Installation manual

& user guide

Jet Thruster Single & Combi

www.jetthruster.com

Jet Thrusters:

JT-30 / JT-50 / JT-70 / JT-90

All our products are manufactured according to CE regulations.

We keep the rights to change descriptions, graphs or statements,

D-010-04

which are required for technical development of our Jet Thruster systems.

Table of Contents

Need help?

Do you have a question about the Jet Thruster JT-30 and is the answer not in the manual?

Questions and answers

Summary of Contents for HOLLAND MARINE PARTS Jet Thruster JT-30

Page 1 Manufactured by Holland Marine Parts B.V. Keep this manual onboard! Installation manual & user guide Jet Thruster Single & Combi www.jetthruster.com Jet Thrusters: JT-30 / JT-50 / JT-70 / JT-90 All our products are manufactured according to CE regulations. We keep the rights to change descriptions, graphs or statements, D-010-04 which are required for technical development of our Jet Thruster systems.
Page 2 D-010-04 Holland Marine Parts D-010-06...
Page 3: Electrical Installation
Electrical Installation D-010-04 D-010-06 Holland Marine Parts...
Page 4 - No common ground, check wiring diagram Invert Switches - to invert Port to Starboard Red Light Flashing - Valve is not open in �me, restart system - Check micro switches for water damage - Open valve to clean inside 20Amps D-010-04 Holland Marine Parts D-010-06...
Page 5 E-304-00 (2m) (5m) (10m) (10m) 12V service battery Series parallel switch Always connect all battery negatives to a common ground. Pump unit (use E-308-00 to extend cable) Directional 3-way valve(s) (use E-309-00 to extend cable) D-010-04 Holland Marine Parts D-010-06...
Page 6 E-304-00 (2m) (5m) (10m) (10m) 12V service battery Always connect all Series parallel switch battery negatives to a common ground. Pump unit (use E-308-00 to extend cable) Directional 3-way valve(s) (use E-309-00 to extend cable) D-010-04 Holland Marine Parts D-010-06...
Page 7 CONTROLLER UNIT: BOW AND STERN DOUBLE SYSTEM & REMOTE SET UP D-010-04 Holland Marine Parts D-010-06...
Page 8 This controller is designed to be used in pleasure crafts, to maneuver yachts sideways. This controller comes with a two year factory guarantee. Content: 1. Introduction and Contents. 2. Installation and explanation of the Controller. 3. Program functions and settings, Led flashing codes. 4. Declaration of Conformity D-010-04 Holland Marine Parts D-010-06...
Page 9 - The status led provides the same information as on the joystickpanel. (see next page Flashing codes) - The Dipswitsches allow you to set up the controller for your application. (see next page ) - The Invert switches allow you to invert the valve or thruster operation. D-010-04 Holland Marine Parts D-010-06...
Page 10 Using these switches You can invert the valve- or thrusteroperation, this simpliﬁes installation. the left switch is for the stern and the right for the bow. Warning: A wrong setting can cause damage or Injury!! Keep your face and hands on a safe distance from thrusteropenings !! D-010-04 Holland Marine Parts D-010-06...
Page 11 Electrical Installation: Jet Thruster Single and Combi Holland Marine Parts recomments Optima Batteries Optima battery YT S 5.5L JT-30 12V 1 x YT S 5.5L 75Ah Visit our website JT-50 24V 2 x YT S 5.5L 75Ah www.jetthruster.com JT-70 24V 4 x YT S 5.5L 75Ah...
