- Page 1 OWNER’S MANUAL REFURBISHED CONDITIONER Read this owner’s manual thoroughly before operating the appliance and keep it handy for reference at all times. TYPE: WINDOW R-LW1516ER...
-
Page 2: Table Of Contents
TABLE OF CONTENTS TABLE OF CONTENTS 3 SAFETY INSTRUCTIONS 18 MAINTENANCE IMPORTANT SAFETY INSTRUCTIONS Air Filter 8 PRODUCT OVERVIEW 19 TROUBLESHOOTING Exterior Parts Before Calling for Service Interior Parts Normal Sounds You May Hear 9 INSTALLATION 22 WARRANTY Electrical Data 10 Installation Overview 11 Window Requirements 11 Preparation of Cabinet... -
Page 3: Safety Instructions
SAFETY INSTRUCTIONS SAFETY INSTRUCTIONS READ ALL INSTRUCTIONS BEFORE USE Your safety and the safety of others are very important. We have provided many important safety messages in this manual and on your appliance. Always read and follow all safety messages. This is the safety alert symbol. - Page 4 ● If you detect a strange sound, a chemical or burning smell, or smoke coming from the appliance, unplug it immediately, and contact an LG Electronics Customer Information Center. ● Never unplug the appliance by pulling on the power cord. Always grip the plug firmly and pull straight out from the outlet.
- Page 5 ● If water enters the product, turn off the power at the main circuit, then unplug the product and call for service. ● If the product has been submerged, contact an LG Electronics Customer Information Center for instructions before resuming use.
- Page 6 SAFETY INSTRUCTIONS CAUTION To reduce the risk of minor or moderate injury to persons, malfunction, or damage to the product or property when using this product, follow basic precautions, including the following: INSTALLATION ● Take care when installing the product that exhaust or condensation does not damage nearby property.
- Page 7 SAFETY INSTRUCTIONS REFRIGERANT (FOR R32 ONLY) WARNING ● Do not use means to accelerate the defrosting process or to clean, other than those recommended by the manufacturer. ● The appliance shall be stored in a room without continuously operating ignition sources (for example: open flames, an operating gas appliance or an operating electric heater).
-
Page 8: Product Overview
PRODUCT OVERVIEW PRODUCT OVERVIEW Exterior Parts Interior Parts Control Panel Evaporator Remote Controller Air Guide Air Filter Brace Compressor Condenser Front Grille Base Pan Air Outlet Power Cord Cabinet... -
Page 9: Installation
INSTALLATION INSTALLATION WARNING Electrical Data ● This appliance should be installed in Power cord may include a current interrupter accordance with the National Electrical device. TEST and RESET buttons are provided Code. on the plug case. The device should be tested on ●... -
Page 10: Installation Overview
INSTALLATION Installation Overview Optional: Heatproof foam (2) (Adhesive backed) Foam-PE (2) (Adhesive backed) Foam strip Right curtain (Non-adhesive) panel Optional: Lower panel guide (2) Optional: Window locking bracket Left curtain Optional: Sill bracket (2) Support panel bracket (2) Screws Needed Type 'A' Screws Type 'B' Screws Type 'C' Screws... -
Page 11: Window Requirements
INSTALLATION Window Requirements Preparation of Cabinet Remove 4 screws which fasten the cabinet ● This unit is designed for installation in standard at both sides and at the back. (Keep the double hung windows with actual opening screws for later use.) widths from 29"... -
Page 12: Cabinet Installation
INSTALLATION Cabinet Installation Insert the lower curtain panel guides into the bottom of the cabinet. Insert the guides so that the flange faces to the rear of the Open the window. Mark a line on the center cabinet. of the inside sill and extending across the center of the outside sill. - Page 13 INSTALLATION Pull each curtain panel out until it meets the Use a screwdriver or power drill to attach window sash track. Pull the bottom window the curtain panels to the window sashes sash down behind the upper panel guide by driving type C screws into the sashes until they meet.
- Page 14 INSTALLATION Cut the non-adhesive foam strip to the Connect the wire harness from the front proper length and insert it between the grille assembly to the air conditioner. upper window sash and the lower window sash. Foam Strip (Non-adhesive) Attach the front grille assembly to the cabinet by inserting the grille tabs into the Attach the window locking bracket with a slots on the front of the cabinet.
-
Page 15: Operation
OPERATION OPERATION Control Panel and Remote Control Remote Control Power Energy Saver - In this mode the compressor and fan turn off when the set Press to turn the air conditioner ON or OFF. temperature is achieved. Approximately Fan Speed every 3 minutes the fan turns on to allow the unit sensor to accurately determine if Press to set the fan speed to Low (F1),... -
Page 16: Wireless Remote Control
OPERATION Wireless Remote Control Temperature Control The thermostat monitors room temperature Inserting Battery to maintain the desired temperature. The thermostat can be set between 60 °F–86 °F Push out the cover on the back of the (16 °C–30 °C). Press arrows to increase or decrease temperature setting. -
Page 17: Ventilation
OPERATION Ventilation Additional Features Push the ventilation lever in to the closed position Slinger Fan to maintain the best cooling performance. Pull the ventilation lever out to open the vent and This air conditioner is equipped with a slinger draw fresh air into the room. fan. -
Page 18: Maintenance
MAINTENANCE MAINTENANCE Wash the filter using lukewarm water below 40 °C (104 °F). WARNING Before cleaning or performing maintenance, disconnect the power supply and wait until the fan stops. Gently shake the excess water from the filter and replace. Air Filter Check the air filter at least twice a month to see if cleaning is necessary. -
Page 19: Troubleshooting
TROUBLESHOOTING TROUBLESHOOTING Before Calling for Service The appliance is equipped with an automatic error-monitoring system to detect and diagnose problems at an early stage. If the appliance does not function properly or does not function at all, check the following before you call for service. Normal Sounds You May Hear High Pitched Chatter Today's high efficiency compressors may have a high pitched chatter during the cooling cycle. - Page 20 TROUBLESHOOTING Problem Possible Cause Solutions Make sure the air conditioner plug The air conditioner is unplugged. is pushed completely into the outlet. Check the house fuse/circuit The fuse is blown/circuit breaker breaker box and replace the fuse or is tripped. reset the breaker.
- Page 21 TROUBLESHOOTING Problem Possible Cause Solutions For proper water disposal, make Water drips The air conditioner is not tilted to sure the air conditioner slants indoors. the outside. slightly from the cabinet front to the rear. This is normal for a short period in Water collects in Moisture removed from air and areas with little humidity;...
