Page 1 HUVITZ Integrated Image Server, HIIS-1 HUVITZ Integrated Image Server HIIS-1 User Manual...
Page 2: Macular 3D Analysis Screen - Summary
However, Huvitz does not assume any responsibility for any latent mistake or omission that results from the use of information included in this user manual. Huvitz has the right to modify this product or product specifications any time, without special notification, and this modification may not be renewed in this document.
Page 3: Table Of Contents
HUVITZ Integrated Image Server, HIIS-1 CONTENT Introduction Overview Intended Use Safety Caution Recommended Specifications for the Installation 1.1.1 Server 1.1.2 Client Classification Symbol Information Installer Installation New Installation Version Upgrade Screen Description Access Screen Log-in Screen Administrator Screen 3.1.1 User Management 3.1.2...
Page 4: Macular 3D Analysis Screen - Summary
HUVITZ Integrated Image Server, HIIS-1 Macular Cross Analysis Screen – Comparison Macular Radial Analysis Screen - Summary Macular Radial Analysis Screen – OU Macular Radial Analysis Screen – Comparison Macular Raster Analysis Screen – Summary Macular Raster Analysis Screen – OU Macular Raster Analysis Screen –...
Page 5 Import Watcher daemon  Huvitz’s equipment connection diagram Huvitz’s equipment connection diagram  Setting method for device connection HIIS (v2.3.0) HUVITZ Integrated Image Server  HOCT-1/1F, HFC-1 (v1.3.3) Optical Coherence Tomography  HIS-5000U (v4.04.20) Slitlamp & Imaging System  HRK-9000A Auto Ref / Keratometer ...
Page 6: Introduction
Web browser.) Intended Use This software (HIIS-1) is a web-based software that can view, store, transmit, and analyze the medical images of patients acquired from ophthalmic imaging devices such as fundus cameras, optical coherence tomography, auto ref/keratometer, etc.
Page 7: Recommended Specifications For The Installation
HUVITZ Integrated Image Server, HIIS-1 Manufacturers are responsible for the safety, reliability, and performance of this program only when the following requirements are fulfilled. (1) When the program has been installed in a proper PC, following the manual. (2) When the program has been operated and maintained according to the manual and service manual.
Page 8: Symbol Information
HUVITZ Integrated Image Server, HIIS-1 Symbol Information Symbol Indication CE Mark (Marque CE) Authorized representative in the European Community – EU ONLY (Représentant autorisé dans la Communauté européenne- EU seulement) Authorized representative in Switzerland (Représentant autorisé dans la Suisse)
Page 9: Installer Installation
HUVITZ Integrated Image Server, HIIS-1 2 Installer Installation New Installation 1 Execute Setup_Huvitz_HIIS-1_X.X.X_x64_XXX_No.X.XX_release.exe Installer. 2 Start installation. Press on the Next button.
Page 10 HUVITZ Integrated Image Server, HIIS-1 3 Select component install. case installation, select both ‘PostgreSQL_Database’ and ‘Huvitz HIIS-1’. If it is not a new installation, uncheck the ‘PostgreSQL_Database’ item. 4 Designate the path to install the program. Use the default value.
Page 11 HUVITZ Integrated Image Server, HIIS-1 5 Designate the path to save the patient data. Since the size of image data is large (5~25MB by each measurement), save on the disc with sufficient available space. 6 Designate the path to install the program for the PostgreSQL database.
Page 12 HUVITZ Integrated Image Server, HIIS-1 7 Designates the port number to be used in the HIIS-1. Make sure to remember this port number since it is the number that is used when contacting from the personal PC via Web browser.
Page 13 There is no need to remember this port number. 10 Error message gets output when the number that is the same as the HIIS-1’s port number is already in use. Set to another number when the following message appears.
Page 14 HUVITZ Integrated Image Server, HIIS-1 11 Displays installation progress. 12 Install PostgreSQL database Start mid-way. Click on the Next button.
Page 15 HUVITZ Integrated Image Server, HIIS-1 13 Do not modify default value and continue to click on the Next. May malfunction when the default value is modified. 14 Designates PostgreSQL database installation path. Continue to click on the Next button.
Page 16 HUVITZ Integrated Image Server, HIIS-1 15 Designates PostgreSQL administrator password. Do not modify since it is used in the system internally. Continue to click on the Next button. 16 Previously set port number is designated automatically. Do not modify and continue to click...