Page 12 If the controller indicated no Common ground there will be a Green light on and Red Flashing fast. Please follow this schedule to resolve this problem. Battery for Jet Thruster Battery for Controller Common Grounding point D-010-04 Holland Marine Parts D-010-06...
Page 13 Nozzle Ø 50mm Nozzle Ø 50mm Pressure hose diameter Pressure hose diameter 3” / 76 mm 3” / 76 mm Weight pump Weight pump 49 kg/95 LBS 61 kg/130 LBS Installation manual with product specifications at: www.hollandmarineparts.nl/download D-010-04 Holland Marine Parts D-010-06...
Page 14 Please note: More electricity will be required as a result of the installation of the Jet Thruster. That is why in some cases it is recommended for the alternator to be converted to high yield or to place a separate alternator. D-010-04 Holland Marine Parts D-010-06...
Page 15 JT-30 (12V) charged with 12V charger Contactor Optima battery Fuse Main switch Controller Charger 12V Service batteries Diode bridge Alternator Start battery D-010-04 Holland Marine Parts D-010-06...
Page 16 JT-50 (24V) charged with 12V charger Series parallel switch Strips pre mounted Contactor Optima batteries Fuse Main switch Controller Charger 12V Service batteries Diode bridge Alternator Start battery D-010-04 Holland Marine Parts D-010-06...
Page 17 JT-50 (24V) charged with 12V Step up Charger Optima batteries Contactor Mac Plus - Step up charger Fuse Main switch Controller Charger 12V Service batteries Diode bridge Alternator Start battery D-010-04 Holland Marine Parts D-010-06...
Page 18 JT-70/JT-90 (24V) charged with 12V charger Series parallel switch Strips pre mounted Optima batteries Contactor Controller Main switch Fuse Charger 12V Service batteries Diode bridge Alternator Start battery D-010-04 Holland Marine Parts D-010-06...
Page 19 JT-70/JT-90 (24V) charged with 12V Step up Optima batteries Mac Plus - Step up charger Contactor Controller Fuse Main switch Charger 12V Service batteries Diode bridge Alternator Start battery D-010-04 Holland Marine Parts D-010-06...
Page 20 JT-70/JT-90 (24V) in a 24V board network Optima batteries Controller Contactor 24V -> 12V converter Fuse Main switch Charger 24V Service batteries Diode bridge Alternator Start battery D-010-04 Holland Marine Parts D-010-06...
Page 21 JT-70/JT-90 (48V) in a 24V board network Series parallel switch Strips pre mounted Controller Optima batteries Contactor 24V -> 12V converter Fuse Main switch Charger 24V Service batteries Diode bridge Alternator Start battery D-010-04 Holland Marine Parts D-010-06...
Page 22 JT-70/JT-90 (48V) in a 12V board network Series parallel switch Strips pre mounted Optima batteries Mac Plus - Step up Charger 12V -> 24V Contactor Controller Fuse Main switch Charger 12V Service batteries Diode bridge Alternator Start battery D-010-04 Holland Marine Parts D-010-06...
Page 23 JT-50/JT-70/JT-90 (48V) in combination with electric propulsion Controller Contactor 48V -> 12V 20A converter Main switch Fuse Main propulsion Charger 48V Fuse D-010-04 Holland Marine Parts D-010-06...
Page 24 E-135-00 (1m) This cable is on one side pre mounted on the contactor. You only need to connect the free side to the series parallel switch. It does not matter which way you connect it! D-010-04 Holland Marine Parts D-010-06...
Page 25 E. Apply the supplied flexible hose from the Air valve to outside of the vessel. In case of a technical failure, water that comes from the pump unit when the Jet Thruster system is engaged, will be pumped outside the vessel. Follow diagram complete the electrical installation. D-010-04 Holland Marine Parts D-010-06...
