Jmaz Lighting VERSA FLEX BAR Quick Start Manual

Versa Flex Bar (Base)
- The Versa Flex Bar will reset once plugged in and the power switch is turned on.
- Allow the Versa Flex to boot up. This may take up to 1 minute.
-

How to Connect the RF Remote

- Go to the MENU on the LED Screen and select "SETTINGS"
- Maneuver to "RF Remote" and once you press enter, make sure that the setting
is turned "ON"
- Return to the "SETTINGS" Menu, and select "RF ID"
-
-
- Using the RF Remote, press the ID (button) you set rapidly 3 times, the "signal"
LED above the display should light up RED.

1. Auto Mode

a. Press "Auto" to begin Auto-Preprogrammed Shows
b. Select between the 12 preprogrammed shows by pressing any of the 1-12
buttons or by pressing the "+" / "-" buttons.

2. Sound Mode

a. Press "Sound" to place the Versa Flex Bar into Sound Mode
i.
b. Select between the 12 preprogrammed shows by pressing any of the 1-12
buttons or by pressing the "+" / "-" buttons.
c. Adjusting microphone Sensitivity
i.
ii.

3. Manual Mode

a. You can manually set up your own unique show by selecting different presets for
each part of the Versa Flex Bar
b. Moving Heads
i.
ii.
c. Warm
i.
VERSA FLEX BAR Quickstart Guide
You can pick RF IDs between #s 1-8
Once selected, press menu until the the display goes back to the starting
screen
The Versa Flex Bar has a default microphone sensitivity of 80%
Press "Sound" and then press "+" and "-" to adjust microphone sensitivity
Pressing "MID" will reset the sound sensitivity to the default setting of
80%
Pressing the "Head" button will turn on the moving heads.
Select between the 12 preprogrammed shows by pressing any of the 1-12
buttons or by pressing the "+" / "-" buttons.
Pressing the "Warm" button will turn on the Warm White LEDs.