Page 17 HUVITZ Integrated Image Server, HIIS-1 17 Sets up the PostgreSQL database language. Continue to click on the Next button since it is possible to use default value. 18 Continue to click on the Next button.
Page 18 HUVITZ Integrated Image Server, HIIS-1 19 Installation is executed. Wait for a moment. 20 PostgreSQL database installation is completed. Click on the Finish.
Page 19 21 When the black screen appears as follows, do not close the window. Instead, wait and it will close automatically. Since database initialization is in progress, it does not operate normally when it is closed mid-way. When the next window pops up, click the “Ok” button. 22 HIIS-1 installation is completed.
Page 20: Version Upgrade
HIIS-1 Version Upgrade To upgrade version, re-install after removing the installed HIIS-1 program. Uninstallation of installed version will automatically start when the upgrade version of HIIS-1 installer starts. 1. To remove installed version, please click ‘OK’ button. 2. Confirm the installed version, and click ‘Yes’ to start uninstallation.
Page 21 HUVITZ Integrated Image Server, HIIS-1 4. Uninstallation is completed 5. Remove installed version manually by following instructions if the installed version is not deleted automatically. Execute Window control panel and select ‘remove program’. 6. Select HIIS-1 and execute ‘remove’.
Page 22 HUVITZ Integrated Image Server, HIIS-1 7. HIIS-1 removal in progress.
Page 23 HUVITZ Integrated Image Server, HIIS-1 8. Press on the Next button after executing new version Installer. 9. This the process for upgrading version. Thus, press on the Next button after clearing selection in case of PostgreSQL_Database installation.
Page 24 HUVITZ Integrated Image Server, HIIS-1 10. Designates path to install the program. 11. Designates path to save HIIS-1 data. Designates the path that was set as it is since previous data needs to be used as is.
Page 25 HUVITZ Integrated Image Server, HIIS-1 12. Designates the port number to use in the HIIS-1. Remember this port number since is the number that needs to be used when contacting HIIS-1 server 13. Designates the port that is used in the installed PostgreSQL program.
Page 26 HUVITZ Integrated Image Server, HIIS-1 14. HIIS-1 installation is in progress. Click the “Ok” button that pops up next. 15. HIIS-1 upgrade is completed.
Page 27 HUVITZ Integrated Image Server, HIIS-1  Cache data of the previous version remains in the Web browser. Thus, there are instances in which screen does not appear properly on the Web browser after upgrading. In this case, open setting with Ctrl + Shift + Del button, delete all the Internet use records as follows and...
Page 28: Screen Description
2 Input address and port number where the HIIS-1 is installed in the Web browser’s address input space (①). In the example, address is 172.10.106.161 and the port number is 8080. If the PC in use is HIIS-1 server, then it is possible to input as localhost:8080 or 127.0.0.1:8080.
Page 29 HIIS-1  Method for finding out HIIS-1’s server address 1. Execute command screen in the computer where HIIS-1 server is installed. (input ‘cmd’ after clicking on the task bar’s Window button) 2. Input ‘ipconfig’. IPv4 address on the result screen is the Web server’s address.
Page 30: Log-In Screen
HUVITZ Integrated Image Server, HIIS-1 Log-in Screen Input user’s ID and password in the ID/Password input space used for logging-in. Administrator’s ID and Password that are used for logging-in after the first installation are admin / admin. Click on the LOGIN button.
Page 31: Administrator Screen
HUVITZ Integrated Image Server, HIIS-1 The following type of administrator page is shown first when logging-in as administrator instead of regular user. Use after creating regular user ID. Ensure that only the user that manages the system can access the system.
Page 32 HUVITZ Integrated Image Server, HIIS-1 Pop-up appears when user is added on normally. Click on ‘Confirm’. Currently registered user information appears when clicked in the following order; ‘USER’ > ‘LIST’. Each user can be modified and deleted. (Precaution) never delete the administrator.
Page 33: Configuration
HUVITZ Integrated Image Server, HIIS-1 3.1.2 Configuration May modify the settings related to the report in the REPORT menu.
Page 34: Patient Information Screen
HUVITZ’s ophthalmic device or when patient is added on using ‘Add Patient’ in the HIIS-1. When mouse is placed on top of the patient list, URL copy icon that enables move to the applicable patient immediately, gets activated.