Page 26 Also possible on pump casting Flexible hose, Ø 8mm Pump unit Water to 3-way valve/nozzle 1/8 BSP thread in the pre-manufactured dimple. In addition, place the air bleed valve and connect to the electrical valve hose. I-806-00 D-010-04 Holland Marine Parts D-010-06...
Page 27 See appendices for additional information. Position of electrical valve must be above water line. Flexible hose, Ø 8mm Water to 3-way valve/nozzle Pump unit Remove plug from pump outlet to connect flexible hose. D-010-04 Holland Marine Parts D-010-06...
Page 28 Double fuse holder Pump outlet Hose clamps 48-60mm 77-94mm Torque max. 9Nm I-114-00, 40 Nm I-331-00, 45 Nm 60-76mm Note: Over tightening will press out the seal and damage the pump head! I-116-00, 40 Nm D-010-04 Holland Marine Parts D-010-06...
Page 29: Warranty Provisions
In case of defects in material and/or defects caused by inadequate work done, as covered under warranty by Holland Marine Parts, the relevant part or the whole device will be either repaired or replaced at the discretion Holland Marine Parts, free of charge.
Page 30: Before You Start
Installation & maintenance Before you start: watch our installation video’s! www.youtube.com/user/hollandmarineparts D-010-04 Holland Marine Parts...
Page 31 Important instructions must be taken into account. Further on you will ﬁnd installation recommendations. Contact your Distributor/dealer in case you have additional questions, or contact Holland Marine Parts. Always make sure to fully read the installation manual which is provided with each Jet Thruster system X-Yacht 442 - Installed with composite nozzle’s then put in the antifouling...
Page 32 The topside of the nozzle tube must be 7-10cm below the waterline, not deeper or higher. In case of a narrow bow, you can cross the hoses. Each nozzle has a 2” Ball valve. 4: Electrical installation See dedicated chapter in this manual. D-010-04 Holland Marine Parts D-010-06...
Page 33 Pressure hoses from the pump to the valve and nozzles can be installed above the water line. If it is cold: heat the hoses with a paint-remover (not too hot!) Warm hoses are much more flexible and easier to install. D-010-04 Holland Marine Parts D-010-06...
Page 34 • Water inlet (3” or 4” depending on your system) • Nut 3” or 4” • Elbow 90-degree • Ball valve • Hose connector • Hose (1 meter) or optional bellow Composite water inlet filter D-010-04 Holland Marine Parts D-010-06...
Page 35 • Very important: Before the Sikaflex291i will start to cure: Immediately check alignment with pump inlet: Now is the time to make small corrections to the 90 degree elbow if necessary • After 15 minutes, depending on temperature / humidity etc do not move the parts anymore. D-010-04 Holland Marine Parts D-010-06...
Page 36 Do not use a saw, or disc cutters to cut the hoses. Use a sharp utility knife. When it’s cold, it is preferred to heat the rubber compound with a heat gun on the inside of the hose for 15 minutes. D-010-04 Holland Marine Parts D-010-06...
Page 37: Hose Clamps
6 different nozzle angles available. With these 6 angles, it’s possible for almost any boat to install the system correctly. You can use the folding tool, present in our catalog to determine the right angle, or look at our installation video’s at Youtube. D-010-04 Holland Marine Parts D-010-06...
