UFSTAT10 Digital Floor Heating Thermostat
The Heat Mat UFSTAT10 Digital Thermostat is designed for floor heating systems
produced in accordance with EN60730-1, EN60730-2-9 and EN50082-1. The
thermostat is equipped with a matrix dot display making it very easy to understand
and operate.
Technical data:
Supply voltage
Maximum load
Operating temperature
Storage temperature
Temperature range, room
sensor
Temperature range, floor
sensor
Control modes
IP class
Terminals
Floor sensor with 3.5m cable
Dimensions
Colour
First time settings:
The first time you switch on the thermostat, the screen shows the product version
number.
This thermostat offers two modes of operation; a manual mode where the
thermostat functions as a simple manual temperature on/off controller, and a fully
programmable automatic mode with a number of events throughout the day that
can have different target temperatures.
When the thermostat is first turned on or after a factory reset the thermostat will
default to manual mode, and the up and down arrows can be used to set the target
floor temperature.
1
100～240VAC
16A
0～50°C
-10～60°C
5～35°C
5～40°C
Floor sensor, room sensor or room sensor
with floor sensor as a limiter
IP21
Max. 2.5 mm
2
NTC, 100K / 25°C
82 mm x 82 mm x 56mm
Polar white (RAL 9010)
50/60Hz
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for HeatMat UFSTAT10
Summary of Contents for HeatMat UFSTAT10
- Page 1 UFSTAT10 Digital Floor Heating Thermostat The Heat Mat UFSTAT10 Digital Thermostat is designed for floor heating systems produced in accordance with EN60730-1, EN60730-2-9 and EN50082-1. The thermostat is equipped with a matrix dot display making it very easy to understand and operate.
- Page 2 If you wish to program the thermostat to operate in auto mode press the menu button and then select Auto. By following the menu prompts you can set the time, day of the week and control mode. • Select the time using the up and down buttons and confirm by selecting OK. •...
- Page 3 Operating table: Auto Main Window Menu start Press Menu “To return to Main Window, go to EXIT and press OK” Menu end Appearance reference: Display interface...
- Page 4 Navigation buttons General operation: When the thermostat is powered up, the version number will be displayed. If you hold the menu button for 3 seconds, the thermostat will turn off, all the settings, including time and date will be saved. To turn the thermostat back on press the menu button again.
- Page 5 To access the Settings menu press the Menu button and then use the right and left arrows to select the menu you wish to access. Event schedule - pre-programmed heating events: You can set the thermostat up with different pre-programmed events to match your requirements.
- Page 6 Program setting: Press the OK button to activate the Program setting. Choose the days you wish to set using the up or down button. Now select the time and temperature for each daily event in the program. Press OK and set the start time for the event concerned. Confirm with OK. Set the temperature for this event and confirm with OK.
- Page 7 These are the icons for events programming: Wake, Leave, Return, Sleep) Factory settings / Pre-set schedule 7 days Wake Leave Return Sleep Time Temp. Time Temp. Time Temp. Time Temp. 4 events 6:30 22°C 7:30 19°C 17:00 22°C 23:00 18°C Monday to Wake Leave...
- Page 8 Time and day: Press OK and set the time in hours and minutes. The day will then be displayed. Set the day and confirm with OK. Calibration: If the actual temperature measured by the thermostat does not correspond to the true temperature you can adjust the thermostat by offsetting the temperature.
- Page 9 Sensor Setting: Set the method you want to use to control your heating system. There are 3 options: Only floor: The thermostat only regulates floor temperature. A floor sensor must be connected. Only room: The thermostat only regulates room temperature – this method should not be used with underfloor heating unless there is an alternative way to limit the floor temperature.
- Page 10 Floor protection Max/Min: only works at Room/limit mode Factory reset: This function allows all the thermostat settings to be reset and revert back to the original manufacturer’s programming. Your personal settings will be erased. Press YES and choose Reset in the menu. Press NO and cancel the factory reset.
- Page 11 Energy monitor: If the load is correctly set the energy monitor can be used to confirm how much energy the underfloor heating system has used on each day of the week or for the last full week. You can also input the load of the system in this menu. Open window: When the Open Window function is activated, a rapid temperature drop in the room (as you would expect if a door or window was left open in cold conditions) will shut...
- Page 12 Heat Mat Underfloor Heating For more information visit: www.heatmat.co.uk Or call us on 01444 247020...
