- Page 1 Installation & Operation Manual SolidSense II Series ® Pressure Transducers Beyond Measure...
-
Page 3: Table Of Contents
Contents Brooks Instrument Section 1 Introduction Introduction ............................5 Intended Use ........................... 6 Notice and Caution Statements ....................... 6 Product Description Code ........................ 6 SolidSense II Pressure Transducer Specifications ................ 10 Section 2 Device Configuration and Wiring General ............................20 Receipt of Equipment ........................ - Page 4 1-4 Dimensional Drawings - SolidSense II Series, CS: Surface Mount, 1.125” C-Seal ....13 1-5 Dimensional Drawings - SolidSense II Series, SF: Face Seal, Swivel, VCR, Female ..13 1-6 Dimensional Drawings - SolidSense II Series, CH: 1.5” C-Seal, High Flow ......
-
Page 5: Section 1 Introduction
Section A - Essential Instructions Back Cover - Limited Warranty and Contacts It is recommended that this manual be read in its entirety before attempting to operate the Brooks SolidSense II Series devices. Figure 1-1 SolidSense II Pressure Transducer Sample Configurations Manual SolidSense II Series Pressure Transducers ®... -
Page 6: Intended Use
II pressure transducers are used to provide years of reliable pressure monitoring in a variety of applications. The SolidSense II Series pressure transducers have one of the smallest footprints in the industry for quick and easy installation in the tightest areas. -
Page 7: Product Description Code For Solidsense Ii - Standard
Brooks Instrument Section 1 Introduction Table 1-2 Product Description Code for SolidSense II - Standard Code Description Code Option Option Description Base Model Code Pressure Transducer Pressure Transducer with integrated display Body Type Dead End Flow Through III. Pressure / Vacuum... -
Page 8: Product Description Code For Solidsense Ii - Atex
Section 1 Introduction Brooks Instrument Table 1-3 Product Description Code for SolidSense II - ATEX Code Description Code Option Option Description Base Model Code Pressure Transducer Body Type Dead End Flow Through III. Pressure / Vacuum Range *Refer to available combinations in... -
Page 9: Range/Unit Available Combinations
Section 1 Introduction Brooks Instrument Table 1-4 Range/Unit Available Combinations III. Pressure/ Vacuum Range Select Range Code PSI (A) 1000 2500 3000 PSI (C) 1000 1500 2500 3000 PSI (G) 1000 2500 3000 BAR (A) BAR (C) BAR (G) IV. -
Page 10: Solidsense Ii Pressure Transducer Specifications
Section 1 Introduction Brooks Instrument SolidSense II Pressure Transducer Specifications Table 1-5 Specifications Performance Non-Display Version Display Version Temperature: Operating: -20ºF to 180ºF (-29ºC to 82ºC) -20°F to 140°F (-29°C to 60°C) Storage: -40ºF to 180ºF (-40ºC to 82ºC) -40°F to 167°F (-40°C to 75°C) Compensated: -4ºF to 140ºF (-20ºC to 60ºC) / 68ºF to 140ºF (20ºC to 60ºC) 0-10 Vdc version... - Page 11 Section 1 Introduction Brooks Instrument Table 1-5 Specifications (Continued) Electrical (Cont.) Display Accuracy: ±-0.25% of Rdg ± 1 Count for psi (excluding transducer output) ± - 0.25% of Rdg ± 5 Count for kPa Character Size: 0.30” height kPa/psi Switch:...
-
Page 12: Dimensional Drawings - Solidsense Ii Series, Sc: Surface Mount, 1.5" C-Seal
Section 1 Introduction Brooks Instrument GFD Configurations Figure 1-2 Dimensional Drawings - SolidSense II Series, SC: Surface Mount, 1.5” C-Seal Figure 1-3 Dimensional Drawings - SolidSense II Series, SM: Face Seal, Swivel, Male Manual SolidSense II Series Pressure Transducers ®... -
Page 13: Dimensional Drawings - Solidsense Ii Series, Cs: Surface Mount, 1.125" C-Seal
Section 1 Introduction Brooks Instrument GFD Configurations Figure 1-4 Dimensional Drawings - SolidSense II Series, CS: Surface Mount, 1.125” C-Seal Figure 1-5 Dimensional Drawings - SolidSense II Series, SF: Face Seal, Swivel, VCR, Female Manual SolidSense II Series Pressure Transducers ®... -
Page 14: Dimensional Drawings - Solidsense Ii Series, Ch: 1.5" C-Seal, High Flow
Section 1 Introduction Brooks Instrument GFD Configurations Figure 1-6 Dimensional Drawings - SolidSense II Series, CH: 1.5” C-Seal, High Flow Figure 1-7 Dimensional Drawings - SolidSense II Series, 4S: Tube Weld Stub, 1/4” OD Manual SolidSense II Series Pressure Transducers ®... -
Page 15: Dimensional Drawings - Solidsense Ii Series, Cd: Surface Mount, Longer Gland, 1.125" C-Seal
Section 1 Introduction Brooks Instrument GFD Configurations Figure 1-8 Dimensional Drawings - SolidSense II Series, CD: Surface Mount, Longer Gland, 1.125” C-Seal Figure 1-9 Dimensional Drawings - SolidSense II Series, NT: 1/4” Male NPT Manual SolidSense II Series Pressure Transducers... -
Page 16: Dimensional Drawings - Solidsense Ii Series, Sm: Face Seal, Swivel Male
Section 1 Introduction Brooks Instrument GFF Configurations Figure 1-10 Dimensional Drawings - SolidSense II Series, SM: Face Seal, Swivel Male Figure 1-11 Dimensional Drawings - SolidSense II Series, VS: Face Seal, Fixed Male/Swivel Female Manual SolidSense II Series Pressure Transducers ®... -