Page 38 Due to this shifted nozzle position, there is more space to connect the parts. You can cross the hoses. Make sure you thoroughly clean all threaded connections with acetone. This is very important. D-010-04 Holland Marine Parts D-010-06...
Page 39 The nozzle will ﬁx to the outside shell. A larger hole must be cut to the inside shell to make place for the PVC spacer. Possible you have to cut away foam or other material present between the shells. D-010-04 Holland Marine Parts D-010-06...
Page 40 Stress inside the hose will be released towards the nozzle assembly. Because the Sikaflex291i has not cured, the parts will set in the perfect position. After the hose cools, and the Sikaflex291i is cured, connec- tions are free of stress. D-010-04 Holland Marine Parts D-010-06...
Page 41: Frequently Asked Questions
Frequently asked questions D-010-04 Holland Marine Parts D-010-06...
Page 42 D-010-04 Holland Marine Parts D-010-06...
Page 43 D-010-04 Holland Marine Parts D-010-06...
Page 44 Read prior to operating the Jet thruster system Your boat is equipped with a Holland Marine Parts electric Jet Thruster. For the safe and correct operation of this system Holland Marine Parts recommends every user to carefully study this operating guide. Familiarise yourself with the system by trying it out in various weather conditions.
Page 45 In this situation the Electrical air valve from Holland Marine Parts should be installed to release the air from the pump head.
Page 46 Repeat this procedure for every ball valve. Step 7: Remove the compressed-air nipple. 3” / 76 mm Step 8: Replace the blind plug or airvalve. In addition you can drain the pumphouse, therefore remove draining plug for draining the pumphouse. D-010-04 Holland Marine Parts D-010-06...
Page 47: Troubleshooting
- Not enough power - Series-parallel does not activate, - Check connections of series switch (JT-50-70-90) - Not enough power - system runs at 12V - Measure if there is 24v on series switch (JT-50-70-90) D-010-04 Holland Marine Parts D-010-06...
Page 48 In this situation the Electrical air valve from Holland Marine Parts should be installed to release the air from the pump head.
Page 49 D-010-04 Holland Marine Parts D-010-06...
Page 50 Exploded View Jet Thruster JT-30 Single Compact I-331-00 Pump unit JT30 I-309-00 I-307-00 V-500-00 I-336-00 I-114-00 I-310-00 I-312-00 I-308-00 I-115-00 I-321-00 I-113-00 I-302-00 I-316-00 Pump unit JT-30 JT-30-50 2-Way pump outlet P-507-52 3-Way valve V-500-00 Hose clamp 77-94 mm I-331-00...
Page 51 Option 2b: P-507-52 V-100-58 I-113-58 I-114-00 Pumpunit JT50 I-311-00 I-307-00 I-310-00 I-309-00 I-316-00 I-115-00 I-302-00 I-321-00 I-336-00 Exploded View Jet Thruster 50 Single Compact Vertical I-321-00 P-115-58 V-100-58 I-321-00 I-113-58 I-115-00 I-302-00 I-114-00 I-336-00 I-114-00 I-316-00 D-010-04 Holland Marine Parts D-010-06...
Page 52 Elbow 45 2” BSP M/F I-316-00 Hose connector 110 mm I-275-01 Hose connector 3”/76 mm / 2” BSP I-215-00 Hose clamp 77-94 mm I-331-00 Ball valve 2” BSP I-321-00 Hose clamp 115-145 mm I-270-02 Nozzles I-336-00 D-010-04 Holland Marine Parts D-010-06...
Page 53 Pump unit JT-50 JT-90 24V V-200-50 I-336-00 I-316-00 I-269-GF I-321-00 I-213-00 I-267-00 Option for vertical pump Exploded View Jet Thruster JT-70/90 Vertical Single Pump unit JT-50 JT-90 24V I-317-00 V-200-50 I-213-00 I-213-00 I-321-00 I-316-00 I-331-00 I-336-00 D-010-04 Holland Marine Parts D-010-06...