Page 35: Patient Add-On Screen
HUVITZ Integrated Image Server, HIIS-1 Patient Add-on Screen Click on the ‘Add Patient’ button to add new patient. When button is clicked on, pop-up for adding in a patient appears, and click on the ‘Save’ button after inputting information on the patient in the input space.
Page 36: Move To Analysis Screen
HUVITZ Integrated Image Server, HIIS-1 Move to Analysis Screen Able to move to Analysis Screen by clicking on the ‘① -> ② -> ③’ in this order. Moves first to Macular 3D Analysis Screen. Analysis Screen Overview Summary: Shows summary information on the results of measuring one eye. This tab is selected by default.
Page 37: Macular 3D Analysis Screen - Summary
HUVITZ Integrated Image Server, HIIS-1 URL that can move immediately to the current inspection is copied. Export the current inspection data as zip. Displays the screen where Comment can be input. When Enter button input, menu modification and COMMENT button are pressed once again, Comment is saved. Input contents are output to the comment category at the report’s lower part.
Page 38 HUVITZ Integrated Image Server, HIIS-1 Macular 3D Analysis Screen – Summary (2) Button that displays scan path (No. ⑪) on top of the Fundus image or makes it disappear. Button that displays Thickness Map on top of the Fundus image or makes it disappear.
Page 39 HUVITZ Integrated Image Server, HIIS-1 Macular 3D Analysis Screen – Summary (3) Displays Thickness chart. Displayed differently depending on the selected Thickness (ILM-RPE/ILM-IPL) domain. ILM-RPE  Diameter of 6mm is divided into 9 domains, and the ETDRS Chart that displays average thickness by each domain is displayed.
Page 40 HUVITZ Integrated Image Server, HIIS-1 4mm for oval shape to higher and lower parts (the part in the No. ① image that is displayed in blue square) ILM-IPL Thickness Map is displayed. Applicable position’s thickness can be seen when the top of the image is clicked on with the mouse (1-Point-Magic function) ILM-RPE Thickness Map is displayed.
Page 41: Macular 3D Analysis Screen - Ou
HUVITZ Integrated Image Server, HIIS-1 Macular 3D Analysis Screen – OU User is able to carry out comparative analysis on patient’s both eyes through OU. Displays Fundus image. Basically, Color Fundus image measured on the same day is displayed, but if none, then IR Fundus image is displayed. When the end of the scan line, displayed on top of the Fundus image is dragged with mouse, B Scan image displayed on No.
Page 42: Macular 3D Analysis Screen - Comparison
HUVITZ Integrated Image Server, HIIS-1 Able to select measurements subjected to comparative analysis independently through Progression. Able to select Thickness. (ILM-RPE or ILM-IPL) Thickness Map is displayed on top of each Fundus image. Thickness Chart is displayed on top of each Fundus image.
Page 43: Macular 3D Analysis Screen - 3D
HUVITZ Integrated Image Server, HIIS-1 Selects the measurement data subjected to comparative analysis. Macular 3D Analysis Screen – 3D (1) IR and Color Fundus are displayed. Able to show by moving the Scan Line vertically/horizontally by dragging the mouse. B-Scan image is displayed.
Page 44: Macular Wide Analysis Screen
HUVITZ Integrated Image Server, HIIS-1 Macular Wide Analysis Screen Macular Wide provides Macular, Disc simultaneous Analysis Screen. Result of the analysis on the below mentioned domain is displayed on No. 2 according to the No. 1 Thickness selection.  ILM-IPL : Macular ...
Page 45: Macular Line Analysis Screen - Ou
HUVITZ Integrated Image Server, HIIS-1 Able to display by applying measurement of the distance between the two points of B Scan image, Color Map Overlay, Monochrome, and Monochrome reverse function. Able to display seven Segmentation information on the B Scan image.
Page 46: Macular Cross Analysis Screen - Summary
HUVITZ Integrated Image Server, HIIS-1 Macular Cross Analysis Screen – Summary Fundus image is displayed. Basically, Color Fundus image, measured on the same day is displayed. But if none, IR Fundus image is displayed. Scan path is displayed on top of the Fundus image line.
Page 47: Macular Cross Analysis Screen - Comparison
HUVITZ Integrated Image Server, HIIS-1 Thickness graph is displayed. Thickness graphs of the both eyes are compared and displayed. Macular Cross Analysis Screen – Comparison Measurement data that serves as the standard for comparison. Able to select the measurement data that serves as the standard for comparison.
