  • Page 1 Gaia Bella Installation handbook Manuel d’installation Manual de instalación Manuale di installazione Installationshandbuch www.poolstar.fr...
  • Page 3 Recommendations Read this manual carefully before using your sauna for the first time. We recommend you keep it in a safe place for future reference. • Wood is a living element, to maintain its original appearance, it is important to treat the outside of the wood against moisture. Use a saturator only on the outside of the sauna.
  • Page 4 Safety IMPORTANT: Please read the safety instructions carefully before installing and using your sauna cabin. They are essential for your safety, so please adhere strictly to them. Beware of hyperthermia, heat stroke or heat exhaustion which can be caused or aggravated by noncompliance with the safety instructions.
  • Page 5 Description sauna Technical data Model HL-T160E Cabin Material Canadian hemlock Voltage 230 V - 50 Hz (excluding stove) Dimensions N° Qantité Name Barrel Cradles Ø 5 x 50 Special bottom slat (convex on both sides) Ø 4 x 40 special bottom slat Ø...
  • Page 6: Installation

    Installation Included accessories: Storage side panel Storage top panel Storage bottom panel Wire cover (sauna stove) Interior floor panel entrance step Door handle Control box Rain coat (gray) Asphalt shingle (grey) Water nose Top filling slat (13mm) Top filling slat (16mm) Top filling slat (34mm) Read the assembly instructions carefully before starting.
  • Page 7: Assemble Instructions

    Assemble instructions Assemble steps Step 1: Step 2: Ø 4 x 40 Ø 4 x 40...
  • Page 8 Assemble instructions Step 3: Ø 4 x 40 Middle Step 4: Ø 4 x 40 Ø 4 x 40...
  • Page 9 Assemble instructions Step 5: Ø 4 x 40 Step 6: 1600x38mm, 13/16/34mm...
  • Page 10 Assemble instructions Step 7: Ø 6 x 75 Step 8: Ø 4 x 40 Ø 4 x 40...
  • Page 11 Assemble instructions Step 9: Step 10: Ø 5 x 50 15-3 15-1 Ø 3 x 18 Ø 4 x 40 Ø 4 x 40 Ø 5 x 50...
  • Page 12 Assemble instructions Step 11: Ø 4 x 40 Ø 4 x 40 Ø 5 x 50 Ø 4 x 40 Step 12: Ø 5 x 50 Ø 4 x 40 20-2 Ø 4 x 40...
  • Page 13 Assemble instructions Step 13: Ø 5 x 50 20-1 90mm Step 14: Ø 4 x 40...
  • Page 14 Assemble instructions IMPORTANT: The roof cover is essential for sauna waterproof, adapt it to according to the environment. Step 15: Ø 4 x 40 Step 16: Ø 3 x 16 1000x320=28x 600x320=12x 430x320=10x 170x320=10x...
  • Page 15 Assemble instructions Step 17: Step 18: 1: fix 2: connect Ø 4 x 25...
  • Page 16: Maintenance And Servicing

    Costs linked to the use of subcontract labour provided by a third party cannot be covered by Holl’s. IMPORTANT Do not return the product to the store Contact your local after sales service on www.holls.fr or POOLSTAR 960 Avenue Olivier Perroy, 13790 ROUSSET - FRANCE...
  • Page 17 LED Controler LED control box Remote control Operating temperature -30°C / 60°C -30°C / 60°C Tension CD5V / 12/24V DC 2 piles NO7 - 3V output 3 channels N-MOS drain open output Power consumption 0.5W 0.09mW Output 6A 3 canaux : 18A 6A Dimensions of the box 83 x 79 x 33cm Fonctions :...
