Summary of Contents for DEEPSEA developments EVSE PORTATIL V1.0
- Page 1 USER MANUAL PORTABLE CHARGE 16A EVSE PORTATIL V1.0 AUTHORS Deepsea Developments DEEPSEA DEVELOPMENTS 2023 Cali, CO | +57 316 703 8923...
- Page 2 IMPORTANT SAFETY INSTRUCTIONS WARNING: To reduce the risk of fire, electric shock and serious injury, observe the following. ● Installation work and electrical wiring must be performed by qualified persons in accordance with all applicable codes and standards. ● When cutting or drilling into the structure, do not damage electrical wiring and other utilities.
-
Page 3: Table Of Contents
Table of Contents 1. INTRODUCTION 2. IMPORTANT SAFETY INSTRUCTIONS 3. CAUTIONS 4. PRODUCT SPECIFICATIONS 5. SETTINGS - PORTAL SETUP 6. CHARGING YOUR VEHICLE 7. TROUBLESHOOTING - INDICATOR LIGHTS 8. PACKAGE LIST 9. WARRANTY Cali, CO | +57 316 703 8923... -
Page 4: Introduction
1. INTRODUCTION The 16A EVSE DSD Portable Charger is a device in charge of energy management for charging electric vehicles. The device has several modules, the first one is in charge of controlling the relays that are connected to the electrical network that will feed the vehicle and the control and monitoring system that will be in charge of managing the load. -
Page 5: Important Safety Instructions
UL Certified UL Recognized - Cable: (UL) E498724 2. IMPORTANT SAFETY INSTRUCTIONS Read these instructions, and the charging instructions in your vehicle owner’s manual, before charging your electric vehicle. Failure to do so may result in serious injury or death. Symbol Usage Take special note of all information marked with the following symbols: "Non - recyclable"... -
Page 6: Product Specifications
Do not step on the cable, do not pull it, do not fold it up and do not knot it. Do not drop the control unit or put heavy items on it. Do not place the charging cable near high-temperature objects. Do not use the device in extreme temperatures, normal operating range (-22°F to +122°F). -
Page 7: Settings - Portal Setup
5. SETTINGS - PORTAL SETUP When the card is energized, it will create a red wireless call Mubon_xxxx where the x represent the last 4 digits of the MAC of the device, in the following image you can see where 5ca8 are the last characters of the MAC, the key is: "DeepSmile"... - Page 8 At that moment the page will provide you with 2 links where you can see that the EVSE-WiFi card is connected to the internet After entering the Link http://mubon-5ca8/ you will see the following web page. Cali, CO | +57 316 703 8923...
-
Page 9: Charging Your Vehicle
With this you verify that the EVSE-WiFi card is connected to the internet and you will be able to use the functionalities of the charger 6. CHARGING YOUR VEHICLE NOTE: Ensure that the car is parked and the engine is turned OFF. Ensure the EV charger is not damaged before use. - Page 10 2. When you plug the portable charger, you see the green light indicating that the charger is ready to be used. 3. Plug the Charge Coupler into your vehicle’s charging outlet until it clicks. Once latched, the Charge Coupler will not disengage until the release button has been pressed manually Cali, CO | +57 316 703 8923...
-
Page 11: Troubleshooting - Indicator Lights
● Plug connected: The yellow light indicates that the charger is connected to the vehicle, and is waiting for the car to enable the battery charging process. 4. Charging begins automatically. Power will be delivered in accordance to the demand of the vehicle. -
Page 12: Package List
If the charger turns red when it is turned on, it means that the electrical network is not in a condition to be able to carry out the vehicle charging process. This can be due to: ● ground fault ● Overvoltage For more information on the error please check the configuration portal.
