ALPEX AEx-8 P Series User Manual

15”, 15.6”, 19”, and 21.5” full ip66 stainless steel designed with m12 waterproof connector of panel pc series
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
AEx-8XXP(H)
15", 15.6", 19", and 21.5" Full IP66 Stainless Steel Designed with M12 waterproof
connector of Panel PC Series.
User Manual
Release Date
Revision
Mar. 2022
V2.0
®2022 Aplex Technology, Inc.
All Rights Reserved.
Published in Taiwan
Aplex Technology, Inc.
15F-1, No.186, Jian Yi Road, Zhonghe District, New Taipei City 235, Taiwan
URL:
http://www.aplextec.com/zh/home.php
Tel: 886-2-82262881
Fax: 886-2-82262883

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AEx-8 P Series and is the answer not in the manual?

Questions and answers

Summary of Contents for ALPEX AEx-8 P Series

  • Page 1 AEx-8XXP(H) 15”, 15.6”, 19”, and 21.5” Full IP66 Stainless Steel Designed with M12 waterproof connector of Panel PC Series. User Manual Release Date Revision Mar. 2022 V2.0 ®2022 Aplex Technology, Inc. All Rights Reserved. Published in Taiwan Aplex Technology, Inc. 15F-1, No.186, Jian Yi Road, Zhonghe District, New Taipei City 235, Taiwan URL: http://www.aplextec.com/zh/home.php...

  • Page 2: Revision History

    Revision History Reversion Date Description 2017/11/24 For Preliminary Release 2018/01/02 Official version 2018/03/27 Modify power pin defined 2018/05/16 Modify power pin description 2018/06/22 Add Warning 2018/10/12 Revise specification wording 2019/08/28 Modify MB information 2020/11/03 Modify MB+ System Specification 2021/06/23 Add IECEX/ATEX Standards in P5 Modify Markings in P4 2021/11/25 Add Pin define data in 1.2 chart...

  • Page 3: Warning!/Disclaimer

    Warning!___________________________ This equipment generates, uses and can radiate radio frequency energy and if not installed and used in accordance with the instructions manual, it may cause interference to radio communications. It has been tested and found to comply with the limits for a Class A computing device pursuant to FCC Rules, which are designed to provide reasonable protection against such interference when operated in a commercial environment.

  • Page 4: Atex Instruction Guide

    ATEX Instruction Guide SAFETY INSTRUCTIONS Read these instructions carefully, and look at the equipment to become familiar with the device before trying to install, operate, or maintain it. The following special messages may appear throughout this documentation or on the equipment to warn of potential hazards or to call attention to information that clarifies or simplifies a procedure.

  • Page 5: Notice/Markings

    Notice Under certain extreme circumstances, the label may generate an ignition-capable level of electrostatic charge. Therefore the equipment shall not be installed in a location where the external conditions are conducive to the build-up of electrostatic charge on the label. In addition, the label shall only be cleaned with a damp cloth.
  • Page 6 Below designated standards were certified with conform the relevant regulations: New standards Ex ec ic IIC T4 Gc II 3GD Ex tc IIIC T135°C Dc IECEx ATEX UKCA IEC 60079-0:2017 EN 60079-0:2018 BS 60079-0:2018 IEC 60079-11:2011 EN 60079-11:2012 BS 60079-11:2012 IEC 60079-7:2015 +AMD1:2017 EN 60079-7:2015/A1:2018 BS 60079-7:2015/A1:2018...

  • Page 7: Table Of Contents

    Table of Contents Revision History…………………………………………………………………………………………………….1 Warning!/Disclaimer…………..……………........…………………………….…2 ATEX Instruction Guide……………….….……………………………………………………………………..3 Notice/Markings……………………………………………………………………….…..……………………..4 Chapter 1 Getting Started 1.1 Features………………………..………………………...…………………………..8 1.2 Specifications…………………...………………………………………………….8 1.3 Dimensions………………………..…………………………………………….12 1.4 Brief Description of AEx-8XXP(H)………………………….……….……14 1.5 VESA Mounting…………………………………………………………………15 1.6 Panel Mounting…………………………………………………………………15 Chapter 2 Hardware 2.1 Motherboard Introduction……………………...……………..………..16 2.2 Specifications…………………………..…………………………………………16 2.3 Jumpers and Connectors Location……………………………………...20 2.4 Jumpers Setting and Connectors…………………………………..……21 Chapter 3 BIOS Setup...
  • Page 8 Chapter 5 Touch Screen Installation 5.1 Windows 8.1/10 Universal Driver Installation…….………………78 5.2 Software Function…………….…………………………………….……..82 Figures Figure 1.1: Dimensions of AEx-815P(H)……..…………………..………………..12 Figure 1.2: Dimensions of AEx-816P…………..…………………..………………..12 Figure 1.3: Dimensions of AEx-819P(H)……..…………………..………………..13 Figure 1.4: Dimensions of AEx-821P…………..…………………..………………..13 Figure 1.5: Front View of AEx-8XXP(H).…………………………………….…….….14 Figure 1.6: Rear View of AEx-8XXP(H)……..…………………………………….….14 Figure 1.7: AEx-8XXP(H) Series VESA Mounting..…………………….…….….15 Figure 1.8: AEx-8XXP(H) Series Panel Mounting…………………………….….15...