Page 48: Macular Radial Analysis Screen - Ou
HUVITZ Integrated Image Server, HIIS-1 B Scan image for the blue scan line is displayed. Thickness graph for the yellow scan line is displayed. Thickness graph for the blue scan line is displayed. Macular Radial Analysis Screen – OU Fundus image is displayed. Basically, Color Fundus image, measured on the same day is displayed.
Page 49: Macular Raster Analysis Screen - Summary
HUVITZ Integrated Image Server, HIIS-1 Macular Raster Analysis Screen – Summary Fundus image is displayed. Basically, Color Fundus image, measured on the same day is displayed. But if none, IR Fundus image is displayed. Able to use 1-Point-Magic function. Thickness Map for the selected Thickness is displayed. Thickness chart, Average information is displayed.
Page 50: Macular Raster Analysis Screen - Ou
HUVITZ Integrated Image Server, HIIS-1 Macular Raster Analysis Screen – OU Fundus image is displayed. Basically, Color Fundus image, measured on the same day is displayed. But if none, IR Fundus image is displayed. B Scan image for the yellow scan line is displayed.
Page 51: Disc 3D Analysis Screen - Summary
HUVITZ Integrated Image Server, HIIS-1 Disc 3D Analysis Screen – Summary Fundus image is displayed. Basically, Color Fundus image, measured on the same day is displayed. But if none, IR Fundus image is displayed. List up the list by clicking on the button when there is Color Fundus image that can be displayed.
Page 52: Disc 3D Analysis Screen - Ou
HUVITZ Integrated Image Server, HIIS-1 Disc 3D Analysis Screen – OU Displays diameter of 3.45mm ring’s Thickness Profile stacked with Normative data along with the two eyes. Difference value of ① is displayed as candle chart. Measurement information figure for the Disc domain for both eyes is displayed together.
Page 53: Disc 3D Analysis Screen - Comparison
HUVITZ Integrated Image Server, HIIS-1 Disc 3D Analysis Screen – Comparison Measurement data that serves as the standard for comparison. Able to select the measurement data that serves as the standard for comparison Disc 3D Analysis Screen – 3D Macular 3D Analysis Screen –...
Page 54: Disc Radial Analysis Screen - Summary
HUVITZ Integrated Image Server, HIIS-1 Disc Radial Analysis Screen – Summary Fundus image is displayed. Basically, Color Fundus image, measured on the same day is displayed. But if none, IR Fundus image is displayed. Able to use 1-Point-Magic function. Thickness Map for the selected Thickness is displayed. RNFL-4 Chart and RNFL-12 Chart are displayed.
Page 55: Disc Radial Analysis Screen - Comparison
HUVITZ Integrated Image Server, HIIS-1 Disc Radial Analysis Screen – Comparison Able to carry out comparative analysis by selecting the list on the measurements of the same area. Disc Raster Analysis Screen – Summary Fundus image is displayed. Basically, Color Fundus image, measured on the same day is displayed.
Page 56: Disc Raster Analysis Screen - Ou
HUVITZ Integrated Image Server, HIIS-1 Disc Raster Analysis Screen – OU Fundus image is displayed. Basically, Color Fundus image, measured on the same day is displayed. But if none, IR Fundus image is displayed. Thickness graph for the yellow scan line is displayed.
Page 57: Disc Circle Analysis Screen - Summary
HUVITZ Integrated Image Server, HIIS-1 Disc Circle Analysis Screen – Summary Fundus image is displayed. Basically, Color Fundus image, measured on the same day is displayed. But if none, IR Fundus image is displayed. B Scan image filmed along the yellow circle is displayed.
Page 58: Disc Circle Analysis Screen - Comparison
HUVITZ Integrated Image Server, HIIS-1 Disc Circle Analysis Screen – Comparison Able to carry out comparative analysis by selecting the list on the measurements of the same area. Anterior Radial Analysis Screen – Summary Fundus image is displayed. Basically, IR Fundus image is displayed. Scan path is displayed on top of the Fundus image.
Page 59: Anterior Radial Analysis Screen - Ou
HUVITZ Integrated Image Server, HIIS-1 image, Color Map Overlay, Monochrome, and Monochrome reverse function. Anterior Radial Analysis Screen – OU Fundus image is displayed. Basically, IR Fundus image is displayed. Thickness graph for the yellow scan line is displayed. Thickness graphs of the both eyes are compared and displayed.
