spacers and middle spacers and they should be stored properly.
  • Page 15 B. Low Configuration Step 5B: Fasten the bed base down by screwing the safety bolts into the retainers through the metal brackets. Note: All assembly fittings should always be tightened properly and fittings should be checked regularly and re-tightened as necessary. B.
  • Page 16 Manufactured for Koala Sleep Pty Ltd Website: koala.com Phone: 1800 575 337 Address: Unit 12 37-41 O’Riordan Street, Alexandria, NSW 2015, Australia Date of launch - 03/2023 SKU-105-0007 This COT is intended for babies aged 3 months to when they are observed attempting to climb out of the cot and looking like they might succeed.