  • Page 9: Getting Started

    Chapter 1 Getting Started 1.1 Features  Intel® Celeron Processor N2930  Full flat bezel and fanless design  Full IP66 grade with M12 waterproof connector  DC 9~36V wide range power input  Projective capacitive touch  316 Stainless steel design ...
  • Page 10 2 x M12 for LAN with waterproof cover and chain Pin Define LAN1_0+ LAN1_0- LAN1_1+ LAN1_1- LAN1_2+ LAN1_2- LAN1_3+ LAN1_3- Power 1 x M12 for DC power 9~36V input by M12 connector Pin Define 1 x M12 for VGA with waterproof cover and chain Storage Space Storage 1 x 2.5”...
  • Page 11 Display type 15” color TFT LCD 15.6” color TFT LCD 19” color TFT LCD 21.5” color TFT LCD Max. Resolution 1024 x 768 1920 x 1080 1280 x 1024 1920 x 1080 Max. Color 16.2M 262K 16.7M 16.7M 16.7M Luminance (cd/m 1000 1000 Contrast Ratio...
  • Page 12 Class III ANSI/ISA 12.12.01-2013 CSA Std.C22.2 No213-1987 CSAE 22UKEX 1073X Operating System Support OS Support Windows Embedded 7 Windows Embedded 8.1 Windows 10 IOT Enterprise LTSB 2016 AEx-8XXP(H) Series User Manual...

  • Page 13: Dimensions

    1.3 Dimensions Figure 1.1: Dimensions of AEx-815P(H) Figure 1.2: Dimensions of AEx-816P AEx-8XXP(H) Series User Manual...

  • Page 14: Figure 1.3: Dimensions Of Aex-819P(H)

    Figure 1.3: Dimensions of AEx-819P(H) Figure 1.4: Dimensions of AEx-821P AEx-8XXP(H) Series User Manual...

  • Page 15: Brief Description Of Aex-8Xxp(H)

    1.4 Brief Description of AEx-8XXP(H) Series AEx-8XXP(H) are panel PC series models for ATEX certification, which comes with full waterproof with IP66 level designed. It is powered by Intel Celeron N2930 processor and supports 8GB DDR3L onboard memory. It comes with a 15”, 15.6”, 19”, and 21.5”...

  • Page 16: Vesa Mounting

    1.5 VESA Mounting The AEx-8XXP(H) series is designed to be VESA mounted as shown in Picture. Just carefully place the unit through the hole and tighten the given screws from the rear to secure the mounting. Figure 1.7: AEx-8XXP (H) Series VESA Mounting 1.6 Panel Mounting There are six holes located along the four sides of the panel PC.

  • Page 17: Chapter 2 Hardware

    Chapter 2 Hardware 2.1 Motherboard Introduction SBC-7111 is a 4" industrial motherboard developed on the basis of Intel Bay trail-I/M Processors, which provides abundant peripheral interfaces to meet the needs of different customers. Also, it features dual GbE ports, 3-COM ports and one Mini PCIE configuration, one VGA port, one HDMI port, one LVDS interface.
  • Page 18 BIOS AMI/UEFI Storage 1 x SATAII Connector (7Pin, option) 1 x SATAII Connector (7Pin + 15Pin) 1 x SD Slot (USB2 to SD, option) Ethernet 2 x PCIe GbE LAN by Intel 82574L USB 3.0 Hub(USB5534): 2 x USB 3.0/USB 2.0 (type A)stack ports (E2_USB5/E2_USB6) 1 x USB 2.0 for Touch controller (E2_USB7) 1 x USB 2.0 Pin header for CN1 (E2_USB8) USB 2.0 Hub(USB2514)
  • Page 19 1 x 4-pin power input connector (DC_IN2/DC12V) Switches and LED 1 x Power on/off switch (BT1/BT2/P_SW/CN2/CN3) Indicators 1 x Reset (CN2) 1 x Power LED status (CN1) 1 x HDD LED status (CN2) 1 x Buzzer External I/O port 2 x COM Ports (COM1/COM2) 2 x USB 3.0/2.0 Ports (stack) 2 x RJ45 GbE LAN Ports 1 x HDMI Port...

