PRODUCT MANUAL

24" Rotary Surface Cleaner

MODEL: TMG-GWS24

Please read the product manual completely before assembly

Check against the parts list to make sure all parts are received

Wear proper safety goggles or other protective gears while in assembly

Missing parts or questions on assembly?

Please call: 1-877-761-2819 or email: cs@tmgindustrial.com

Do not return the product to dealer, they are not equipped to handle your

requests

WWW.TMGINDUSTRIAL.COM

Toll Free:1-877-761-2819

Table of Contents

Need help?

Do you have a question about the TMG-GWS24 and is the answer not in the manual?

Questions and answers

Summary of Contents for TMG TMG-GWS24

Page 1 PRODUCT MANUAL 24” Rotary Surface Cleaner MODEL: TMG-GWS24 Please read the product manual completely before assembly Check against the parts list to make sure all parts are received Wear proper safety goggles or other protective gears while in assembly Missing parts or questions on assembly? Please call: 1-877-761-2819 or email: cs@tmgindustrial.com...
Page 2: Table Of Contents
TABLE OF CONTENTS TABLE OF CONTENTS......................2 INTRODUCTION........................3 IMPORTANT..........................3 SAFETY WARNINGS........................4 FEATURES..........................6 SPECIFICATIONS........................6 INSTALLATION & PREPARATION....................7 CLEAN UP WITH YOUR ROTARY SURFACE CLEANER............8 OPERATION..........................9 TROUBLESHOOTING......................10 PRODUCT EXPLODED AND PARTS LIST................11 WWW.TMGINDUSTRIAL.COM P02/14 Toll Free:1-877-761-2819...
Page 3: Introduction
INTRODUCTION Congratulations on the purchase of your new Rotary Surface Cleaner! You can be assured this Cleaner was constructed and designed with quality and performance in mind. Each component has been rigorously tested to ensure the highest level of acceptance. Your Rotary Surface Cleaner is equipped with a heavy duty high pressure swivel with the versatility of using this Cleaner in both cold and hot water applications.
Page 4: Safety Warnings
SAFETY WARNINGSUCTION HAZARD RISK OF INJECTION OR SEVERE CUTTING INJURY POTENTIAL CONSEQUENCE Serious injury or death could occur from high pressure spray penetrating the skin. -Keep clear of nozzle and spray! Never put your hand, fingers or body directly over the spray nozzle.
Page 5 HAZARD RISK OF BODILY INJURY POTENTIAL CONSEQUENCE Serious injury or death may occur from detergents contacting or penetrating the skin. -SEEK EMERGENCY MEDICAL CARE if the spray appears to have penetrated the skin! DO NOT TREAT AS A SIMPLE CUT! Be prepared to tell a physician exactly what kind of cleaning agents you were using by reading the Material Safety Data Sheet provided with your detergent.
Page 6: Features
3. High Pressure Water Hose 4. Hand-Upper 5. Clevis Pin X 3PCS 6. Bridge Pin X 3PCS 7. Handle-Lower 8. Cover Assembly SPECIFICATIONSU CTION Model TMG-SCP24 Operation Pressure (PSI) 2000-4000 Flow Rate (GPM) 3.0-8.0 Max Temperature (°F/°C) 194°/90° Maximum RPM 2500 Unit Net Weight (Kg) 13.2...
Page 7: Installation & Preparation
INSTALLATION & PREPARATIONU CTION NOZZLE SELECTION & INSTALLATION: 1. Your Rotary Surface Cleaner will come installed with one set of 25020 nozzles (25degree and 2.0 orifice). A. The minimum orifice size to be used in your Rotary Surface Cleaner is half that which is being used in your pressure washer. Example: If your pressure washer uses a size 5 orifice, you will need to use a size 2.5 orifice in your Rotary Surface Cleaner.
Page 8: Clean Up With Your Rotary Surface Cleaner
INSTALLATION & PREPARATIONU CTION Risk of Injury or damage to machine!! COMPLETE SET UP NEVER OPERATE THE UNITIF IT BEGINS TO VIBRATE! Shutdown the unit and tighten the rotating bar, bolts and fittings. PRE-START INSPECTION PROCEDURES: 1. Inspect Rotary Surface Cleaner before each use. Tighten rotating bar, bolts and fittings as needed.
Page 9: Operation
OPERATION The Following Contains Operating And Maintenance Instructions. Do Not Attempt To Operate This Rotary Surface Cleaner Until You Have Read And Understood All Safety Warning And Instructions Listed In This Manual. Incorrect Operation Of This Unit Can Cause Serious Injury!! Do Not Alter Or Modify This Equipment In Any Manner! START-UP: 1.
Page 10: Troubleshooting
TROUBLESHOOTING PROBLEM PROBABLE CAUSE REMEDY Inadequate cleaning power. Not enough PSI from Ensure unit produces a minimum pressure washer. 2000 PSI. Most effective cleaning range is 2500-4000 PSI. Inadequate water supply. Turn water supply completely "ON" and/ or clean water filter on pressure washer.
Page 11: Product Exploded And Parts List
PRODUCT EXPLODED AND PARTS LIST Handle Assembly WWW.TMGINDUSTRIAL.COM P11/14 Toll Free:1-877-761-2819...
Page 12 PRODUCT EXPLODED AND PARTS LIST Cover Assembly WWW.TMGINDUSTRIAL.COM P12/14 Toll Free:1-877-761-2819...
Page 13 PRODUCT EXPLODED AND PARTS LIST Swivel Assembly WWW.TMGINDUSTRIAL.COM P13/14 Toll Free:1-877-761-2819...
Page 14 PRODUCT EXPLODED AND PARTS LIST Part # Description Qty. Part # Description Qty. High pressure water hose Spray nozzle 1/4” QD plug Screw Screw M6x30 Brush assembly 1/4” quick connect Grease nipple Sleeve Swivel housing Trigger gun O-ring Grip Compression spring Upper handle O-ring Lower handle...
