keymaXX PK361 User Manual

Hide thumbs

Advertisement

Quick Links

Download this manual
PK361
08/2023
KEY0005518-000
user manual

Advertisement

loading
Need help?

Need help?

Do you have a question about the PK361 and is the answer not in the manual?

Questions and answers

Related Manuals for keymaXX PK361

Summary of Contents for keymaXX PK361

  • Page 1 PK361 08/2023 KEY0005518-000 user manual...
  • Page 2 Intended use: The keymaXX PK361 is a digital stage piano, designed to play sounds on the keyboard and make them audible through built-in speakers or headphones. Improper use of the product is considered improper and can lead to personal injury or property damage. No liability is assumed for damage resulting from improper use.
  • Page 3 Important safety instructions! Please read before connection! CAUTION! (Electro Magnetic Interference) The normal function of the product may be disturbed by Strong Electro Magnetic Interference. If so, simply reset the product to resume normal operation by following the owner‘s manual. In case the function could not resume, please use the product in other location.
  • Page 4 Hint! (Operating conditions) Due to its structural characteristics, the device is designed for indoor operation (IP20). Never expose the device to rain, moisture or liquids as this may cause damage. Vibrations, dust or solar radiation can also lead to damage, avoid them! Do not apply excessive force to the switches or controls.
  • Page 5 Hint! (Interferences with other electrical devices) Radios and televisions placed nearby may experience reception interference. Operate this unit at a suitable distance from radios and televisions. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: ...
  • Page 6 Cleaning: A regular cleaning of the device from impurities and dust increases the durability of the product. Always disconnect the device from the power supply before cleaning it! Never clean the appliance wet! Optical lenses should be cleaned with a dry microfiber cloth to optimize light output. Ventilation grilles and openings should always be cleaned of dust and dirt.
  • Page 7 PANEL CONTROL AND EXTENSION PORTS Using AC/DC Power supply Adapter The AC/DC power supply adaptor must be the one designated for the instrument. Please connect one side to the power supply socket an the back-panel and the other to the city- power network.
  • Page 8 PANEL CONTROL AND EXTENSION PORTS Audio output/headphone connection Audio output: first turn off the power supply of the electronic keyboard and external sound equipment, then insert one end of the audio cable into the PHONES/OUTPUT interface for audio output on the back of the electronic keyboard, and insert the other end into the audio input interface of the sound equipment.

  • Page 9: Basic Performance Method

    BASIC PERFORMANCE METHOD Up/Down button When the instrument is powered on, the functions shown below [FUNCTION] will be available; press [UP/DOWN] to switch to the functions shown above [FUNCTION], and the light above is on, and "RHYM". Displayed on the screen Press [UP/DOWN] again to switch to the functions shown below, and the light above is off and "TONE"...
  • Page 10 BASIC PERFORMANCE METHOD Master volume Press [FUNCTION] + [MASTER VOL+] or [MASTER VOL-] on the keyboard to control the master volume. "VOLUME" and the current volume level will be shown on the display. Press [MASTER VOL+] and [MASTER VOL-] at the same time, and master volume will be restored to the power- an preset value.
  • Page 11 BASIC PERFORMANCE METHOD Play demo songs There are 50 demo sounds to choose from, numbering "00" to "49". Press [DEMO SONG] to play all demo sounds by order. Press [FUNCTION] + [Number] on the keyboard to select the corresponding demo sound number.
  • Page 12 AUTOMATIC RHYTHM Rhythm selection There are 300 rhythms to choose from, numbering "000" to "299" When [UP/DOWN] is pressed, the light above is on and "RHYM" displayed on the screen. Press [RHYTHM] + [Number] on the keyboard to select the corresponding rhythm number. Rhythm control 1.
  • Page 13 AUTOMATIC RHYTHM Rhythm Vol Press [FUNCTION] + [RHYTHM VOL+] or [RHYTHM VOL-] on the keyboard to increase or decrease rhythm volume. Press [FUNCTION] + [RHYTHM VOL+] and [RHYTHM VOL-] on the keyboard at the same time, and the rhythm volume will be recovered to the power-on preset value. Metronome Press [Metronome] once to enable the metronome and again to disable the metronome.
  • Page 14 AUTOMATIC RHYTHM Tempo The default tempo is 120, which can be adjusted from "30" to "280". Press and hold [FUNCTION] + keyboard [TEMPO] number and -/+ keys to adjust the tempo. The light above [UP/DOWN] is on, With the rhythm playing, press and hold [FUNCTION] + keyboard [TEMPO] number and -/+ keys to adjust the tempo of rhythm.
  • Page 15 AUTOMATIC BASS CHORD Fingered chord The light above [UP/DOWN] is on, press the [FINGERED CHORD] button to start chord function and "FIN" is displayed on the screen. When the rhythm is activated, you can perform automatic chord according to the multi-finger chord rule in the chord keyboard area (keys 1-19 from the left). ...
  • Page 16 AUTOMATIC BASS CHORD Chord Timbre Press and hold [FUNCTION) + [CHORD TIMBRE] of the keyboard to change the chord timbre. Chord Vol Press [FUNCTION) + [CHORD VOL+] or [CHORD VOL-) on the keyboard to increase or decrease chord volume. Press and hold [FUNCTION) + (CHORD VOL +] or (CHORD VOL-) to restore the main volume to the preset value of startup.
  • Page 17 EFFECT CHANGE Tone Change  Sustain: Sustain the ending time of a note  Press (FUNCTION) + (SUSTAIN-ON) or [SUSTAIN-OFF) on the keyboard to enable or disable the sustain function, "SUS" appears on the screen if the Sustain function is enabled and disappears if the Sustain function is disabled.
  • Page 18 EFFECT CHANGE Transpose Transpose function saves you the trouble of rising and falling tones when playing the keyboard. Play the C note whatever the actual tone is. Press and hold [FUNCTION) + (TRANSPOSE-1), to lower by a semitone (half a step), and now C note becomes B note; press and hold the [FUNCTION) + [TRANSPOSE KEY] Key +1], to raise by a semitone (half a step), and now #C note becomes bD note.
  • Page 19 EFFECT CHANGE Split The keyboard can be split into two zones, in this way you can play two different timbres with your left and right hands respectively. You should set the timbre for the right hand side after the timbre that you were using before splitting is applied to the left-hand side.
  • Page 20 RECORDING & PROGRAMMING Programming Press and hold [FUNCTION] + [PROGRAMMING] on the keyboard once to enter the programming mode and "PRG" displayed on the screen. Press and hold [FUNCTION] + [PROGRAMMING] on the keyboard again to exit the programming mode, data will be cleared automatically.
  • Page 21 STATE MEMORY The state memory stores the tone, rhythm, and tempo parameter settings for you to choose from easily. You can save up to 3 different settings. Save state memory After you've set the preferred tone, rhythm and tempo, Up/Down button light is on, press and hold the [ MEMORY] button + [MEMORY 1] to [MEMORY 3] to save the current working state.
  • Page 22 INTELLIGENT THREE-STEP LESSON The intelligent teaching function is divided into three steps to guide the learner to gradually learn to play the electronic keyboard. The learner should exercise in the first step "One Key" to get familiar with the melody and rhythm of the song, followed by the second step "Follow" for correct playing of the song and then the third step "Ensemble"...

  • Page 23: Timbre Table

    TIMBRE TABLE...
  • Page 24 TIMBRE TABLE...

  • Page 25: Rhythm Table

    RHYTHM TABLE...
  • Page 26 RHYTHM TABLE...