  • Page 20: Figure 2.1: Motherboard Dimensions

    (units :mm) Figure 2.1: Motherboard Dimensions AEx-8XXP(H) Series User Manual...

  • Page 21: Jumpers And Connectors Location

    2.3 Jumpers and Connectors Location Figure 2.2: Jumpers and Connectors Location- Board Top Figure 2.3: Jumpers and Connectors Location- Board Bottom AEx-8XXP(H) Series User Manual...

  • Page 22: Jumpers Setting And Connectors

    2.4 Jumpers Setting and Connectors 1. U2: (FCBGA1170), onboard Intel Bay trail-I/M Processors. Model Processor Number Cores/Threads Remarks SBC-7111-N2930-4G SBC-7111-N2930-4G-SW N2930 1.83 up to 4 / 4 4.5/7.5W SBC-7111-N2930P-4G 2.16GHz SBC-7111-N2930-2G SBC-7111-N2930P-CN3V-2G SBC-7111-N2930-8G SBC-7111-E3845-4G E3845 1.91GHz 4 / 4 option 2.
  • Page 23 Pin# Signal Name VBAT Ground 6. DC_IN1: (5.08mm Pitch 1x3 Pin Connector), DC9~36V System power input connector. Pin# Power Input DC+6V~36V Ground Model DC_IN1 SBC-7111-N2930-4G 180°Connector SBC-7111-N2930-4G-SW 180°Connector SBC-7111-N2930-2G 180°Connector SBC-7111-N2930-8G 180°Connector SBC-7111-E3845-4G 180°Connector SBC-7111-N2930P-4G 45°Connector SBC-7111-N2930P-CN3V-2G 45°Connector 7. DC_IN2 (option): (2.0mm Pitch 1x8 wafer Pin Header) DC12V System power input connector.
  • Page 24 ● ● ○ SBC-7111-N2930-8G ● ● ○ SBC-7111-E3845-4G SBC-7111-N2930P-CN3V-2G ○ ● ○ ○ ● ● SBC-7111-N2930-4G-SW 9. FAN1(option): (2.54mm Pitch 1x3 Pin Header), Fan connector, cooling fans can be connected directly for use. You may set the rotation condition of cooling fan in menu of BIOS CMOS Setup.
  • Page 25 Ground Ground ○ VGA hot plug setting: VGA1 (Pin Header) Function Pin4-Pin6 (Close) VGA Simulation Disabled Pin4-Pin6 (Open) VGA Simulation Enabled Use the 2.0mm jumper cap to close pin4 and pin6 11. HDMI1: (HDMI 19P Connector), High Definition Multimedia Interface connector. 12.
  • Page 26 (2.0mm Pitch 1x6 wafer Pin Header), Backlight control connector for LVDS. Pin# Signal Name +DC12V +DC12V Ground Ground BKLT_EN_OUT BKLT_CTRL 15. CN1: (1.25mm Pitch 2x20 Connector, DF13-40P), for 18/24-bit LVDS output connector, fully supported by Parad PS8625(DP to LVDS), the interface features dual channel 24-bit output.
  • Page 27 Power LED PWR_LED+ Ground Power LED 16. JP4 (Reserve): (2.0mm Pitch 2x2 Pin Header). Function Close 3-4 (default) Open 1-2 (default) Close 3-4 (option) Hardware Enabled 17. TCH1: (2.0mm Pitch 1x6 wafer Pin Header), internal Touch controller connector. Pin# Signal Name SENSE GND_EARCH 18.
  • Page 28 RS485 (option) OFF: Pin1, Pin2, Pin3, Pin4, Pin5 20. S_422: (Switch), COM1 setting, it provides selectable RS232 or RS422 or RS485 serial signal output. Function S_422 Pin# (switch) RS232 (Default) OFF: Pin1, Pin2, Pin3, Pin4, Pin5 RS422 (option) ON: Pin1, Pin2, Pin3, Pin4, Pin5 RS485 (option) ON: Pin1, Pin2, Pin3, Pin4, Pin5 S-422 (switch)
