Page 1 SSM workstation Quick Guide XWV-3010...
Page 2 Disclaimer Hanwha Vision makes the best to verify the integrity and correctness of the contents in this document, but no formal guarantee shall be provided. Use of this document and the subsequent results shall be entirely on the user’s own responsibility.
Page 3: Table Of Contents
Table of Contents OVERVIEW Before reading the user manual Configuration and Tips of User Manual Package Contents Part Names and Functions EXECUTION 10 Power Supply 11 Configure the workstation 14 How to Launch SSM 16 Menu Description...
Page 4: Overview
Overview Before reading the user manual Be sure to read the following before reading the user manual. • This manual is copyrighted by the manufacturer. • This manual cannot be reproduced without permission. • We are not responsible for any damage caused by using products other than the standard product or using the product for the purpose other than mentioned in the manual.
Page 5 Notes, Cautions, and Warnings Notes Provides important information which helps you use the product more efficiently. Explains the risk of hardware damage or data loss while teaching how to prevent these Cautions problems. Warnings The warning explains that there is a risk of property loss, bodily injury, or death.
Page 6: Configuration And Tips Of User Manual
Overview Configuration and Tips of User Manual The manual of this product is composed as follows. y Quick Guide y SSM User Manual y System User Manual This User Manual is the default setting for user's guide. The User Manual contains the following in order: If you want to apply the modification to the actual operating environment, refer to the SSM User Manual and the System User Manual.
Page 7: Package Contents
Package Contents Main body Mouse Power cord mDP to DP adapter Quick Guide Accessories other than the SSM workstation body are consumables and are excluded from the warranty. All manuals can be downloaded from our homepage (www.HanwhaVision.com).
Page 8: Part Names And Functions
Overview Part Names and Functions Front Name Name Power button and power indicator USB 2.0 port SD card reader USB 3.2 Gen2x2 Type-C port Ⓡ Hard drive operation indicator USB 3.2 Gen2x2 port Universal audio jack port Optical disk drive USB 2.0 port, supports PowerShare 8_ Overview...
Page 9 Rear Name Name Line In/Out re-assignment Power connector port 2 DisplayPort 1.4 ports Power supply diagnostic indicator Serial port Loop lock PS/2 keyboard port Network port USB 3.2 Gen 2 port 3 USB 3.2 Gen 1 ports 2 USB 2.0 ports, supports turning on the power Kensington security cable slot Extended Network port PS/2 mouse port...
Page 10: Execution
Execution Power Supply Plug all of the power cords into the back of the product, and press the power button. If the product does not turn on, check the following. 1. Make sure that all the power cords have been plugged in firmly, and that they meet the required power specifications.
Page 11: Configure The Workstation
Configure the workstation 1. Connect the keyboard and mouse. 2. Connect to a network using a cable or connect to a wireless network.
Page 12 Execution 3. Connect the monitor. If a monitor’s connection terminal is removed or its configuration is changed while using multiple monitors, the monitoring window may move or an excessive CPU load could occur. No connection cable will be provided other than mDP to DP adapter. 12_ Execution...
Page 13 4. Connect the power cable. 5. Press the power button.
Page 14: How To Launch Ssm
Execution How to Launch SSM This chapter describes how to launch SSM. For more information on how to use SSM, refer to the additional manual on the desktop. 1. Click the SSM Service Manager icon on the desktop to launch it. 2.
Page 15 7. Enter the IP address and name of the server to be connected, and click the OK button. 8. Check if the added server's name is selected on the server on the login screen. 9. On the login screen, click the Login button. 10.
Page 16: Menu Description
Execution Menu Description The menus in the SSM Console client program consist of tabs. You can freely move on the menu tabs to select the desired menu item. 1. To open a menu page, click the '+' in the upper left corner of the program and select the desired menu. 2.
Page 17 Please check “Product warranty information” from our website. https://www.hanwhavision.com/en/support/warranty/ Hanwha Vision cares for the environment at all product manufacturing stages, and is taking measures to provide customers with more environmentally friendly products. The Eco mark represents Hanwha Vision’s devotion to creating environmentally friendly products, and indicates that the product satisfies the EU RoHS Directive.