Page 54 ANGLES IN DEGREES - TOLERANCES ±0.2mm ±0.5º - BREAK ALL EDGES Drawn by : Toofan Pour Part No./Note Scale: Drawn date : 22-03-2017 Customer Scale Checked by Reference D-010-04 Holland Marine Parts D-010-06 Modified by Weight in kg Modified date Material/Size...
Page 55 ANGLES IN DEGREES - TOLERANCES ±0.2mm ±0.5º - BREAK ALL EDGES Drawn by : Toofan Pour Part No./Note Drawn by : Toofan Pour Part No./Note D-010-04 Drawn date : 22-03-2017 Holland Marine Parts D-010-06 Scale: Customer Scale: Drawn date : 22-03-2017 Customer Scale Checked by...
Page 56 3 options for hose connector on pump outlet: Outlet Inlet 226,25 227,5 D-010-04 Holland Marine Parts D-010-06 UNLESS OTHERWISE SPECIFIED: DIMENSIONS ARE IN MILLIMETERS JT-30 Vertical + inlet Ra 3.2 0.03 0.03 ANGLES IN DEGREES - TOLERANCES ±0.2mm ±1º - BREAK ALL EDGES...
Page 57 JTV-30-50 12V Jet Thruster Vertical 30Kgf D-010-04 Holland Marine Parts D-010-06...
Page 58 ANGLES IN DEGREES - TOLERANCES ±0.2mm ±0.5º - BREAK ALL EDGES Drawn by : Toofan Pour Part No./Note Drawn date : 22-03-2017 Scale: Customer D-010-04 Holland Marine Parts D-010-06 Scale Checked by Reference Modified by Weight in kg Modified date Material/Size...
Page 59 ANGLES IN DEGREES - TOLERANCES ±0.2mm ±0.5º - BREAK ALL EDGES Drawn by : Toofan Pour Part No./Note Drawn date : 22-03-2017 Scale: Customer D-010-04 Scale Checked by Reference Holland Marine Parts D-010-06 Modified by Weight in kg : 24.5 kg Modified date Material/Size...
Page 60 227,5 UNLESS OTHERWISE SPECIFIED: DIMENSIONS ARE IN MILLIMETERS JT-50 vertical+ inlet 0.03 0.03 D-010-04 Ra 3.2 Holland Marine Parts D-010-06 ANGLES IN DEGREES - TOLERANCES ±0.2mm ±1º - BREAK ALL EDGES Drawn by : Toofan Pour Part No. Scale Drawn date...
Page 61 ﬁrmly and secure in place. Because the pump head is close to the hull, the Jet Thruster Vertical is an ideal Jet Thruster for boats with shallow draft such as Waterskiing and wakeboarding boats. D-010-04 Holland Marine Parts D-010-06...
Page 62 Before you screw the Note: In case you know the exact hull thickness, modiﬁed inlet into the pump, make sure there are no Holland Marine Parts can provide a dedicated burrs that can damage the thread of the pump head! cut-lo-length Water Inlet.
Page 63 - Maximum tighten the inlet: This will lock the assembly in place Use Wet Wipes to easily remove spilled sealant from parts, tools and hands. - Wet Wipes I-391-00 ensure a spotless installation, and are highly recommended. D-010-04 Holland Marine Parts D-010-06...
Page 64 Connect with flexible hose to inlet on pump unit. 2 options for hose connector Max. hose length 1 m / 3.3 ft on pump outlet: Inlet 487,5mm 573 22,6 115 4,5 188 7,4 148 5,8 175 6,9 D-010-04 Holland Marine Parts D-010-06...
Page 65 Connect with flexible hose to inlet on pump unit. Max. hose length 1 m / 3.3 ft Inlet 2 options for hose connector on pump outlet: 487,5mm 115 4,5 573 22,6 334,8 13,2 188 7,4 148 5,8 175 6,9 D-010-04 Holland Marine Parts D-010-06...
Page 66 JT-70 vertical Ra 3.2 0.03 0.03 ANGLES IN DEGREES - TOLERANCES ±0.2mm ±1º - BREAK ALL EDGES Drawn by : Toofan Pour Part No. D-010-04 Holland Marine Parts D-010-06 Scale Drawn date Customer 1:7.5 Scale Checked by Reference QC by...
Page 67 JT-90 position 1 0.03 0.03 Ra 3.2 ANGLES IN DEGREES - TOLERANCES ±0.2mm ±1º - BREAK ALL EDGES Drawn by : Toofan Pour Part No. D-010-04 Holland Marine Parts D-010-06 Scale Drawn date : 20-04-2017 Customer 1:7.5 Scale Checked by...
