Summary of Contents for HI-ND Dual totem 55
- Page 1 INSTALLATION MANUAL Part number: DT5511-5301 Description: Dual totem 55 MANUFACTURER HI-ND Sweden AB Mekanikervägen 9A, 146 33 Tullinge Email: info@hi-nd.se...
- Page 2 Local installation rules must be obtained. A correct mounting is important and it is not the responsibility of HI-ND Sweden AB. Faulty mounting may result in injury to persons. HI-ND will not be responsible if the product has been mounted incorrectly. Anchor bolts are not included with the product.
- Page 3 ASSEMBLY INSTRUCTIONS NUMBER OF PERSONS REQUIRED: 2 persons Power cable input IMPORTANT Please make sure the floor is straight and The Double Totem shall be clean. Its recommended to also add glue fastened with 4 anchors in between the bottom plate and floor concrete.
- Page 4 1 Remove the partition plate 2 Partition plates removed. Computers can be placed inside the bottom partition 3 Use anchors in all four corners...
- Page 5 4 Unpack and prepare to attach the glass 5 Use the cylindrical rod, included, to hang the glass. Lock the rod with the aluminium stick, included.
- Page 6 6 Gas springs are mounted to the totem. 7 Connect gas springs to the glass...
- Page 7 8 Attach VESA mounts to the back of the screen 9 Attach screen to the totem...
- Page 8 10 Screen attach in the totem 11 Use M5 screw, included, to lock the glass 12 Bottom hatch can now be attached...
- Page 9 13 Lock the bottom hatch with M4 screws, included, on each side of the totem 14 Attach sidecover on each side of the totem 15 Finished...
