COMPASS HEALTH NEB-SOCCER User Manual

Compressor nebulizer
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
CAUTION-Federal (U.S.A.) law restricts this device to sale by, or on the order of a
physician.
Manufactured for Compass Health Brands.

Table of Contents

INTRODUCTION .....................................................................................................................2
IEC SYMBOLS .........................................................................................................................2
IMPORTANT SAFEGUARDS .................................................................................................3
WORK PRINCIPLE ..................................................................................................................4
COMPONENTS AND SUGGESTED USAGE LIFE ...............................................................5
GETTING STARTED ...............................................................................................................6
COMPRESSOR NEBULIZER CLEANING ............................................................................9
FILTER CHANGE ..................................................................................................................
MAINTENANCE ....................................................................................................................
SPECIFICATIONS ..................................................................................................................
TROUBLESHOOTING GUIDE ............................................................................................ 12
ELECTROMAGNETIC COMPATIBILITY ......................................................................... 13
Emissions test ......................................................................................................................... 14
Group 1 ................................................................................................................................... 14
...................................................................................................................... 14
...................................................................................................................... 15
Immunity test
WARRANTY...........................................................................................................................18
User Manual
Compressor Nebulizer
NEB-SOCCER
SOCCER-TRU
SOCCER-TRUWB-PB
..................................................................................... 17
10
10
11

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the NEB-SOCCER and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for COMPASS HEALTH NEB-SOCCER

Summary of Contents for COMPASS HEALTH NEB-SOCCER

  • Page 1: Table Of Contents

    Compressor Nebulizer NEB-SOCCER SOCCER-TRU SOCCER-TRUWB-PB CAUTION–Federal (U.S.A.) law restricts this device to sale by, or on the order of a physician. Manufactured for Compass Health Brands. Table of Contents INTRODUCTION ........................2 IEC SYMBOLS .........................2 IMPORTANT SAFEGUARDS ....................3 WORK PRINCIPLE ........................4 COMPONENTS AND SUGGESTED USAGE LIFE ...............5...

  • Page 2: Introduction

    INTRODUCTION The Soccer Ball Nebulizer Compressor System is a medical device designed to deliver medicine prescribed by a physician to the airways of the lungs. The Nebulizer Set and the Air Compressor combined provides aerosol mist for inhalation by the patient for medical treatment only.

  • Page 3: Important Safeguards

    IMPORTANT SAFEGUARDS When using electrical products, especially when children are present, basic safety precautions should always be followed. Read all instructions before using. Important information is highlighted by these terms: DANGER– Urgent safety information for hazards that will cause serious injury or death.

  • Page 4: Work Principle

    5. Keep the power cord away from heated surfaces. 6. Never block the air openings of the product or place it on a soft surface, such as a bed or couch, where the air openings may be blocked. Keep the air openings free of lint, hair, and the like.

  • Page 5: Components And Suggested Usage Life

    ILLUSTRATION OF PARTS Figure 1: Disposable Nebulizer NEB-SOCCER Components (Disposable Nebulizer components for Adults and Children 5 Years and Older) 1. Mouthpiece 2. Medication Cup 3. Connection Tubing 4. Tube Connector 5. Air Openings 6. Power Switch 7. Filter & Cover 8.

  • Page 6: Getting Started

    GETTING STARTED 1. Check to ensure the following components of the nebulizer are enclosed: • Compressor unit • Tubing and accessories (see pages 5 for illustration of parts) It is recommended to keep extra tubing, accessories and air filters on hand at all times in case original parts become lost, damaged, or soiled.
  • Page 7 7. If using the mask (optional), press it directly into the nebulizer cap (Figure 4). If using the mouthpiece, attach it firmly into the nebulizer cap. The cap is designed to fit tightly (Figure 4). Mask (optional) Figure 4 8. If using reusable jet nebulizer reference Figure 5 for instructions. Figure 5...
  • Page 8 Attach one end of the tubing firmly onto the air outlet on the back of the compressor unit. It is important that the tubing be pushed all the way onto the air outlet. The tubing is designed to fit tightly (Figure 6-1). 10.

  • Page 9: Compressor Nebulizer Cleaning

    OPERATION To operate the compressor Nebulizer, do the following: 1. Plug in the Compressor, but do not connect the Nebulizer Set. 2. Make sure that the air filter is attached to the Compressor. 3. Turn on the power switch. 4. After the Compressor runs properly for 1-2 minutes, connect the jet outlet of the Compressor to the inlet of the Nebulizer Set 5.

  • Page 10: Filter Change

    FILTER CHANGE Compass Part No. for Filter is CIF-NEB-5 1. Filter should be changed every 6 months or sooner if filter discolors. 2. Remove filter by grasping it firmly and pulling out of the unit. Discard old filter. 3. Replace with a new filter. Additional filters should be purchased from your Compass provider.

  • Page 11: Specifications

    NOTE–If the problem persists after the above basic maintenance, any further maintenance must be performed by a qualified Compass provider or authorized service center. Please refer to the contact information in the last page of this manual. DANGER–Electric shock hazard. Do not remove compressor cabinet. All disassembly and maintenance must be done by a qualified Compass provider.

  • Page 12: Troubleshooting Guide

    WARNING: Equipment not suitable for use in the presence of flammable anesthetic mixture with air or with oxygen or nitrous oxide. This product complies with the following electromagnetic compatibility standard: IEC 60601-1-2:2nd Edition. This is a home use desktop device and it is not intended to be used as a portable device.

  • Page 13: Electromagnetic Compatibility

    ELECTROMAGNETIC COMPATIBILITY The information contained in this section (such as separation distances) is in general specifically written with regard to Soccer Ball Nebulizer. The numbers provided will not guarantee faultless operation but should provide reasonable assurance of such. This information may not be applicable to other medical electrical equipment; older equipment may be particularly susceptible to interference.

  • Page 14: Guidance And Manufacturer´s Declaration - Electromagnetic Emission

    Electromagnetic Emissions This equipment is intended for use in the electromagnetic environment specified below. The user of this equipment should assure that is used in such an environment. Emissions Compliance Electromagnetic environment according to RF emissions (CISPR 11) Group 1 The equipment uses RF energy only for its internal function.

  • Page 15: Immunity Test

    power frequency 3 A/m 30 A/m Equipment which emits high magnetic field 50/60 Hz levels of power line magnetic (IEC 61000-4-8) fields (in excess of 30A/m) should be kept at a distance to reduce likelihood interference.. Warning keep Soccer Ball Nebulizer away from sources of high levels of power line magnetic fields (in excess of 30 A/m) to reduce the...
  • Page 16 Portable mobile communications equipment should be used no closer to any part of the, including cables, than the recommended separation distance calculated from equation applicable to the frequency of the transmitter as below. Conducted RF 3 V rms 150 kHz to 80 3 Vrms Recommended separation...

  • Page 17: Recommended Separation Distance

    NOTE 1 At 80 MHz and 800 MHz, the higher frequency range applies. NOTE 2 These guidelines may not apply in all situations. Electromagnetic propagation is affected by absorption and reflection from structures, objects and people. Field strengths from fixed transmitters, such as base stations for radio (cellular/cordless) telephones and land mobile radios, amateur radio, AM and FM radio broadcast and TV broadcast cannot be predicted theoretically with accuracy.
