- Page 1 Wireless Door Detector User’s Manual V1.1.1...
-
Page 2: Foreword
User’s Manual Foreword General This manual introduces the installation, functions and operations of the Wireless Door Detector (hereinafter referred to as the "door detector"). Read carefully before using the device, and keep the manual safe for future reference. Model DHI-ARD323-W2(S); DHI-ARD323-W2(868S) Safety Instructions The following signal words might appear in the manual. - Page 3 User’s Manual About the Manual The manual is for reference only. Slight differences might be found between the manual and the ● product. We are not liable for losses incurred due to operating the product in ways that are not in ●...
-
Page 4: Important Safeguards And Warnings
User’s Manual Important Safeguards and Warnings This section introduces content covering the proper handling of the door detector, hazard protection, and protection of property damage. Read carefully before using the door detector, and comply with the guidelines when using it. Operation Requirements Make sure that the power supply of the door detector works properly before use. -
Page 5: Table Of Contents
User’s Manual Table of Contents Foreword................................I Important Safeguards and Warnings......................III 1 Introduction..............................1 1.1 Overview......................................1 1.2 Technical Specifications................................1 1.3 Detection Performance................................3 2 Checklist................................4 3 Design................................5 3.1 Appearance....................................5 3.2 Dimensions....................................6 4 Adding the Door Detector to the Hub......................7 5 Installation............................... -
Page 6: Introduction
User’s Manual 1 Introduction 1.1 Overview Door detector is a wireless detector consisting of a sensor and a magnet that can send a signal to the hub and trigger an alarm when an armed door is opened. It can be set up via the DMSS app for iOS and Android phones. - Page 7 User’s Manual Type Parameter Description Sensor Reed switch Test Mode Technical Parameter Scenario Non-metal doors Movement Distance < 40 mm (1.57") Power Supply CR123A battery Battery Voltage 3 VDC Min. Voltage 1.8 VDC Battery Low Threshold 2.7 VDC Battery Restore 2.75 VDC Threshold Typical Voltage...
-
Page 8: Detection Performance
User’s Manual Type Parameter Description DHI-ARD323-W2 (868S): EN 50131-1: 2006 + A2:2017 + A3:2020 ● EN50131-2-6:2008 ● DHI-ARD323-W2 (S): EN50131-6:2017 ● Certifications ● EN50131-5-3:2017 ● ● Security Grade 2 ● Environmental Class II ● ● 1.3 Detection Performance An alarm will be triggered when the gap between the door detector and the magnetic stick is wider than the distances shown in the table below. -
Page 9: Checklist
User’s Manual 2 Checklist Figure 2-1 Checklist Table 2-1 Checklist Item Name Quantity Item Name Quantity Door detector Quick start guide Legal and regulatory Double-sided tape 2 information Cable Screw package... -
Page 10: Design
User’s Manual 3 Design 3.1 Appearance Figure 3-1 Appearance Table 3-1 1 Name Description Flashes green quickly: Pairing mode. ● Indicator Solid green: Alarm event is triggered. ● Peripheral port Connect the peripheral with the alarm cable. On/Off switch Turn on or turn off the door detector. When the tamper button is released, the tamper Tamper switch alarm will be triggered. -
Page 11: Dimensions
User’s Manual 3.2 Dimensions Figure 3-2 Dimensions (mm [inch]) -
Page 12: Adding The Door Detector To The Hub
User’s Manual 4 Adding the Door Detector to the Hub Background Information Before you connect door detector to the hub, install the DMSS app to your phone. This manual uses iOS as an example. Make sure that the version of the DMSS app is 1.96 or later, and the hub is V1.001.0000000.5.R. ●... -
Page 13: Installation
User’s Manual 5 Installation 5.1 Replacing the battery Background Information The battery has been installed when leaving the factory, and the door detector can be used directly. If the battery is dead, you need to replace the battery. Procedure Step 1 Open the back cover of the door detector. -
Page 14: Installing The Door Detector
User’s Manual 5.2 Installing the Door Detector Prerequisites Before installation, add the door detector to the hub and check the signal strength of the installation location. We recommend installing the door detector in a place with a signal strength of at least 2 bars. - Page 15 User’s Manual Figure 5-6 Drill holes Step 4 Close the door detector. Figure 5-7 Close the door detector...
-
Page 16: Configuration
User’s Manual 6 Configuration You can view and edit general information of the door detector. 6.1 Viewing Status On the hub screen, select a door detector from the accessory list, and then you can view the status of the door detector. Table 6-1 Status Parameter Value... -
Page 17: Configuring The Door Detector
User’s Manual Parameter Value Exit Delay Time Open or close status of the door. Door Status : Open. ● : Closed. ● Active status of the 24 h protection zone. 24 H Protection Zone Status : Open. ● : Closed. ●... - Page 18 User’s Manual Parameter Description Enable the 24 H Protection Zone function, and then the peripheral located in the 24 h protection zone is always active 24 H Protection Zone whether the security system is configured in the armed mode or not.
- Page 19 User’s Manual Parameter Description Select from high, low, and automatic. ● The higher the transmission power, the farther the signal can ● travel, but the greater the power consumption. Transmit Power If you select Low, and then the door detector will enter reduced ●...
-
Page 20: Appendix 1 Cybersecurity Recommendations
IP video surveillance is not immune to cyber risks, but taking basic steps toward protecting and strengthening networks and networked appliances will make them less susceptible to attacks. Below are some tips and recommendations from Watchguard on how to create a more secured security system. - Page 21 Establish the 802.1x access authentication system to reduce the risk of unauthorized access ● to private networks. Enable IP/MAC address filtering function to limit the range of hosts allowed to access the ● device. More information Please visit Watchguard's official website (www.watchguardsystems.com.au) for security announcements and the latest security recommendations.
- Page 22 You deserve to feel safe, secure & protected Website: www.watchguardsystems.com.au | Email: sales@watchguardsystems.com.au I Tel: 02 4545 2598...