Page 68 89,90 UNLESS OTHERWISE SPECIFIED: DIMENSIONS ARE IN MILLIMETERS JT-90 position 2 0.03 0.03 Ra 3.2 D-010-04 Holland Marine Parts D-010-06 ANGLES IN DEGREES - TOLERANCES ±0.2mm ±1º - BREAK ALL EDGES Drawn by : Toofan Pour Part No. Scale Drawn date...
Page 69 UNLESS OTHERWISE SPECIFIED: DIMENSIONS ARE IN MILLIMETERS JT-90 vertical 1 Ra 3.2 0.03 0.03 ANGLES IN DEGREES - TOLERANCES ±0.2mm ±1º - BREAK ALL EDGES D-010-04 Holland Marine Parts D-010-06 Drawn by : Toofan Pour Part No. Scale Drawn date...
Page 70 F-210-00 Water inlet I-616-00 Hexagon socket countersunk head M10x50 F-222-00 Seal Pump outlet P-260-00 Pump outlet straight 2’5” threaded P-256-00 Hexagon Cylinder bolt M8x35 F-208-00 10 Ball valve 25” I-309-00 11 Pump Bracket JT90 P-216-00 D-010-04 Holland Marine Parts D-010-06...
Page 71 Warning: F-222-00 bolt provides sufficient thread for hull thickness of 5-22mm. In case you have a different hull thickness, a different bolt length must be used: Consult Holland Marine parts to avoid permanent damage to the pump and your boat. D-010-04 Holland Marine Parts D-010-06...
Page 72 Technical Specifications 3-way valve JT-30 Composite (52mm) 207mm (8,15”) 114mm (4,49”) 160mm (6,29”) 241mm (9,49”) 9mm (0,35”) 55mm (2,16”) D-010-04 Holland Marine Parts D-010-06...
Page 73 Technical Specifications 3-way valve JT-50 (58mm) 207mm (8,15”) 114mm (4,49”) 160mm (6,29”) 241mm (9,49”) 9mm (0,35”) 55mm (2,16”) D-010-04 Holland Marine Parts D-010-06...
Page 74 Technical Specifications 3-way valve JT-70 / JT-90 275mm (10,83”) 227mm (8,94”) 144mm (5,67”) 188mm (7,4”) 9mm (0,35”) 70mm (2,75”) D-010-04 Holland Marine Parts D-010-06...
Page 75 The included hose clamps are robust and of high quality. Holland Marine Parts recommends using hose clamps which are provided with the installation kit. The installation of diﬀerent hose clamps than the ones included with the system is at your own risk.
Page 76 Electrical air valve that will help to rapidly prime the pump. In addition to select the optimum position of the pump unit Holland Marine Parts advises to place suitable battery’s directly next to the pump unit in order to keep the battery cabling as short as possible! The jet thruster uses a lot of electrical energy in a short period of time.
Page 77 For lateral placement attach a straight hose connector + rubber seal to the pump head. Pump head position II P-115-58 2” / 58 mm P-115-52 P-242-00 JT30/JT50 JT70/JT90 2” / 52 mm 3” / 76 mm D-010-04 Holland Marine Parts D-010-06...
Page 78 However, in case of grounding or suc- tion of a lot of amount of sand and dirt. The 3-way valve can loose function. Open the bolts and cleaned the system out. V-100-50 / V-200-50 D-010-04 Holland Marine Parts D-010-06...
Page 79 - nozzle 35 nozzle 45 - nozzle 45 nozzle 55 nozzle 0 nozzle 25 nozzle 35 - nozzle 35 nozzle 45 - nozzle 45 nozzle 55 nozzle 65 transom 90 nozzle aluminium nozzle SS316 nozzle steel D-010-04 Holland Marine Parts D-010-06...
Page 80 In case of a blund bow, concider an increased nozzle angle. Choose the correct nozzle angle 0 , 25 , 35 , 45 , 55 , 65 Nozzle can be rotated to achieve optimum position. 90 mm forward in bow D-010-04 Holland Marine Parts D-010-06...
Page 81 I-361-00 1 x 2” BSP 45 elbow to each nozzle. 2” BSP, m/f, SS316 1. Crossed nozzle position 2. Horizontal shifted nozzle position 3. Vertical shifted and crossed nozzle position D-010-04 Holland Marine Parts D-010-06...
Page 82 3. Placing the thru-hull nozzle 3.1 Pass thru-hull to the boot hull 3.2 Apply PU-sealant around the cut out. use enough PU-sealant. The excessive amount you can clean with the wet wipes. (Optional I-390-00) D-010-04 Holland Marine Parts...
