Innovative Power

USER

MANUAL

GW51.2V100Ah

Version：01.00

Table of Contents

Need help?

Do you have a question about the GW51.2V100Ah and is the answer not in the manual?

Questions and answers

Summary of Contents for Growcol GW51.2V100Ah

Page 1 Innovative Power USER MANUAL GW51.2V100Ah Version：01.00...
Page 2: Table Of Contents
CONTENTS 1 Foreword..............................2 Safety................................ 2.1 Safety Precautions........................2.2 Abuse Operation......................... 3 Overview..............................3.1 Product Description........................3.1.1 Features..........................3.1.2 Basic Functions......................... 3.2 Application Scenario......................... 4 Application Description........................4.1 Parallel Connection Application.................... 4.2 Low-temperature Application....................4.3 Low Battery-capacity Storage (SOC≤5%)................4.4 Application of Nearing the Ocean..................5 Product Introduction..........................
Page 3: Foreword
Overview This user manual mainly introduces product introduction, application descrip- tion, installation instructions, power-on instructions, maintenance instructions and provides instructions the GW51.2V100Ah LFP battery pack for technical support engineers, maintenance engineers and users. Reader This document is mainly applicable to the following engineers...
Page 4: Safety
2 Safety 2.1 Safety Precautions Before carrying out battery work, you must read carefully the safety precautions and master the correct installation and connection methods of the battery. Prohibit to turn it upside down, tilt, or collide. Prohibit to short-circuit the positive and negative poles of the battery, otherwise it will cause the battery to be damaged.
Page 5: Overview
3 Overview 3.1 Product Description The GW51.2V100Ah product use lithium iron phosphate (LFP) as the positive electrode material. It can be widely used in energy storage systems such as residen- tial energy storage, back-up power, and PV self-consumption optimization. The battery pack is composed of 16 cells of LFP batteries in series connection, with low self-discharge, high energy density, and no memory effect.
Page 6: Application Scenario
3 Overview • Parallel connection application Support multiple battery packs in parallel, RS485/CAN communication supports up to 6 groups without control unit（or max supports 15 groups with control unit）. • Balance function Support the cells balance function. 3.2 Application Scenario The battery pack is used to provide backup power, load shifting, peaking shaving and can be used for residential energy storage, solar energy storage and other application scenarios.
Page 7: Application Description
4 Application Description 4.1 Parallel Connection Application The battery packs support parallel connection, and synchronously increases the backup time or backup power. Confirm the consistency between the battery packs, check the SOC and voltage and turn off the batteries before connecting them in parallel. Multiple battery packs of parallel connection need to use to communicate, pay attention to the DIP switch settings.
Page 8: Application Of Nearing The Ocean
4 Application Description days@25°C, 15 days@45°C. The battery needs to be recharged in time after storage, otherwise the battery may be damaged due to over-discharge, and the entire battery pack needs to be replaced. The following conditions may cause the battery pack to be stored in a discharged state: After the utility power failure, the line/fault cannot be eliminated in time, and the power supply cannot be restored for a long time.
Page 9: Product Introduction
5 Product Introduction 5.1 Panel Introduction 5.1.1 Panel Function Figure 5-1 Front Panel The interface definition as below table： Table 5-1 Operation Panel Interface Definition Name Description Remark To fix the battery Hangers Power terminal ‘+’ Battery Output ‘+’ Power Power switch State of charge Details shows in table 5-4...
Page 10: Indicator Description
5 Product Introduction 5.1.2 Indicator Description Wall Mounting：When battery is fixed on the wall, please refer to the LED strip on the panel for the status of the battery. Table 5-2 LED Strip Mode Name Description Remark GREEN YELLOW LOW SOC NOTE If you want to turn off the LED strip, please set the sixth of the DIP address to ‘OFF’.
Page 11 5 Product Introduction The power indicator is used to identify the current capacity status of the battery. The number of flashing indicators corresponds to different remaining capacity. The specific meaning is shown in the following table. Table 5-4 SOC Indicator Definition Remaining Capacity Range ●...
Page 12: Dip Address
5 Product Introduction 5.1.3 DIP Address To communicate with the battery, you need to assign an address to the battery BMS through the DIP switch. The relationship between DIP address and BMS address as below： Table 5-6 Correspondence between BMS and DIP Switch DIP 1 DIP 2 DIP 3...
Page 13: Communication Port Definition
5 Product Introduction NOTE CAN communication setting：set the master battery’s DIP address to ‘0’. and for the remaining battery’s DIP addresses need to increase sequentially. RS 485 communication setting：set the batteries’ DIP addresses from 1-15. 5.1.4 Communication Port Definition RJ 45 definition as below： Table 5-7 RJ 45 Definition RJ 45Photo Description...
Page 14: Installation
6 Installation 6.1 Tools Preparation ATTENTION Use insulated tools to avoid electric shock. If you use tools without insulation protection, you need to wrap the exposed metal parts with insulation tape for insulation treatment. The following table describes the tools and meters that may be used before installation.