  • Page 29 422_RX- 422_TX- 422_TX+ Ground BIOS Setup: Advanced/F81216SEC Super IO Configuration/Serial Port 1 Configuration 【RS-422】 RS485 (option) Pin# Signal Name 485- 485+ Ground BIOS Setup: Advanced/F81216SEC Super IO Configuration/Serial Port 1 Configuration 【RS-485】 22. JP2: (2.0mm Pitch 2x3 Pin Header), COM2 jumper setting, pin 1~6 are used to select signal out of pin 9 of COM2 port.
  • Page 30 Pin# Signal Name DCD# (Data Carrier Detect) RXD (Received Data) TXD (Transmit Data) DTR (Data Terminal Ready) Ground DSR (Data Set Ready) RTS (Request To Send) CTS (Clear To Send) JP2 select Setting (RI/5V/12V) 24. LED1, LED2, LED3, LED4 (option) : LED1: LED STATUS.
  • Page 31 26. SATA2 (option): (SATA 7Pin), SATA Connectors, one SATA connector is provided with transfer speed up to 3.0Gb/s. Model SATA2 (Connectors) ○ SBC-7111-N2930-4G ○ SBC-7111-N2930-4G-SW SBC-7111-N2930P-4G ○ SBC-7111-N2930P-CN3V-2G ○ SBC-7111-E3845-4G ○ SBC-7111-N2930-2G ○ ○ SBC-7111-N2930-8G 27. SATA1: (SATA 7Pin+15Pin), SATA Connectors, one SATA connector is provided with transfer speed up to 3.0Gb/s.
  • Page 32 MIC-IN-L MIC-IN-R GND-AUD MIC1_JD 32. LINE_OUT1: (Diameter 3.5mm Jack), HD Audio port, an onboard Realtek ALC662-VD codec is used to provide high quality audio I/O ports. Line Out can be connected to a headphone or amplifier. Model LINE_OUT1 ● SBC-7111-N2930-4G SBC-7111-N2930P-4G ●...
  • Page 33 Model RJ45(LAN1) RJ45(LAN2) ● ● SBC-7111-N2930-4G ● ● SBC-7111-N2930P-4G SBC-7111-N2930-2G ● ● SBC-7111-N2930-8G ● ● SBC-7111-E3845-4G ● ● SBC-7111-N2930P-CN3V-2G ● ○ ● ● SBC-7111-N2930-4G-SW 35. BUZ1: Onboard buzzer. 36. CN2: (DF13-30P Connector) For expand output connector, It provides eight GPIO, one RS422 or RS485, one USB2.0, one Power on/off, one Reset.
  • Page 34 Advanced/IT8518Super IO Configuration/Serial Port 2 Configuration【RS-485】 Advanced/IT8518Super IO Configuration/Serial Port 2 Configuration【RS-422】 37. EC_GPIO1 (option): (2.0mm Pitch 1X10 Pin Header)For expand connector, it provides eight GPIO. Pin# Signal Name Ground GPA0_ONOFF GPA1_SPK- GPE6_BKLT- GPE0_BKLT+ SPKGPC3_SPK+ BKL_CTRL_PWR ADC6_BKLT_CTRL ADC7_L_SENSE 3.3V Function EC_GPIO1 Backlight Automatic dimming ○...
  • Page 35 COM4_DSR COM_CTS- Ground Ground COM3_RI COM3_DCD- COM3 COM3 COM3_TXD COM3_RXD (UART) (UART) COM3_DTR DSRCOM3_RTS- COM3_DSR DTRCOM3_CTS- GPIO23 SOC_GPIO23 ICH_GPIO22 GPIO22 GPIO25 SOC_GPIO25 ICH_GPIO24 GPIO24 Ground Ground PCIE_TX0_DN PCIE_TX0_DP PCIE_RX0_DN PCIE_RX0_DP PCIE 1X PCIE 1X Ground Ground PCIE_REFCLK0_DN PCIE_REFCLK0_DP PCIE0_WAKE_N PLTRST_3P3_N SMBUS SMB_CLK_S0 SMB_DATA_S0...
  • Page 36 39. TB-528Series: CN3： (1.27mm Pitch 2X30 Pin Header), connect to SBC-7118 CN2 pin Header. M-PCIE1： (Socket 52Pin),mini PCIe socket, it is located at the top, it supports mini PCIe devices with USB2.0(USB3),Smbus,SIM and PCIe signal. MPCIe card size is 30x30mm or 30x50.95mm.