Page 83 This amount of thread is needed for the ball valve or 45 degree elbow. JT-70 & JT-90 assambly Final assambly of a JT-70 & JT-90 Jet Thruster. Nozzle with guide rings & spacers, composite 2’’ ball valve and hose connector. D-010-04 Holland Marine Parts...
Page 84 6: Fit in the nozzle and check if nozzle is placed horizontal and in 90˚ angle to the heart line of the vessel e.g. by inserting the nozzle from the inside out to determine if hole is drilled correct. D-010-04 Holland Marine Parts D-010-06...
Page 85 11: Repeat installation 12: Thoroughly secure process like suggested the flange treaded at point 7. water intake by fasten the provided 3” nut. D-010-04 Holland Marine Parts D-010-06...
Page 86 Ask the professional supplier of these products for the right products, surface preparation, film thickness and methods of ap- plication to ensure a water and vapor proof coating of the submerged stainless steel parts. If this coating is not vapor proof, most likely corrosion will occur. D-010-04 Holland Marine Parts D-010-06...
Page 87: Cathodic Protection
D. To water inlet A: CP-003-00 Anode Holder Backside JT70/JT90 B: CP-004-00 Zinc Anode To water inlet C: P-260-00 Seal D: E-114-00 Cable set JT30/JT50 E-115-00 Cable set JT70/JT90 JT70-JT90 pump outlet JT70-JT90 pump inlet D-010-04 Holland Marine Parts D-010-06...
Page 88 - Always avoid contact between stainless steel parts and other metal parts to avoid rust, or other types of corrosion to the stainless steel. - Be vigilant for signs of corrosion and act if noticed to avoid (further) damage or dangerous situations. D-010-04 Holland Marine Parts D-010-06...
Page 89 • Anode must be placed close to bow or stern nozzles. - Bolt M8 / nut / washers • Do not paint the Anode. - Cable assembly Remove the antifauling Drill and cut thread M8 Use Sikaflex to seal the bolt M8 Place washer D-010-04 Holland Marine Parts D-010-06...
Page 90: Zinc Anode
€ 145.- P-155-52 P-155-58 2-Way 90 degrees hose connector € 175.- CP-001-00 CP-001-00 Zinc anode holder JT30-JT50 € 56.- CP-004-00 CP-004-00 Replacement Zinc anode JT30/ JT50 € 5.- CP-005-00 CP-005-00 Seal for Outlet Zinc Anode D-010-04 Holland Marine Parts D-010-06...
Page 91 Water inlet zinc anode JT70/JT90 Cable set to water inlet and flange Cables are included with zinc anode Option 2 € 195.- CP-050-00 Zinc anode water inlet JT-70/JT90 € 85.- CP-051-00 Replacement Zinc anode JT70/ JT90 D-010-04 D-010-06 Holland Marine Parts...
Page 92 Corrodium BV Planetenweg 5 2132 HN Hoofddorp 00 31 85 2733501 Fax 0031 85 2733502 info@corrodium.nl Holland Marine Parts Heijningen Report Inspection and Maintenance Jet Thrusters Materials Selection and Corrosion Document Number 214065 Revision No. Revision Date 17 July 2014...
Page 93 2.3 Galvanic corrosion Nozzles/Valves 2 2.4 Pumpunit2 Maintenance and Inspection 3.1 Nozzles 3 3.2 Valves/Nozzles Threading 3.3 Pump Frequently Asked Questions (faq) 3 Doc. No. 214065 Rev. No. Rev. Date 17 juli 2014 Page 1 of D-010-04 Holland Marine Parts D-010-06...
Page 94: Scope Of Work
Materials Heijningen Scope of Work Holland Marine Parts Jet Thrusters have been made of corrosion resistant alloys. However, under extreme conditions corrosion problems might occur. For this reasons it's important that a regular inspection is done. This report will describe which type of corrosion might occur on which locations. And how to inspect on corrosion.