Page 60: Anterior Line Analysis Screen - Summary
HUVITZ Integrated Image Server, HIIS-1 Anterior Line Analysis Screen – Summary Fundus image is displayed. Basically, IR Fundus image is displayed. Scan path is displayed on top of the Fundus image. B Scan image’s Brightness / Contrast can be calibrated Able to display by measuring the angle and length within the B Scan, Color Map Overlay, Monochrome, and by applying Monochrome reverse function.
Page 61: Anterior Line Analysis Screen - Comparison
HUVITZ Integrated Image Server, HIIS-1 Anterior Line Analysis Screen – Comparison Able to carry out comparative analysis by selecting the list for the measurement of the same part. Anterior Line Analysis Screen – Function is the same as that of the Anterior Wide Analysis Screen –...
Page 62: Anterior Wide Analysis Screen - Ou
HUVITZ Integrated Image Server, HIIS-1 Anterior Wide Analysis Screen – OU Fundus image is displayed. Basically, IR Fundus image is displayed. Bscan for the both eyes are displayed. Anterior Wide Analysis Screen – Comparison Able to carry out comparative analysis by selecting the list for the measurement of the same part.
Page 63: Angiography Analysis Screen - Summary
HUVITZ Integrated Image Server, HIIS-1 Angiography Analysis Screen - Summary (1) - Single: display angio information about only single eye. - OU: display angio information about both of eyes. - Progression: It is easy to check the progress by comparing the eyes taken over several days.
Page 64 HUVITZ Integrated Image Server, HIIS-1 Angiography Analysis Screen - Summary (2) Select the angiogram in the combo box. - Superficial: Its signal depth is from ILM(0um) to IPL(0um). - Deep: Its signal depth is from IPL (0um) to OPL(0um). - Outer: Its signal depth is from OPL(0um) to BRM(0um).
Page 65: Angiography Analysis Screen - Ou
HUVITZ Integrated Image Server, HIIS-1 -Area: FAZ area in mm^2. -Perimeter: FAZ perimeter in mm. -Circularity: FAZ circularity ratio. Acquired B-Scan with angiogram. And Tomography can overlap with a red color for a blood probability. Angiography Analysis Screen – OU...
Page 66: Angiography Analysis Screen - Comparison
HUVITZ Integrated Image Server, HIIS-1 FAZ (1) Screen VESSEL Angiography Analysis Screen – Comparison Change the standard of single eye. FAZ (1) Screen VESSEL...
Page 67: Angiography Analysis Screen - Progression
HUVITZ Integrated Image Server, HIIS-1 Angiography Analysis Screen – Progression Select data with which you want to compare in the list box. Select data with which you want to compare in the list box. Select data with which you want to compare in the list box.
Page 68: Color Fundus Analysis Screen - Summary
HUVITZ Integrated Image Server, HIIS-1 Color Fundus Analysis Screen – Summary (1) Displays on the Fundus image by removing RED color (Red-Free button). Displays on the Fundus image by applying Red-Free and Emboss filter (Emboss button). Download a currently displayed Fundus as jpg Fundus image’s reference point is displayed.
Page 69: Color Fundus Analysis Screen - Ou
HUVITZ Integrated Image Server, HIIS-1 Measures the area mass at the inside of the Fundus. Displays the distance from mouse click to release by measuring the length. Able to calibrate move and length after measurement is completed, by clicking on the measurement point. When segment is clicked on, point is added, and able to modify into polygon (unit: mm2).
Page 70: Color Fundus Analysis Screen - Stereo
HUVITZ Integrated Image Server, HIIS-1 Color Fundus Analysis Screen – Stereo Able to carry out comparative analysis by selecting the list on the same measurement parts. Color Fundus Analysis Screen – Panorama Selects the fundus image that is the target for moving. Selected image is displayed on No.
Page 71 HUVITZ Integrated Image Server, HIIS-1 Press on the stitch reset button to merge again after modifying the position.
Page 72: Biometry Analysis Screen - Summary
HUVITZ Integrated Image Server, HIIS-1 Biometry Analysis screen – Summary Biometry OCT module is available as an upgrade to the HOCT system. Screen setting - Single: display Biometry information about only single eye. - OU: display Biometry information about both of eyes.
