CHANGSHA SPARK TECHNOLOGY ELECTRONICS CO.,LTD
KUNGFUPAO
SF-K2
USER MANUAL
SF-K2
KUNGFUPAO USER MANUAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the KUNGFUPAO SF-K2 and is the answer not in the manual?

Questions and answers

Summary of Contents for Spark KUNGFUPAO SF-K2

  • Page 1 CHANGSHA SPARK TECHNOLOGY ELECTRONICS CO.,LTD KUNGFUPAO SF-K2 USER MANUAL SF-K2 KUNGFUPAO USER MANUAL...
  • Page 2: Table Of Contents

    CONTENTS DISCLAIMER ▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪A1 PREFACE ▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪A1 1 PRODUCT INTRODUCTION ▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪A2 1.1 PRODUCT OVERVIEW ▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪A2 1.2 PRODUCT ACCESSORIES ▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪A3 1.3 BUTANE GAS ▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪A3 2 TECHNICAL PARAMETER ▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪A4 ▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪A4 2.1 FUNCTIONAL CHARACTERISTICS 3 SCREEN OPERATION GUIDE ▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪A5 3.1 BACK PANEL INTRODUCTION ▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪A5 3.2 DMX PARAMETER LIST ▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪A6 4 SAFETY NOTICE ▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪A6...
  • Page 3: Preface ▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪▪A1

    This product is a professlonal machine, we do not assume any responsibiity for accldents or losses caused by theuse or maintenance of this product by personnel without professional training and permisslon. If the information contalned in the manual or the product speclfications are changed, Spark Fabrica will not informou further and responsible for anv errors or omissions.
  • Page 4: Product Introduction

    Kungfupao is a new spark device without gunpowder and reworks invented by Changsha Spark Technology Electronics Co.,Ltd. It is a new product which produce istant spark e ect. This product can be widely used in weddings, opening celebration, meeting, sports events, concert and so on.
  • Page 5: Product Accessories

    CHANGSHA SPARK TECHNOLOGY ELECTRONICS CO.,LTD 1.2 PRODUCT ACCESSORIES 1.6M Power Plug User Manual 3 Meters Power Pair Cable (optional) 3 Meters DMX Pair Cable Open the package carefully and check to make sure the goods are in good condition.
  • Page 6: Technical Parameter

    CHANGSHA SPARK TECHNOLOGY ELECTRONICS CO.,LTD 2 TECHNICAL PARAMETER Brand SPARK FABRICA Identification Name Kungfupao/SF-K2 Input Voltage & Frequency 100-260V,50 / 60HZ AC Power Power Granule Composite Ti (medium) Powder Consumption (100% Output) Granule Height Powder Tank Capacity Tank type...
  • Page 7: Screen Operation Guide

    CHANGSHA SPARK TECHNOLOGY ELECTRONICS CO.,LTD 3 SCREEN OPERATION GUIDE 3.1 BACK PANEL INTRODUCTION Light on when there is an error. DMX signal. Flash means DMX signal available, otherwise no DMX signal Working Indicator ENTER MENU Confirm and save Switch interface to setup...
  • Page 8: Dmx Parameter List

    Keep audience and ammable material at a minimum distance of 3m from SPARK JET PRO. Make sure the sparks shoot out by the unit can NOT touch any objects. Clean the unit before and a er the show. Make sure that no Composite Ti remains in the pipe and the nozzle.
  • Page 9 Make sure that children, unauthorized people or animals get never access to the machine. The noise level generated from the spark machine is estimated at 80dB. Wear eye protection when you fi`ll in granules or test the spark machine. KUNGFUPAO USER MANUAL SF-K2 |...
  • Page 10: Machine Operation

    CHANGSHA SPARK TECHNOLOGY ELECTRONICS CO.,LTD MACHINE OPERATION 5.1 ADJUST ANGLE * The angle of gun tube can be adjusted freely. There are 5 angles, and each angle is spaced 15 degrees apart. Please install safety shaft to the position required before adjustment and pull up lock pin to adjust the angle.
  • Page 11: Install Machine

    CHANGSHA SPARK TECHNOLOGY ELECTRONICS CO.,LTD 5.2 INSTALL MACHINE Install machine on the solid horizontal ground or truss, through four M10 nuts on the base-plate. 5.3 INSTALL BUTANE GAS *Symbol of are showed on the panel. *Install tank: Combine tank’s gas with ,and spin to...
  • Page 12: Fill Granule

    CHANGSHA SPARK TECHNOLOGY ELECTRONICS CO.,LTD 5.4 FILL GRANULE Spark Fabrica Granule is the consumable specially designed for spark machine,to simulate cold fountain re works eect for stage. *Tear the vacuum package of granule,and fill the granule into the nozzle of Kungfupao.
  • Page 13: Start To Operate

    CHANGSHA SPARK TECHNOLOGY ELECTRONICS CO.,LTD START TO OPERATE 6.1 TURN ON MACHINE’S POWER AC power supply: Turn on the power switch, the RUN indicator light is lit, which means the power is connected. It indicates that no consumables are added when the LCD displays E1.
  • Page 14: Failure Handling

    Gas leakage fault WARRANTY INSTRUCTIONS Sincere thanks for your choosing Kungfupao SF-K2, you will receive quality servicefrom us. The product warranty period is 3 year. If there are any quality problems within 7 days aftershipping out from our factory, we can exchange a brand new same model machine for you.We will offer free of charge mainte- nance service for machines which with hardwaremalfunction (except for the instrument damage caused by human factors)in warrantyoeriod.
  • Page 15: Warranty Card

    CHANGSHA SPARK TECHNOLOGY ELECTRONICS CO.,LTD NOTICE For product damage not included in warranty range, we can provide paid service. *Invoice and warranty card are necessary when applying for maintenance service from SPARK FABRICA. WARRANTY CARD WARRANTY CARD Serial No:...
  • Page 16 www.sparkfabrica.com marketing@sparkfabrica.com +86 138 7585 1139...