Page 15: Unpacking And Inspection
6 Installation 6.2 Unpacking and Inspection Study this manual carefully before any installation of the batteries. The batteries must only be installed and operated by trained personnel. Check the quantity of battery and accessories with delivery list. Check the appearance whether there is damaged or leakage, if any damage is detected, please do not proceed to the next installation.
Page 16 6 Installation Figure 6-2-2 Figure 6-2-1 1 Installation Space Requirement. Table 6-2 Installation Space Requirement Min. Distance Left 200mm 200mm Right 150mm Bottom 150mm Wall mounting is as follows（included the right and wrong way） . Figure 6-3 Wall Mounting...
Page 17 6 Installation 2 Make sure the battery is in off status. 3 Install the expansion bolt. A. Please make sure that the thickness of the wall for battery module installation is more than 60mm; B. Please place the bitmap horizontally on the wall and confirm the level by level; C.
Page 18: Rack Mouning
Figure 6-5 Put the Battery into Rack 6 Installation NOTE The depth of the expansion bolts knocked into the wall shall be subject to the entry of all expansion pipes into the holes. The battery needs to be installed indoors, avoiding direct sunlight, rain, snow. Installation wall requirements: please install the battery on a solid concrete wall, do not install the battery on a light or loose wall.
Page 19 6 Installation 3 Use 4 M6*25 bolts to fix thebattery on the rack. Figure 6-7 Fix the Battery on the Rack 4 Grounding the battery. Figure 6-8 Grounding the Battery ATTENTION The battery pack should be installed by professionally trained personnel， and it is strictly forbidden to install it without permission.
Page 20: Cable Connection
6 Installation 6.5 Cable Connection 6.5.1 Power Cable Connection Use the negative power cable to connect the negative bus bar with the battery negative (‘-’) terminal, and use the positive power cable to connect the positive bus bar with the battery positive (‘+’) terminal. A.
Page 21 6 Installation B. If the battery total input/output current more than 100A in parallel, the wiring method should configure bus-bars to connect the power cables. Figure 6-10 Connect the Battery Pack Power Cable to Bus-bars ATTENTION DO NOT use the batteries and cables with more than 100A current, otherwise there is a risk of damage to the batteries and cables.
Page 22: Communication Cable Connection
6 Installation 6.5.2 Communication Cable Connection A. Use the communication cable to connect the battery packs in series through the COM1/COM2 communication port, and connect the battery packs at the end to the inverter's communication port. Figure 6-11 Connect COM1/COM2 Communication Cable B.
Page 23: 120Ω Resistor Connection
6 Installation 6.5.3 120Ω Resistor Connection To ensure stable CAN communication with the inverter when more than 2 batteries are used in parallel, please take out a 120Ω resistor from the ‘Slave Battery Kit’ and insert it into the RJ45 port of the battery that communicates farthest with the inverter. Figure 6-12 Connect the 120Ω...
Page 24: Power On
4 Please configure the actual number of batteries in parallel connection through the UIWare. As follows. NOTE This section is for professionals only and requires specific tools and software. Currently only open to growcol accredited engineers.
Page 25: Uiware Configuration
7 Power On 7.1.2 UIWare Configuration Figure 7-1 Configuration Page 1 Connect the UIWare by computer successfully. 2 Click the 'HOMESTORE' page. 3 Select the actual number of batteries in parallel connection on the 'SYSTEM PACK SUM' 4 Click the‘Write’ button to finish the setting. 5 Restart the battery.
Page 26: Power System Parameter Setting
7 Power On 7.2 Power System Parameter Setting Table 7-1 Parameter Setting Standard Value Parameters Units Rated voltage 51.2 Float charge voltage 57.6 Standard charge current 0.2C Max charge/discharge current Condition to float charge 0.05C Charging operation temp ℃ 0~60℃ Discharging operation temp ℃...
Page 27: Shipment & Maintenance & Storage
8 Shipment & Maintenance & Storage 8.1 Shipment It is suitable for the transportation of vehicles, ships and airplanes. During transportation, shading, sun protection and civilized loading and unloading should be performed. The box containing the product is allowed to be transported by any means of transportation.
Page 28: Routine Maintenance
Appearance deformed, take a photo and replace the or leakage. defective battery pack. The appearance of the battery Please contact Growcol or the authorized pack does not leak. dealers in time for other abnormal No deformation or swelling situations. of the shell.
Page 29: Battery Storage
Have a complete charge & discharge and please check with the alarm list. Complete cycleunder the equipment no Please contact with Growcol or the Cycle lack of power. authorized dealers if the alarm still exists. There is no aging of the connecting wire and no cracking of the Replace the faulty connection.
Page 30: Trouble Shooting
9 Trouble Shooting Please refer to the table below to deal with common faults： Table 9-1 FAQ Phenomenon Possible Cause Solution The power cable of the battery pack is not Reconnect the power cable of the battery pack properly connected. The indicator The power switch is off.
Page 31: Warranty
10 Warranty Except for the following and the conditions specified in the contract, you can go to the Growcol or the authorized dealers for reasonable warranty and maintenance. 1 Failure of equipment caused by unauthorized disassembly and maintenance operations without the authorization of Growcol or the authorized dealers is not within the scope of the warranty.
Page 32: Abbreviations