Page 73: Biometry Analysis Screen - Ou
HUVITZ Integrated Image Server, HIIS-1 Biometry Analysis Screen - OU Axial Length Results (OD) : Display the measurement results of the Axial Length. (OD) (AL) Lens Thickness Results (OD) : Display the measurement results of the Length Thickness. (OD) (ACD, LT, CCT)
Page 74: Topography Analysis Screen - Summary
HUVITZ Integrated Image Server, HIIS-1 Topography Analysis Screen - Summary Information : Display basic information for exam. Basic/Detail Display : Choose one between Basic Topography map and Detail Topography map Topography map : Display Topography map. Cornea View : Display Cornea Image.
Page 75: Topography Analysis Screen - Detailed
HUVITZ Integrated Image Server, HIIS-1 Topography Analysis Screen - Detailed Basic/Detail Display : Choose one between Basic Topography map and Detail Topography map. Topography map : Display Topography map. Summary Table : Display Summary data table for analysis. Change unit : Change the unit of curvature data.
Page 76: Topography Analysis Screen - Ou
HUVITZ Integrated Image Server, HIIS-1 Topography Analysis Screen - OU Data list box: Select data to compare in the list box. Topography Map (OD) : Display Topography map. (OD) Topography Map (OU) : Display Topography map. (OU) Summary list box : Select summary table to compare in the list box.
Page 77: Topography Analysis Screen - Comparison
HUVITZ Integrated Image Server, HIIS-1 Topography Analysis Screen - Comparison Information : Display basic information for exam. Data list box : Select data to compare in the list box. Topography map : Display topography map of the selected exam. Difference map : Display the difference in topography map between the selected and the compared exam.
Page 78: Topography Analysis Screen - Progression
HUVITZ Integrated Image Server, HIIS-1 Topography Analysis Screen - Progression Information : Display basic information for exam. Topography map : Display topography map of the selected exam. Topography map (1) : Display topography map of the compared exam. Topography map (2) : Display topography map of the compared exam.
Page 79 HUVITZ Integrated Image Server, HIIS-1 Topography map Axial map  This map is useful for understanding the overall curvature distribution of the cornea.  Calculate the vertical distance from the corneal surface to the central optical axis as the radius of curvature.
Page 80 HUVITZ Integrated Image Server, HIIS-1  Kerato map and Axial map display curvature of the front and use the Refractive index 1.3375 and 1.3376, respectively.  Posterior map displays the rear curvature.  Total map uses a ray tracing technique that tracks the movement of light through the cornea.
Page 81 HUVITZ Integrated Image Server, HIIS-1  If the path of incident light is the same as shown above, the Net Power at point Pa is [Reflection at Pa + Reflection at Pp]. VIII. Axial True Net  This map displays the refractive power of the cornea.
Page 82 HUVITZ Integrated Image Server, HIIS-1  Calculate the thickness of the cornea to make a map. XIV. Epithelium  Calculate the thickness of the Epithelium to make a map. Topography Analysis Data I. Central Keratometry - SimK  Displays the simulated Keratometry value of the central area(3mm) ...
Page 83: Refraction Screen Overview
HUVITZ Integrated Image Server, HIIS-1  Display as a numerical value After calculating the difference between each ring and the surrounding ring. Pachymetry  Display thickness information of cornea. Refraction Screen Overview Indicates the dates for the current patient’s examination history.
Page 84: Refraction Analysis Screen
HUVITZ Integrated Image Server, HIIS-1 Refraction Analysis Screen It creates the latest measurement data for the selected patient. Click the list button to import patient’s measurement data Confirm the measurement data. Confirm Color, IOL, TFBUT, MEIBO values if REF/KER data exists. The numbers besides Color, IOL, TFBUT, MEIBO displaying on Refractor Image, indicate number of images for each examination.
Page 85: Overview Of Myopic Management Analysis Screen
HUVITZ Integrated Image Server, HIIS-1 Overview of Myopic Management Analysis Screen 1. Display patient information. 2. It shows the Axial Length (AL) data of the right eye (OD) and left eye (OS) by date in a graph. 3. The graph shows the average curvature data of the right eye (OD) and left eye (OS) by date.
Page 86 HUVITZ Integrated Image Server, HIIS-1 2. If you select a patient with Axial Length, Refraction, and Topography measurement data, A button called “Myopia” is created on the upper left. Click the “Myopia” button to enter the myopia management analysis screen.
Page 87 HUVITZ Integrated Image Server, HIIS-1 1. Open the two list combo boxes and select the measurement date of the data you want to check. 2. If you select the measurement date of the data you want to check, it confirms which part of the eye the information corresponds to.