  • Page 37 H1/H2: MPCIE1 SCREW HOLES, H2 for mini PCIE card (30mmx30mm) assemble. H1 for mini PCIE card (30mmx50.95mm) assemble. LED1： Mini PCIe devices LED Status. SIM1： (Nano SIM Socket 6 Pin), Support SIM Card devices. SIM2(option)： (1.25mm Pitch 1X6 Pin Wafer), For expansion SIM Card devices. GPIO1：...
  • Page 38 Signal Name Pin# Pin# Signal Name 5V_USB12 5V_USB12 E_USB1_N E_USB2_N E_USB1_P E_USB2_P Ground Ground Ground Note: Before connection, make sure that pinout of the USB Cable is in accordance with that of the said tables. Any inconformity may cause system down and even hardware damages.
  • Page 39 JP5 Setting: Pin1-2 : RI (Ring Indicator) (default) Pin3-4 : 5V Standby power (option) Pin5-6:12V Standby power (option) COM_5： (2.0mm Pitch 2X5 Pin Header),COM5 Port, up to one standard RS232 port are provided. They can be used directly via COM cable connection. Signal Name Pin# Pin#...
  • Page 40 Ground DSR (Data Set Ready) RTS (Request To Send) CTS (Clear To Send) JP6 Setting: Pin1-2 : RI (Ring Indicator) (default) Pin3-4 : 5V Standby power (option) Pin5-6:12V Standby power (option) COM_6： (2.0mm Pitch 2X5 Pin Header), COM6 Port, up to one standard RS232 port are provided.
  • Page 41 39-1. TB-528CAN2 R2.00: SBC-7118 IO expansion card, providing two CAN-bus Interface. TB-528CAN2 Top： CN3： (1.27mm Pitch 2X30 Pin Header),connect to SBC-7118 CN2 pin Header. M-PCIE1： (Socket 52Pin),mini PCIe socket, it is located at the top, it supports mini PCIe devices with Smbus,USB2.0,SIM and PCIe signal.
  • Page 42 LED1： Mini PCIe devices LED Status SIM1(option)： (SIM Socket 6 Pin), Support SIM Card devices PS2： (2.0mm Pitch 1X6 Pin Wafer), PS/2 keyboard and mouse port, the port can be connected to PS/2 keyboard or mouse via a dedicated cable for direct used. Pin# Signal Name KBDATA...
  • Page 43 Signal Name Pin# Pin# Signal Name 3P3V_S5_USB 3P3V_S5 3P3V_S5_USB 3P3V_S5 3P3V_S5_USB 3P3V_S5 PSON_ATX Ground PSON_ATX Ground JP6： (2.0mm Pitch 2x3 Pin Header),COM6 setting jumper, pin 1~6 are used to select signal out of pin 9 of COM6 port. JP3 Pin# Function Close 1-2 RI (Ring Indicator)
  • Page 44 GPIO1： (2.0mm Pitch 2x5 Pin Header),General-purpose input/output port, it provides a group of self-programming interfaces to customers for flexible use. Signal Name Pin# Pin# Signal Name Ground SMB_DATA_R SMB_CLK_R PCH-GPIO56 PCH -GPIO57 PCH -GPIO59 PCH -GPIO58 JTAG： (2.0mm Pitch 2x5 Pin Header), Reserve. JP1：...
  • Page 45 39-2. TB-528E1U2/TB-528E1U2POE/TB-528E1U2UPOE: SBC-7111 IO expansion card, providing USB2.0 and 1xGbE Lan expansion. Can support POE(Power over Ethernet) powered device via onboard POE module Model USB2.0 Type-A GbE LAN TB-528E1U2 ● ● TB-528E1U2POE ● ● 30W PD TB-528E1U2UPOE ● ● 45W PD TB-528E1U2POE Top：...
  • Page 46 PSE Function support PSE output Voltage DC44~ 57V U2/U7 (Option)： For onboard POE powered device module. Model PoE Module TB-528E1U2POE TB-528E1U2UPOE 12V_OUT1： (3.96mm Pitch 1x2 Pin Header), POE DC12V Output. Pin# Output Voltage 12V_POE Ground 12V_OUT3(option)： (2.0mm Pitch 1x6 Pin Header), Reserve. 12V_OUT1(option)：...

