TMG -APW20 Installation Instructions & Product Manual

20 gallon parts washer
Hide thumbs

Advertisement

Quick Links

Download this manual
TMG-APW20
PRODUCT MANUAL
v2023.08.26
20 GALLON PARTS WASHER
Please read and understand the product manual completely before assembly
Check against the parts list to make sure all parts are received
Wear proper safety goggles or other protective gears while in assembly
Do not return the product to dealer. They are not equipped to handle your requests.
Missing parts or questions on assembly?
Please call: 1-877-761-2819 or email: cs@tmgindustrial.com

Advertisement

loading
Need help?

Need help?

Do you have a question about the TMG-APW20 and is the answer not in the manual?

Questions and answers

Summary of Contents for TMG TMG-APW20

  • Page 1 TMG-APW20 PRODUCT MANUAL v2023.08.26 20 GALLON PARTS WASHER Please read and understand the product manual completely before assembly Check against the parts list to make sure all parts are received Wear proper safety goggles or other protective gears while in assembly Do not return the product to dealer.

  • Page 2: Table Of Contents

    TABLE OF CONTENTS TABLE OF CONTENTS ........................2 SAFETY INFORMATION........................... SPECIFICATION..............................COMPONENTS AND CONTROLS........................UNPACKING & ASSEMBLY..........................OPERATION..............................CARE & MAINTENANCE......................TROUBLESHOOTING..........................PARTS DIAGRAM............................

  • Page 3: Safety Information

    IMPORTANT SAFETY INFORMATION Before operating the PARTS WASHER read the following safety instructions. Failure to comply with these warnings may result in serious injury or death. SAFETY INSTRUCTIONS The alert symbol is used throughout this manual and this manual and on the product safety decals. This symbol indicates attention is required and identifies hazards concerning your personal safety and the safety of others.
  • Page 4 INTRODUCTION The 20 Gallon Parts Washer is ideal for cleaning grimy parts with water- based solvents. It has a steel flex nozzle and lid with an electrical safety link in the hinge. SAFETY WARNING! Read and understand all instructions before using this tool. The operator must follow basic precautions to reduce the risk of personal injury and/or damage to the equipment.
  • Page 5 Do not modify the washer lid or the lid arm to keep the lid open. Heat from a fire will melt the fusible link and the washer lid will automatically fall to smother the flames. Use the parts washer in a well-ventilated area to avoid fume build up from the solvent. ELECTRICAL SAFETY WARNING! To reduce risk of electric shock, be certain that the plug is connected to a properly grounded receptacle.

  • Page 6: Specification

    PRODUCTS SPECIFICATIONS Model TMG-APW20 Tank capacity 20 Gallon Solvent capacity 12 Gallon Electric pump 120VAC, 60hz, 0.25A Flow rate 4GPM Tank size 28”x19”x10” Dimensions (L x W x H) 30” x 21” x 35” COMPONENTS AND CONTROLS A: Cover B: Spray Gun...

  • Page 7: Unpacking & Assembly

    UNPACKING & ASSEMBLY UNPACKING WARNING! Do not operate the tool if any part is missing. Replace the missing part before operating. Failure to do so could result in a malfunction and personal injury. Remove the parts and accessories from the packaging and inspect for damage. Make sure that all items in the parts list are included.
  • Page 8 Pump Housing Fig 3 6. Snap the Pump Housing Cover (20) into place on the Pump (28) Housing (28) (Fig 3). 7. Connect the Flexible Pipe (24) to the Elbow (29) (Fig 4). 8. Loosen the two Screws (17) on the Switch Box (23) until there is about a 1/8”...

  • Page 9: Operation

    OPERATING OPERATION WARNING! DO NOT use liquids with a flashpoint under 150ºF (65ºC), such as gasoline, kerosene, ethanol, etc., in the parts washer. The liquid may ignite and cause a fire. Check the manufacturer’s Material Data Sheet for the liquid cleaner’s flashpoint. CAUTION! Wear gloves that will not react with the solvent to protect your hands.

  • Page 10: Care & Maintenance

    IMPORTANT! DO NOT pollute the environment by allowing uncontrolled discharge of waste oil. TROUBLESHOOTING Visit a TMG INDUSTRIAL location for a solution if the tool does not function properly or parts are missing. If unable to do so, have a qualified technician service the tool.

  • Page 11: Parts Diagram

    EXPLODED VIEW & PARTS LIST 1. Exploded diagram...
  • Page 12 2. Parts List PART NO. DESCRIPTION PART NO. DESCRIPTION Cover Screw M4x10 Work basket Strain relief Spring pin Ø1.6x10 Cable and plug Pin 5x20 Pump Housing Safety hinge Filter screen Parts tray Switch Basin Switch box Spring washer Ø6 Flexible pipe G1/4” Nut M6 Elbow seat O-ring Ø11.8x3.1...
