TrueFlame Gas Side & Power Burner User Manual

Models: Side Burner: TFSB2-NG; TFSB2-LP

Power Burner: TFPB-NG; TFPB-LP

ATTENTION:

INSTALLER: PLEASE LEAVE THESE INSTRUCTIONS WITH THE CONSUMER.

CONSUMER: PLEASE READ & RETAIN THESE INSTRUCTIONS FOR FUTURE

REFERENCE AND BEFORE INSTALLING OR OPERATING.

Remove

This appliance is designed as an "ATTENDED APPLIANCE".

DO NOT leave this appliance burning when unattended.

030323

Need help?

Do you have a question about the TFSB2-NG and is the answer not in the manual?

Questions and answers

Summary of Contents for TrueFlame TFSB2-NG

Page 1 TrueFlame Gas Side & Power Burner User Manual Models: Side Burner: TFSB2-NG; TFSB2-LP Power Burner: TFPB-NG; TFPB-LP ATTENTION: INSTALLER: PLEASE LEAVE THESE INSTRUCTIONS WITH THE CONSUMER. CONSUMER: PLEASE READ & RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE AND BEFORE INSTALLING OR OPERATING.
Page 2 WARNINGS READ THIS MANUAL CAREFULLY AND COMPLETELY EXPLOSION HAZARD: BEFORE USING YOUR SIDE BURNER TO REDUCE THE DO NOT use the Side Burner as a storage area for flamma- RISK OF: ble materials. Keep area clear and free from combustible Fire, burn hazard, personal injury or property damage, materials, gasoline, and other flammable vapors and improper installation or servicing electric shock.
Page 3 THANK YOU Power Burner: TFPB-NG; TFPB-LP Thank you for your purchase. We’d like to welcome you to the TrueFlame family of luxury outdoor kitchen (Natural Gas & Liquid Propane Gas Configurations) products, and we look forward to being a part your home for years to come.
Page 4 WARNINGS SAFETY AND INSTALLATION WARNINGS • Please read all instructions before installation or operating your gas Side Burner to prevent injury and appliance dam- • All gas Side Burners will get hot during use. Use extreme caution when operating. • Do not touch hot surfaces.
Page 5 BEFORE USING THE SIDE BURNER UNPACKING YOUR SIDE BURNER IMPORTANT NOTES: Included with your TrueFlame Side Burner are the following BE MINDFUL OF WIND DIRECTION loose items: Using your Side Burner in windy conditions may disrupt Cooking Grates: TFSB2(1), TFPB(2)
Page 6 INSTALLATION MINIMUM SIDE BURNER CLEARANCES: TrueFlame Side Burners are a “built-in” gas unit that re- quires a non-combustible island/enclosure. Use Figure 1 Minimum clearances between the Side Burner and any and Table 1 as a guide. side wall or rear wall must fall within one (or more) of the...
Page 7 10” clearance between the Side Burner When installing this Side Burner in a combustible surround, and protected wall.) an TrueFlame insulating jacket/Side Burner liner must be used. Min. 14” Non-Combustible A minimum five (5) foot clearance is required between the Substrate countertop and the overhead construction.
Page 8 GAS REQUIREMENTS NATURAL GAS REQUIREMENTS WARNING • TrueFlame recommends that only qualified profession- als perform the required plumbing on this product. GAS LINES • Check the Rating Plate to make sure the gas Never connect a gas line directly to the Side supply you are hooking up to is the gas type the Side Burner.
Page 9 GAS REQUIREMENTS SAFE USE AND MAINTENANCE OF PROPANE GAS CYLINDERS IMPORTANT FOR YOUR SAFETY READ AND FOLLOW ALL WARNINGS PROVIDED WITH THE PROPANE GAS CYLINDER. When operating a Propane gas cylinder, these instructions and warnings MUST be observed. FAILURE TO DO SO MAY RESULT IN A SERIOUS FIRE OR EXPLOSION COUPLER OPERATION CYLINDER/CONNECTOR REQUIREMENTS To connect the regulator/hose to the Propane gas...
Page 10 GAS REQUIREMENTS CONNECTING TO A SIDE BURNER LIQUID PROPANE INSTALLATION You will need a ‘T’ adapter fitting (not provided) or similar LP gas Side Burner models are designed for use with a connection to connect a single gas line to both a grill and standard 20 lb.
Page 11 CUSTOM-BUILT ENCLOSURES/ ISLANDS VENTILATION REQUIREMENTS IMPORTANT: Ventilation is require in the enclosure on opposite sides FOR ALL ENCLOSURES to create cross-ventilation. Liquid propane is heavier than natural gas and vents should be located near the bottom of FOR ALL GAS TYPES: the enclosure.
Page 12 OPERATION & MAINTENANCE TIPS READ INSTRUCTIONS READ INSTRUCTIONS BEFORE LIGHTING BEFORE LIGHTING MANUAL (MATCH LIGHT) IGNITION SPARK IGNITION CAUTION: Keep your face and body away from CAUTION: Keep your face and body away from the Side Burner top when lighting the Side Burner top when lighting Always remove the stainless steel lid before light- Always remove the stainless steel lid before light-...
Page 13 Solutions used for cleaning concrete and masonry can Routinely wipe down your Side Burner exterior with warm be very corrosive and will ‘attack’ stainless steel water and finish by applying stainless steel polish. • Be sure your TrueFlame products are well protected before using these products. 030323...
Page 14 IMPORTANT NOTE: FOR LOCATIONS NEAR COASTAL AREAS AND POOLS: #304 stainless steel materials used in the construction of your TrueFlame Side Burner are highly rust resistant, however, chlorine in the air from swimming pools or the salt from sea air may cause surface rust to appear and even create some pitting if left on the product.
Page 15 SIDE & POWER BURNER ILLUSTRATIONS SIDE BURNER: TFSB2 POWER BURNER: TFPB 030323...
Page 16 ILLUSTRATED & REPLACEMENT PARTS TFSB2 Double Side Burner...
Page 17 ILLUSTRATED & REPLACEMENT PARTS TFPB Power Burner 030323...
Page 18 WARRANTY G O L D S T A N D A R D LIFETIME WARRANTY AMD DIRECT GAS APPLIANCES GOLD STANDARD GRILLS, SIDE/POWER BURNERS, WARRANTY GAS GRIDDLE & OVEN • Gold Standard Lifetime Warranty on construction and manufacturer defects • Gold Standard Lifetime Warranty on Stainless Steel Construction •...
Page 19 NOTES 030323...
Page 20 For more information call Customer Care at 800-966-8126 Hours: 7am - 5pm PST 14520 DELTA LANE SUITE 105 HUNTINGTON BEACH, CA 92647 800.966.8126 VER 2.21.23 030323...