Page 17: Dimensional Drawings - Solidsense Ii Series, 4A: Micro-Fit Tee, 3/8" Branch X 1/4" Run
Section 1 Introduction Brooks Instrument GFF Configurations Figure 1-12 Dimensional Drawings - SolidSense II Series, 4A: Micro-Fit Tee, 3/8” Branch X 1/4” Run Figure 1-13 Dimensional Drawings - SolidSense II Series, VM: Face Seal, Fixed Male Manual SolidSense II Series Pressure Transducers... -
Page 18: Dimensional Drawings - Solidsense Ii Series, Single End (Gid)
Section 1 Introduction Brooks Instrument GID & GIF Integrated Display Configurations Figure 1-14 Dimensional Drawings - SolidSense II Series, Single End (GID) and Flow Through (GIF) Integrated Display Models Manual SolidSense II Series Pressure Transducers ®... -
Page 19: Dimensional Drawings - Solidsense Ii Atex Pressure Transmitter (Option)
Section 1 Introduction Brooks Instrument Figure 1-15 Dimensional Drawings - SolidSense II ATEX Pressure Transmitter (Option) For more details on the SolidSense II ATEX compliant pressure transmitters, visit our website at www.BrooksInstrument.com/Products for the data sheet: DS-PR-SolidSense II ATEX-PT-eng or contact your nearest Brooks Customer Service Center for assistance. -
Page 20: General
If the packing case is damaged, the local carrier should be notified at once regarding his liability. A report should be submitted to the nearest Brooks Instrument location listed on the Global Service Network page on our website: BrooksInstrument.com/GlobalSupportCenters... -
Page 21: Transit Precautions
Section 2 Installation Brooks Instrument Transit Precautions To safeguard against damage during transit, transport the device to the installation site in the same container used for transportation from the factory, if circumstances permit. Removal from Storage Upon removal of the device from storage, a visual inspection should be conducted to verify its “as-received”... -
Page 22: Electrical Connections
Section 2 Installation Brooks Instrument 3. Prepare the SolidSense II pressure transducer for use. a. Verify integrity of the seal by appropriate helium leak-testing proce-dures. b. Turn the gas flow ON then OFF, 10 times to remove any particles generated during installation. -
Page 23: Ma Pinouts
Section 2 Installation Brooks Instrument Figure 2-1 4-20 mA Pinouts Figure 2-2 Voltage Output Pinouts Manual SolidSense II Series Pressure Transducers ®... -
Page 24: Ma Output Device Wiring To Lr056
Section 2 Installation Brooks Instrument The SolidSense II pressure transducer can be wired directly to a 12 or 24 Vdc LR056. The pigtail cable is connected as shown in Figure 2-3. Figure 2-3 4-20 mA Output Device Wiring to LR056... -
Page 25: Non-Incendive Field Wiring 4-20 Ma
Section 2 Installation Brooks Instrument Non-Incendive Field Wiring 4-20 mA Figure 2-5 Non-Incendive Field Wiring for 4-20 mA Manual SolidSense II Series Pressure Transducers ®... -
Page 26: Non-Incendive Field Wiring 0-5 Vdc
Section 2 Installation Brooks Instrument Non-Incendive Field Wiring 0-5 Vdc Figure 2-6 Non-Incendive Field Wiring for 0-5 Vdc Manual SolidSense II Series Pressure Transducers ®... -
Page 27: Zero Adjustment
Section 2 Installation Brooks Instrument Zero Adjustment The SolidSense II pressure transducer is factory calibrated and does not normally need a field adjustment. If a field adjustment becomes necessary, adjust the zero as noted below. Zero Adjustment (SolidSense II Standard Pressure Transducers) On standard SolidSense II pressure transducer models, the zero adjustment screw is located on the body as shown in Figure 2-7. -
Page 28: Zero Adjustment (Atex Solidsense Ii Standard Pressure Transmitters Only)
Section 2 Installation Brooks Instrument Zero Adjustment (ATEX SolidSense II Pressure Transmitters Only) On ATEX SolidSense II pressure transmitters, the zero adjustment screw is located underneath the access cover nut as shown in Figure 2-8(A-B). Unscrew the access cover by turning it in a counterclockwise direction with the electrical connector pointing upward. -
Page 29: Zero Adjustment (Integrated Display Solidsense Ii Pressure Transmitters Only)
Section 2 Installation Brooks Instrument Zero Adjustment (Integrated Display SolidSense II Pressure Transmitters Only) On the Integrated Display SolidSense II transmitters, the zero adjust screw is located on the top face adjacent to the display switch as noted in Figure 2-10. - Page 30 Brooks Instrument can provide seminars and dedicated training to engineers, end users and maintenance persons. Please contact your nearest sales representative for more details. Due to Brooks Instrument's commitment to continuous improvement of our products, all specifications are subject to change without notice. TRADEMARKS Brooks is a trademark of Brooks Instrument, LLC All other trademarks are the property of their respective owners.