  • Page 47: Bios Setup

    Chapter 3 BIOS Setup 3.1 Operations after POST Screen After CMOS discharge or BIOS flashing operation, press [Delete] key to enter CMOS Setup. After optimizing and exiting CMOS Setup, the POST screen displayed for the first time is as follows and includes basic information on BIOS, CPU, memory, and storage devices.

  • Page 48: Main Settings

    3.3 Main Settings System Time: Set the system time, the time format is: Hour : 0 to 23 Minute : 0 to 59 Second : 0 to 59 AEx-8XXP(H) Series User Manual...

  • Page 49: Advanced Settings

    System Date: Set the system date, the date format is: Day: Note that the ‘Day’ automatically changes when you set the date. Month: 01 to 12 Date: 01 to 31 Year: 1998 to 2099 3.4 Advanced Settings 3.4.1 ACPI Settings Enable ACPI Auto Conf: [Disabled] [Enabled]...
  • Page 50 [Enabled] [Disabled] ACPI Sleep State: [S3 (Suspend to RAM) ] [Suspend Disabled] Lock Legacy Resources: [Disabled] [Enabled] 3.4.2 F81216SEC Super IO Configuration Super IO chip F81216SEC Serial Port 1 Configuration UART1 Mode Selection： [RS-232] [RS-485] [RS-422] Serial Port 2 Configuration Change Settings [Auto] Serial Port 3 Configuration...
  • Page 51 3.4.5 CPU Configuration Socket 0 CPU Information Intel® Atom™ CPU E3845 @ 1.91GHz CPU Signature 30679 Microcode Patch Max CPU Speed 1910 MHz Mix CPU Speed 500 MHz Processor Cores Intel HT Technology Not Supported Intel HT-X Technology Supported L1 Data Cache 24KB x 4 L1 Code Cache 32KB x 4...
  • Page 52 3.4.6 PPM Configuration CPU C State Report [Enabled] [Disabled] Max CPU C-state [C7] [C6] [C1] SOix [Disabled] [Enabled] 3.4.7 Thermal Configuration Parameters 3.4.8 IDE Configuration Serial-ATA(SATA) [Enabled] [Disabled] SATA Test Mode [Disabled] [Enabled] SATA Speed Support [Gen2] [Gen1] SATA ODD Port [No ODD] [Porto ODD] [Port1 ODD]...
  • Page 53 Serial-ATA Port 1 [Enabled] [Disabled] SATA Port1 Hotplug [Disabled] [Enabled] SATA Port0 Not Present SATA Port1 Not Present 3.4.9 Miscellaneous Configuration 3.4.10 LPSS & SCC Configuration LPSS & SCC Configuration [ACPI Mode] SCC Configuration SCC eMMC Support [eMMC AUTO MODE] SCC eMMC 4.5 DDR50 Support [Enabled] SCC eMMC 4.5 HS200 Support [Disabled]...
  • Page 54 I2C touch Device Address LPSS HSUART #1 Support [Disabled] LPSS HSUART #2 Support [Disabled] LPSS PWM #1 Support [Enabled] LPSS PWM #2 Support [Enabled] LPSS SPI Support [Enabled] 3.4.11 System Component 3.4.12 Network Stack Configuration Network Stack [Disabled] 3.4.13 CSM Configuration CSM Support [Enabled] CSM16 Module Version...
  • Page 55 3.4.14 SDIO Configuration 3.4.15 USB Configuration USB Configuration USB Module Version 8.11.02 USB Devices: 1 keyboard, 1 Mouse，2 Hubs Legacy USB Support: [Enabled] [Disabled] XHCI Hand-off: [Enabled] [Disabled] EHCI Hand-off: [Disabled] [Enabled] USB Mass Storage Driver Support [Enabled] [Disabled] USB hardware delays and time-outs： USB transfer time-out: [20 sec] [10 sec]...

  • Page 56: Chipset Settings

    3.5 Chipset Settings 3.5.1 Host Bridge ►Intel IGD Configuration ►IGD – LCD Control Force Lid Status [On] [Off] [Auto] ALS Support [Disabled] IGD Flat Panel [Auto] Pannel Scaling [Auto] ►Memory Frequency and Timing ►Graphics Power Management Control Memory Information Total Memory 4096 MB(DDR3L) Memory Slot0 4096 MB(DDR3L)
  • Page 57 [2.25GB] [2.5GB] [2.75GB] [3GB] Backlight PWM or DC Control [PWM] [DC] Backlight PWM Control [PWM Normal by BIOS] BIOS Control Backlight Level [Level 7] [Level 0] [Level 1] [Level 2] [Level 3] [Level 4] [Level 5] [Level 6] [Level 8] [Level 9] [Level 10] [Level 11]...
  • Page 58 USB 2.0(EHCI) Support [Enabled] USB EHCI debug [Disabled] USB Per Port Control [Enabled] USB Port 0 [Enabled] USB Port 1 [Enabled] USB Port 2 [Enabled] USB Port 3 [Enabled] AEx-8XXP(H) Series User Manual...