Page 88: After Operation
HUVITZ Integrated Image Server, HIIS-1 After operation HIIS-1 program does not provide an exit button within the program. Click the ‘X’ button in the web browser to close the program. The program will be automatically logged out Trouble Shooting Guide Should the device function improperly, attempt to correct the problem according to the following table before contacting sales distributors.
Page 89 HIIS-1 server are are not networked on the same network No data is transmitted to HIIS-1 server Check the IP of HIIS-1 server is entered correctly on Huvitz’s IP of HIIS-1 server is not correct. equipment. Check that the HIIS-1 server...
Page 90: Import Cannon Fundus Data (Eyescape)
HUVITZ Integrated Image Server, HIIS-1 4 Import Cannon fundus Data (EyeScape) Import Watcher daemon  1. After running a browser (Chrome is recommended) on the PC, connect to HIIS. 2. After entering your ID and password, click the LOGIN button to log in.
Page 91: Huvitz's Equipment Connection Diagram
HUVITZ Integrated Image Server, HIIS-1 5 Huvitz’s equipment connection diagram Huvitz’s equipment connection diagram ...
Page 92: Setting Method For Device Connection
3. On the ADMINISTRATOR screen, click [CONFIGURATION] / [SETUP] and set the value for the equipment that needs to be connected among the "Huvitz Connection Port" items. 4. If the device that needs to be connected is HLM, change NO to YES and click the APPLY button.
Page 93: Hoct-1/1F, Hfc-1 (V1.3.3) Optical Coherence Tomography
HUVITZ Integrated Image Server, HIIS-1 HOCT-1/1F, HFC-1 (v1.3.3) Optical Coherence Tomography  1. Fill in Server IP and Server Port information on [SETUP]-[System]. (Server IP, it means local IP address, where Web-Viewer has installed.) 2. Select patients in the Patients List and clicking 'TRANSFER’ button, send all of the patient...
Page 94 HUVITZ Integrated Image Server, HIIS-1 3. Select data in Data List. And Clicking 'TRANSFER’ button, send the data. 4. When it succeeded to send data, the following message box popped up on the window.
Page 95: His-5000U (V4.04.20) Slitlamp & Imaging System
HUVITZ Integrated Image Server, HIIS-1 HIS-5000U (v4.04.20) Slitlamp & Imaging System  1. Open the Setup window. Fill in WebServer setting and save the setting. (Server IP, it means local IP address, where Web-Viewer has installed.) 2. Select a patient in the Patients List. And using mouse right click, select ‘Send WebViewer’.
Page 96 HUVITZ Integrated Image Server, HIIS-1 3. Select data in the Exam Date List. And using mouse right click, select ‘Send WebViewer’. Then, all of the data (which had taken in same day) has sent. 4. Select data in the Data List and Using mouse right click, select ‘Send WebViewer’.
Page 97: Hrk-9000A Auto Ref / Keratometer
HUVITZ Integrated Image Server, HIIS-1 HRK-9000A Auto Ref / Keratometer  1. WiFi Network Setting for ref/keratometer. Select WIFI on SETUP MODE. And turn on WiFi to use transmission function, Set TRANSFER TYPE to set up data transmission method. Press on the AP SSID entry window to enter SSID. When SSID is not known, press SCAN button...
Page 98 HUVITZ Integrated Image Server, HIIS-1 Press on the AP PASSWORD entry window to enter password. Press VERIFY button on the right to confirm the password. Password verification takes up less than 10 seconds, and the result will be shown on the screen.
Page 99 HUVITZ Integrated Image Server, HIIS-1 If there is a connection failure after automated connection attempt or if there is a connection error during operation, button will appear on the bottom of the main measurement mode screen. Pressing the button will bring up the connection status screen.
Page 100: Hrk-Mate (V1.0.12)
HUVITZ Integrated Image Server, HIIS-1 HRK-Mate (v1.0.12)  1. Open [Transfer Options..] in Setup 2. Fill in Transfer information (IP, Port), check ‘Use Auto Transfer'. And save its setting. (Server IP, it means local IP address, where Web-Viewer has installed.) Then, it transfers the data to web-viewer, as HRK-Mate program receive the data from HRK device.