Page 95: Maintenance And Inspection
A: If the pits are not deep, the can be grinded out smoothly succeeded by polishing the surface. If the pits are deep, the need to be welded and the surface must be grinded again. Doc. No. 214065 Rev. No. Rev. Date 17 juli 2014 Page 3 of D-010-04 Holland Marine Parts D-010-06...
Page 96 A: Only if the stray current runs through the water from one electrode to the other one (the nozzle). An electrical circuit must be drawn in order to explain this. Stray currents causing corrosion are rare. 17 juli 2014 Doc. No. 214065 Rev. No. Rev. Date Page 4 of D-010-04 Holland Marine Parts D-010-06...
Page 97 D-010-04 Holland Marine Parts D-010-06...
Page 98 D-010-04 Holland Marine Parts D-010-06...
Page 99 - Part 1: Emission EN55014-2:1997 Electromagnetic compatibility - Requirements for +A2:2008+A1:2001 household appliances, electric tools and similar apparatus - Part 2: Immunity - Product family standard All components used are conform 2011/65/EU (RoHs Directive) Sneek 02/02/2017 Karyvo VOF. D-010-04 Holland Marine Parts D-010-06...
Page 100 D-010-04 Holland Marine Parts D-010-06...
Page 101 D-010-04 Holland Marine Parts D-010-06...
Page 102 D-010-04 Holland Marine Parts D-010-06...
Page 103 D-010-04 Holland Marine Parts D-010-06...
Page 104 1 pos. 1 100 / 3.94" Serial No: Serial No: Serial No: Serial No: Serial No: Serial No: 356,5 /14'' 196 / 7,7" 144 / 5,7" 356,5 /14'' 196 / 7,7" 144 / 5,7" D-010-04 Holland Marine Parts D-010-06...
Page 105 ......................D-010-04 Holland Marine Parts D-010-06...
Page 106: Project Info
......................D-010-04 Holland Marine Parts D-010-06...
Page 107 If the contracting party is not bound, then the party that concluded the agreement is deemed to be the contracting party. 4. In the present General Terms and Conditions “us” and “we” shall always refer to Holland Marine Parts B.V., whereas contracting party shall refer to our other party.
Page 108 2. Without prejudice to the stipulations of section 1, we shall only be liable for damage if the contracting party proves that the damage is due to gross negligence or intent on the part of the directors of Holland Marine Parts B.V.. We shall not indemnify the contracting party against gross negligence or intent on the part of our personnel or our supporting personnel, neither shall we indemnify the contracting party vis à...
Page 109 ﬁled in writing by registered letter under penalty of nullity of the complaint concerned, within 8 days from completion or delivery of the work or the good concerned or from the day the invoices were sent. Complaints shall not suspend the contracting party’s obligation(s) to pay. D-010-04 Holland Marine Parts D-010-06...
Page 110 XIV Applicable Law Dutch law exclusively, shall apply to all offers made and agreements concluded on the present General Terms and Conditions and the con- sequences thereof. The application of the Vienna Sales Convention shall be excluded. D-010-04 Holland Marine Parts D-010-06...
Page 111 D-010-04 Holland Marine Parts D-010-06...
Page 112 D-010-04 Holland Marine Parts D-010-06...
Page 113 D-010-04 D-010-06 Holland Marine Parts...
Page 114 D-010-04 Holland Marine Parts D-010-06...
Page 115 D-010-04 D-010-06 Holland Marine Parts...
Page 116 D-010-04 Holland Marine Parts D-010-06...
Page 117 D-010-04 D-010-06 Holland Marine Parts...
Page 118 D-010-04 Holland Marine Parts D-010-06...