  • Page 59: Security Settings

    3.6 Security Settings 3.6.1 Administrator Password 3.6.2 User Password Type the password with up to 20 characters and then press Enter key. This will clear all previously typed CMOS passwords. You will be requested to confirm the password. Type the password again and press Enter key.
  • Page 60 will be disabled. You will have direct access to BIOS setup without typing any password after system reboot once the password is disabled. Once the password feature is used, you will be requested to type the password each time you enter BIOS setup. This will prevent unauthorized persons from changing your system configurations.

  • Page 61: Boot Settings

    3.7 Boot Settings Setup Prompt Timeout Bootup Numlock State [On] [off] Quiet Boot [Disabled] [Enabled] Fast Boot [Disabled] [Enabled] Boot Option Priorities Boot Option #1 Sets the system boot order Hard Drive BBS Priorities [SATA PM:*** … ] Boot Option #1 SATA PM:***…...

  • Page 62: Save & Exit Settings

    3.8 Save & Exit Settings Save Changes and Exit Save & Exit Setup save Configuration and exit ? [Yes] [No] Discard Changes and Ext Exit Without Saving Quit without saving? [Yes] [No] Save Changes and Reset Save & reset Save Configuration and reset? [Yes] [No] Discard Changes and Reset...
  • Page 63 Save Changes Save Setup Values Save configuration? [Yes] [No] Discard Changes Load Previous Values Load Previous Values? [Yes] [No] Restore Defaults Load Optimized Defaults Load optimized Defaults? [Yes] [No] Save user Defaults Save Values as User Defaults Save configuration? [Yes] [No] Restore user Defaults Restore User Defaults Restore User Defaults?

  • Page 64: Chapter 4 Installation Of Drivers

    Chapter 4 Installation of Drivers This chapter describes the installation procedures for software and drivers under the windows 8.1 & 10. The software and drivers are included with the motherboard. The contents include Intel/VGA chipset driver, Audio driver, Com Driver, and TXE(Win) Driver Installation instructions are given below.

  • Page 65: Intel® Atom™ Soc Chipset

    4.1 Intel® Atom™ SoC Chipset To install the Intel chipset driver, please follow the steps below. Step1. Select Intel ® Atom™ SoC Chipset from the list Step2. Here is welcome page. Please make sure you save and exit all programs before install.
  • Page 66 Step3. Read the license agreement. Click Accept to accept all of the terms of the license agreement. Step4. Click Install to begin the installation. AEx-8XXP(H) Series User Manual...
  • Page 67 Step5. Click Finish to exit the wizard. AEx-8XXP(H) Series User Manual...

  • Page 68: Intel® Vga Chipset

    4.2 Intel® VGA Chipset To install the Intel® VGA Chipset, please follow the steps below. Step1. Select Intel® VGA Chipset from the list. Step2. Click Next. AEx-8XXP(H) Series User Manual...
  • Page 69 Step3. Choose automatically run function and Click Next to setup program. Step4. Read the license agreement. Click Yes to accept all of the terms of the license agreement. AEx-8XXP(H) Series User Manual...
  • Page 70 Step5. Click Next to continue. Step6. Click Next to continue. AEx-8XXP(H) Series User Manual...
  • Page 71 Step7. Select Yes, I want to restart this computer now. Click Finish, then remove any installation media from the drives. AEx-8XXP(H) Series User Manual...

  • Page 72: Realtek Alc662 Hd Audio Driver Installation

    4.3 Realtek ALC662 HD Audio Driver Installation To install the Realtek ALC662 HD Audio Driver, please follow the steps below. Step1. Select Realtek AL662 HD Audio Driver from the list Step2. Click Next to continue. AEx-8XXP(H) Series User Manual...
  • Page 73 Step3. Click Yes, I want to restart my computer now. Click Finish to complete the installation. AEx-8XXP(H) Series User Manual...

  • Page 74: Com Driver

    4.4 Com Driver To install the Com Driver, please follow the steps below. Step1. Select Com Driver from the list Step2. Select setup language you need. Click Next to continue. AEx-8XXP(H) Series User Manual...
  • Page 75 Step3. Click Next to begin the installation. Step4. Choose Yes, I want to restart my computer now. Click Finish to complete the installation. AEx-8XXP(H) Series User Manual...

