Summary of Contents for SLS QTVDVD
- Page 1 OWNER’S & INSTRUCTION MANUAL Quick Touch Vault Drawer MODEL: Digital Drawer (QTVDVD) Digital + Bio Drawer (QTVDVDB) SURELOCK-SECURITY.COM...
-
Page 2: Attention
ATTENTION IMPORTANT! READ CAREFULLY, RETAIN FOR FUTURE REFERENCE. MANUAL MUST BE READ BEFORE OPERATING! NEVER keep backup keys in your safe! Do not store this document in your safe. Mount your safe in a secure location. Store a record of your combination and keys in a safe and secure location away from children. •... -
Page 3: Table Of Contents
TABLE OF CONTENTS Attention ........................2 Disclaimers ........................2 Parts & Specs .......................4 Introduction ........................5 Battery Installation ....................5 Battery Display .......................5 Opening Safe with the Backup Key ................6 Programming Code Resetting .......................6 Registering Fingerprints ..................7 Deleting Fingerprints ....................8 Keypad Sound ......................8 Backlit Keypad ......................8 Installation Safe Installation ......................8 Mounting Instructions .....................9... -
Page 4: Parts & Specs
6. Keypad Keys 3. Battery Display 7. Fingerprint Scanner* 4. Battery Compartment MODEL WEIGHT ASSEMBLED (WXDXH) 13.50x11.10x3.81 IN. QTVDVD/QTVDVDB 15.87 LBS / 7.20 KG 343x282x97 MM. BOX CONTENTS Safe & Attached Mounting Plate Backup Keys Mounting Screws Manual **Batteries Not Included (use new 4 - AA Batteries) -
Page 5: Introduction
INTRODUCTION The Surelock Quicktouch Vault is a biometric fingerprint access, code access, and key access safe. It provides secure storage for valuables such as firearms, ammunition, cash, and other personal items. The safe combines high security with complete quick access control with its solid construction and biometric technology. -
Page 6: Opening Safe With The Backup Key
OPENING SAFE WITH THE BACKUP KEY Locate the key hole at the back of the safe. Turn the key counter-clockwise to open the safe. Programming CODE RESETTING Default Code: 1234 1. With the vault open, press and hold down the 'PROGRAM' button for 5 seconds and immediately remove your finger once you hear a beep and all keypad keys light up once. -
Page 7: Registering Fingerprints
REGISTERING FINGERPRINTS 1. It is highly recommended that users should program a new vault code before registering fingerprints. To increase your success rate of registering a fingerprint, ensure that your hands are clean. Excessive moisture such as lotions or oils will affect your fingerprint and may cause inaccurate sensor readings. -
Page 8: Deleting Fingerprints
IMPORTANT • If all keys flash green 5 times with 5 beeps, it means registration has failed and you must repeat the above steps. • The safe can hold 20 fingerprints. If the light flashes 5 times with 10 beeps when trying to register your fingerprint, it means the fingerprint storage capacity is full. -
Page 9: Mounting Instructions
MOUNTING INSTRUCTIONS ON A DESK WITHOUT A MOUNTING PLATE 1. Open your safe and press the small handles on the outside of the drawer sliders. Slide out the drawer to separate from the safe base. 2. Unscrew the nuts that secure the plate to the bottom of the safe. - Page 10 4. Pull out the slide bar from the safe base and reconnect the drawer. 5. Place the safe on top of the desk. ON A DESK WITH A MOUNTING PLATE 1. Put the safe on the desk and mark the position of the plate.
- Page 11 2. Open your safe and press the small handles on the outside of the drawer sliders. Slide out the drawer to separate from the safe base. 3. Unscrew the nuts that secure the plate to the bottom of the safe. 4.
- Page 12 5. Attach the plate to the surface with six mounting screws that are provided. 6. Place the safe on the attached plate. 7. Replace the nuts to the plate attached bolts. 8. Pull out the slide bar from the safe base and reconnect the drawer.
- Page 13 UNDER A DESK WITH THE MOUNTING PLATE 1. Open your safe and press the small handles on the outside of the drawer sliders. Slide out the drawer to separate from the safe base. 2. Remove the bolted plate on top of the safe with an Allen Wrench.*Wrench not included.
- Page 14 4. Mark the position of the plate. 5. Attach the plate to the surface with six mounting screws that are provided. 6. Place the safe on the attached plate 7. Replace the nuts to the plate attached bolts.
-
Page 15: Care And Maintenance
CARE AND MAINTENANCE • Test your registered fingerprints every 6 months. • Keep liquids away from the control panel. • Place your safe in secure area. • DO NOT disassemble the product. Contact Customer Care for all repairs. • Use only NEW AA alkaline batteries. Fingerprint Scanner •... -
Page 16: Lifetime Warranty
LIFETIME WARRANTY SureLock Security Company (“SureLock”, “SureLock Security”, or “SureLock Security Co.”) cabinets, vaults and safes, manufactured by Dansons, carry a limited warranty from the date of sale by the original owner. The warranty coverage begins on the original date of purchase and proof of date of purchase, or copy of original bill of sale, is required to validate the warranty. - Page 17 Important DO NOT RETURN PRODUCT TO STORE For all questions, comments, or inquiries, please contact Dansons Customer Care department. USA: (480) 923-9637 service@surelock-security.com WARNING: THIS PRODUCT CAN EXPOSE YOU TO CHEMICALS INCLUDING DI (2-ETHYLHEXYL) PHTHALATE (DEHP) WHICH IS KNOWN TO THE STATE OF CALIFORNIA TO CAUSE CANCER AND BIRTH DEFECTS...
