- Page 1 Instruction Manual GH001-122G Customer Service: E-mail: fanmiservice@outlook.com...
-
Page 2: Close-Up View
Congratulations on choosing appliance, which you will find is dependable and easy to use. We recommend that you read this manual for best performance and to extend the life of your appliance. Thank you. Close-up View 1. Triple Ring Burner 2. -
Page 3: How To Use Your Gas Hob
How To Use Your Gas hob The position of the corresponding gas burner is indicated on each control knob. Gas Burners The burners are different in size and power. Choose the most appropriate one for the diameter of the cookware being used. -
Page 4: Practical Advice
On cooktops with automatic ignition, the end of the electronic ignition device must be cleaned carefully ● and frequently, making sure that the gas holes are not clogged; The electric hobs should be cleaned using a damp cloth ● and then rubbed with oil while still warm; Stainless steel can be stained if it remains in contact with highly calcareous water or aggressive ●... - Page 5 Always use cookware with a flat bottom and keep the lid on; ● When the contents come to a boil, turn the knob to "Low". ● Burner Ø Cookware diameter (cm) Triple Ring Burner 24 - 26 Semi-rapid Burner 16 - 20 To identify the type of burner, refer to the designs in the section entitled, "Burner and Nozzle Specifications".
-
Page 6: Is There A Problem
Use cookware the diameter of which is at least as large as the cooking area so that all of the heat produced by the heating element is used. Make sure that the bottom of tile pot is always dry and clean to insure good contact between the ●... -
Page 7: Installation Instructions For Built-In
The cookware is not stable. Check to make sure that: The bottom of the cookware is perfectly flat. ● The cookware is centered correctly on the burner or electric hot plate. ● The support grids have not been inverted. ● If, despite all of these checks, the cooktop does not function properly and problem persists, call the nearest Never call upon technicians not authorized by the manufacturer, and refuse to accept spare parts that are not original. - Page 8 Examples of ventilation holes for comburant air. Enlarging the ventilation slot between window and floor Fig.3 Fig.4 c) Intensive and prolonged use of the appliance may necessitate supplemental ventilation, e.g. opening a Window or increasing the power of the air intake system (if present). d) Liquefied petroleum gases are heavier than air and, as a result, settle downwards.
- Page 9 Fig.6 Hook position for Hook position for Hook position for H=30mm top H=40mm top H=20mm top N.B: Use the hook contained in the "accessories set" f) In the event the cooktop is not installed above a built-in oven, a wood panel must be inserted as insulation.This panel must be placed at least 20 mm from the bottom of the cooktop itself.
- Page 10 gas pressure conforms to the indications given in table 1 "Nozzle and burner characteristics". Connection to non-flexible tube (copper or steel) Connection to the gas source must be done in such a way as to not create any stress points at any part of the appliance.
-
Page 11: Burners And Nozzle Specifications
Burners and Nozzle Specifications Table1 G25.1 G2.350 Burner Therm Nozzle Thermal Nozz Thermal Nozzle Therma Nozzle Therma Nozzle Thermal Nozzle Nozzle Nozzle 1/100 power power 1/100 l power 1/100 l power 1/100 power 1/100 1/100 1/100 power (mm) 1/10 (mm) (mm) (mm) (mm) - Page 12 Valve adjustment Valve adjustment should be done with the control knob set at Burner ON saving flame position. Remove the knob, and adjust the flame with a tiny screwdriver (see fig.7 below). Fig.7 Checking the adjusted flame: heat the burner at full open position for 10 minutes. The turn the knob into the saving setting.
- Page 13 Nozzle Pressure Nominal Charge Reduced Charge Type of Burner diameter mbar 1/100mm kcal/h kcal/h Natural — 1.88 1617 0.60 Natural — 208.3 1.88 1617 0.60 Natural — 208.1 1.88 1617 0.60 G25.1 Natural — 218.5 1.88 1617 0.60 Semi-rapid Natural —...
- Page 14 Amzgachfktch Foshan Fanmi Home Technology Co., Ltd. Add: 11F-6, West of Building E, No. 6, Keyuan 3rd Rd., Xiaohuangpu Community, Ronggui St., Shunde Dist., Foshan, Guangdong...