  • Page 76: Intel_Txe(Win) Driver

    4.5 Intel_TXE(Win) Driver To install the Intel_TXE(Win) Driver, please follow the steps below. Step1. Select Intel_TXE(Win) Driver from the list Step2. Click Next to continue. AEx-8XXP(H) Series User Manual...
  • Page 77 Step3. Read the license agreement. Choose Accept and click Next to accept all of the terms of the license agreement. Step4. Click Next to continue. AEx-8XXP(H) Series User Manual...
  • Page 78 Step5. Click Finish to complete the installation. AEx-8XXP(H) Series User Manual...

  • Page 79: Chapter 5 Touch Screen Installation

    Chapter 5 Touch Screen Installation This chapter describes how to install drivers and other software that will allow your touch screen work with different operating systems. 5.1 Windows 8.1/10 Universal Driver Installation for PenMount 6000 Series Before installing the Windows 8.1/10 driver software, you must have the Windows 8.1/10 system installed and running on your computer.
  • Page 80 Step2. Click Next to continue. Step3. Read the license agreement. Click I Agree to agree the license agreement. AEx-8XXP(H) Series User Manual...
  • Page 81 Step4. Choose the folder in which to install PenMount Windows Universal Driver. Click Install to start the installation. Step5. Wait for installation. Then click Yes to continue. AEx-8XXP(H) Series User Manual...
  • Page 82 Step6. Click Finish to complete the installation. AEx-8XXP(H) Series User Manual...

  • Page 83: Software Function

    5.2 Software Functions Upon rebooting, the computer automatically finds the new 6000 controller board. The touch screen is connected but not calibrated. Follow the procedures below to carry out calibration. 1. After installation, click the PenMount Monitor icon “PM” in the menu bar. 2.
  • Page 84 Calibrate This function offers two ways to calibrate your touch screen. ‘Standard Calibration’ adjusts most touch screens. ‘Advanced Calibration’ adjusts aging touch screens. Standard Calibration Click this button and arrows appear pointing to red squares. Use your finger or stylus to touch the red squares in sequence.
  • Page 85 Step 2.Click “Standard Calibration” to start calibration procedure NOTE: The older the touch screen, the more Advanced Mode calibration points you need for an accurate calibration. Use a stylus during Advanced Calibration for greater accuracy. Please follow the step as below: AEx-8XXP(H) Series User Manual...
  • Page 86 Step3. Select Device to calibrate, then you can start to do Advanced Calibration. NOTE: Recommend to use a stylus during Advanced Calibration for greater accuracy. Plot Calibration Data Check this function and a touch panel linearity comparison graph appears when you have finished Advanced Calibration.
  • Page 87 Setting Touch Mode This mode enables and disables the mouse’s ability to drag on-screen icons – useful for configuring POS terminals. Mouse Emulation – Select this mode and the mouse functions as normal and allows dragging of icons. Click on Touch – Select this mode and mouse only provides a click function, and dragging is disables.
  • Page 88 Edge Compensation You can use Edge Compensation to calibrate more subtly. About This panel displays information about the PenMount controller and driver version. AEx-8XXP(H) Series User Manual...
  • Page 89 Multiple Monitors Multiple Monitors support from two to six touch screen displays for one system. The PenMount drivers for Windows 8.1/10 support Multiple Monitors. This function supports from two to six touch screen displays for one system. Each monitor requires its own PenMount touch screen control board, either installed inside the display or in a central unit.
  • Page 90 4. Touching all screens completes the mapping and the desktop reappears on the monitors. 5. Select a display and execute the “Calibration” function. A message to start calibration appears. Click OK. 6. “Touch this screen to start its calibration” appears on one of the screens. Touch the screen.
  • Page 91 About This panel displays information about the PenMount controller and this driver version. PenMount Monitor Menu Icon The PenMount monitor icon (PM) appears in the menu bar of Windows 8.1/10 system when you turn on PenMount Monitor in PenMount Utilities. PenMount Monitor has the following function Control Panel Open Control Panel Windows...
  • Page 92 Configuring the Rotate Function 1. Install the rotation software package. 2. Choose the rotate function (0°, 90°, 180°, 270°) in the 3rd party software. The calibration screen appears automatically. Touch this point and rotation is mapped. NOTE: The Rotate function is disabled if you use Monitor Mapping. AEx-8XXP(H) Series User Manual...