Page 101: Hdr-9000 (V1.1.2) Digital Refractor
HUVITZ Integrated Image Server, HIIS-1 HDR-9000 (v1.1.2) Digital Refractor  1. Clicking Shift button, select Settings on Home Menu. And turn on Connection on Communication tab. 2. Set 'Send WebViewer’ to 'YES’. And Fill in WebViewer IP Address and Port.
Page 102: Hdr-Mate
HUVITZ Integrated Image Server, HIIS-1 HDR-Mate  1. Fill in [Web Viewer Option] in [Options]-[Data Receiving & Transfer] 2. Select patient data in Received List. 3. Click button to send selected data.
Page 103: Hlm-9000 Auto Lensmeter
HUVITZ Integrated Image Server, HIIS-1 HLM-9000 Auto Lensmeter  1. WiFi Network Setting. Select NETWORK on SETUP MODE. And turn on WiFi to use transmission function, Set TRANSFER TYPE to set up data transmission method. Press on the AP SSID entry window to enter SSID. When SSID is not known, press SCAN button...
Page 104 HUVITZ Integrated Image Server, HIIS-1 Press on the AP PASSWORD entry window to enter password. Press VERIFY button on the right to confirm the password. Password verification takes up less than 10 seconds, and the result will be shown on the screen.
Page 105: Htr-1A Optometry & Intraocular Pressure
HUVITZ Integrated Image Server, HIIS-1 HTR-1A Optometry & intraocular pressure  1. WiFi Network Setting Select the [COMMUNICATION] tab in Setup mode. Set the Tcp Out item to ON. 2. WiFi Network Setting If using WiFi, set "Wifi/Ethernet" to WIFI.
Page 106 HUVITZ Integrated Image Server, HIIS-1 3. Go to the 3-tab page. Press on the AP SSID entry window to enter SSID. When SSID is not known, press SCAN button on the right to select from available AP SSID. Press on the AP PASSWORD entry window to enter password. Press VERIFY button on the right to confirm the password.
Page 107 HUVITZ Integrated Image Server, HIIS-1 4. Web-Viewer Connection Setting Select NETWORK page 1 on User SETUP Mode. And enter information for Server IP (where Web-Server is located). : Select if transfer the data to Web-Viewer. : Enter a name for the Web-Viewer.
Page 108: Hnt-1/1P Non-Contact Tonometer
HUVITZ Integrated Image Server, HIIS-1 HNT-1/1P Non-contact Tonometer  1. Serial COM Port Setting Select the [Print] on the Setup page. - COM Out : Setup of transmission on/off(Communication to other machines) HNT equipment cannot be directly connected to HIIS.
Page 109: Htg-1 Standalone Biometry & Topography / Only Topography
HUVITZ Integrated Image Server, HIIS-1 HBM-1 & HTG-1  Standalone Biometry & Topography / Only Topograph 1. Fill in Server IP and Server Port information on [SETUP]-[Connectivity]. (Server IP, it means local IP address, where Web-Viewer has installed.) 2. Select data in Data List. And clicking 'TRANSFER’ button, send the data.
Page 110: Dicom Setting
HUVITZ Integrated Image Server, HIIS-1 7 DICOM Setting 1. After running a browser (Chrome is recommended) on the PC, connect to HIIS. 2. After entering your ID and password, click the LOGIN button to log in. 3. On the ADMINISTRATOR screen, click [CONFIGURATION] / [SETUP] to set the corresponding information.
Page 111: Specifications And Accessories
HUVITZ Integrated Image Server, HIIS-1 8 Specifications and Accessories Standard Accessories User manual - User manual is provided as an electronic file (PDF) through manufacturer’s web system. Optional Accessories Quick Guide - Key is provided as USB. - Quick Guide is provided with USB.
Page 112: Information Needed For Service
Client name: Client address: Client contact number: Model number: Serial number: HIIs-1 version: Contact the Huvitz’s service department directly by referring to the address and telephone numbers below if you cannot contact the distributor where you purchased the product.
Page 113 HUVITZ Integrated Image Server, HIIS-1 ■ How to Contact Huvitz Co., Ltd. Huvitz Co., Ltd. 38, Burim-ro 170beon-gil, Dongan-gu, Anyang-si, Gyeonggi-do, 14055, Republic of Korea Tel: +82-31-428-9100 Fax: +82-31-477-9022(F/A) E-mail : svc@huvitz.com website : www.huvitz.com ■ EU Representative Medical Device Safety Service GmbH (MDSS) Schiffgraben 41, 30175 Hannover, Germany ■...
