BIG ASS FANS Obsidian BAFCF30240B Installation, Operation And Maintenance Manual
BIG ASS FANS Obsidian BAFCF30240B Installation, Operation And Maintenance Manual

BIG ASS FANS Obsidian BAFCF30240B Installation, Operation And Maintenance Manual

Electric outdoor patio heater

Advertisement

Quick Links

MODELS
VOLTAGE
TOTAL POWER (W)
CURRENT(AMPS)
BAFCF30240B
208/240
2250/3000
10.8/12.5
FIRE/EXPLOSION HAZARD WARNING
NOT FOR USE IN HAZARDOUS OR EXPLOSIVE ATMOSPHERES
During operation, always ensure combustible materials are kept at a safe distance from the heater
body and from the emitted radiant energy. This heater is not intended for use in hazardous areas where
flammable vapours, gases, liquids or other combustibles are present. Failure to do so can result in
personal injury/or property damage.
FOR OUTDOOR RESIDENTIAL AND INDOOR OR OUTDOOR COMMERCIAL USE
BIG ASS FANS dba DELTA T LLC
238 INNOVATION DR. LEXINGTON KY 405011
PHONE: 877.BIG.FANS
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the Obsidian BAFCF30240B and is the answer not in the manual?

Questions and answers

Summary of Contents for BIG ASS FANS Obsidian BAFCF30240B

  • Page 1 Failure to do so can result in personal injury/or property damage. FOR OUTDOOR RESIDENTIAL AND INDOOR OR OUTDOOR COMMERCIAL USE BIG ASS FANS dba DELTA T LLC 238 INNOVATION DR. LEXINGTON KY 405011 PHONE: 877.BIG.FANS...
  • Page 2: Table Of Contents

    TABLE OF CONTENTS 1 - SAFETY ................................3 2 - INSTALLATION INSTRUCTIONS .......................... 5 3 - OPERATING INSTRUCTIONS ..........................9 3.2.1 Operation of the Remote Control ....................10 4 - MAINTENANCE ..............................11 5 - GROUNDING INSTRUCTIONS ........................... 14 WARNINGS THIS ELECTRIC APPLIANCE PRODUCES INFRARED HEAT, AND FAILURE TO FOLLOW WARNINGS AND INSTRUCTIONS CAN CAUSE FIRE, ELECTRIC SHOCK, OR INJURY.
  • Page 3: Safety

    shock, and injury to persons, including the following outlined in section 1 – SAFETY. Read all instructions before installing or using this heater. 1 - SAFETY WARNINGS WARNING: FIRE OR EXPLOSTION HAZARD • • Failure to precisely follow safety warnings could Do not insert or allow foreign objects to enter any result in serious injury or property damage.
  • Page 4 Contact an This product must be installed by a certified electrician and must adhere to all local, authorized BIG ASS FANS dealer for support. state and national electric codes (NEC) • Do not use the heater if the power cord is •...
  • Page 5: Installation Instructions

    BIG ASS FANS infrared heaters produce radiant heat that warms people and objects, rather than the air around them. The heater can be wall or ceiling mounted and includes brackets which allow the user to direct the infrared heat where desired.
  • Page 6 Ceiling Suspended Minimum Clearances ELECTRICAL INSTALLATION Safety Precautions 1. Each power supply circuit must be properly grounded. 2. Use a certified ground fault protection device for wet environment installations. 3. Use a proper electrical connection box 4. Supply voltage and frequency must correspond to the electrical rating indicated on unit’s information plate...
  • Page 7 WALL-MOUNTED INSTALLATION THE BAFCF30240B HEATER MUST BE INSTALLED WITH BOTH MOUNTING BRACKETS PROVIDED IN THE BOX. 1. Take the heater out of the box and remove all short part of the bracket. NOTE: Wall bolts or protective foam inserts. anchors are not supplied. Select an appropriate size to provide adequate support for the weight 2.
  • Page 8 CEILING MOUNTED INSTALLATION Heater should be hung using rigid mounting brackets, the unit must not be able to swing in any direction under applied load from wind or persons. It is highly recommended that users install the heater with the WARNING ceiling mounting hardware provided.
  • Page 9: Operating Instructions

    ADJUSTING DIRECTIONAL POSITIONING Never attempt to move or adjust the heater angle while it is running. Personal WARNING injury could result. 1. Turn off the heaters electrical supply line from the main power supply. 2. Allow the heater to cool before adjusting the angle. 3.
  • Page 10: Operation Of The Remote Control

    PCB BYPASS MODE When the bypass mode is selected, the heater will operate at 100% of rated power OR may be controlled by other type of external control system. Installer or specifier is responsible for compatibility and safety of controls not included with this heater.
  • Page 11: Maintenance

    2. The heater can be still used normally in the event the remote control is misplaced, however it must be used in PCB bypass mode where the heater will run fully on. Contact your local authorized BIG ASS FANS Dealer for remote replacement.
  • Page 12 REPLACING THE EMITTER Contact your distributor for the correct replacement emitter, providing the model number and rating from the rating label. Using an incorrect replacement emitter can cause the heater to fail. Notice: Read through the Emitter replacement procedure below before beginning the replacement. For easier replacement, remove the heater from the wall or ceiling.
  • Page 13 9. Insert the new emitter through the reflector 10. Connect the new emitter to the terminals of openings. Insert the Reflector Shields and bend the heater; screw in the protective plastic caps the tabs back into place. The Reflector Shields hold the emitter in the correct position during operation.
  • Page 14: Grounding Instructions

    5 - GROUNDING INSTRUCTIONS Connection to GFCI protected outlet is recommended For outdoor, exposed environments and/or as required by local, state and National Electrical Code (NEC) requirements. WARNING FAILURE TO USE A GFCI PROTECTED OUTLET COULD RESULT IN FIRE OR ELECTRIC SHOCK! This heater is for use on 240 Volts.
