Standing Desk Frame
Operator's Manual
WARNING:
Read carefully and understand all INSTRUCTIONS before operating. Failure to follow the
safety rules and other basic safe ty precautions may result in serious personal injury.
Save these instructions in a safe place and on hand so that they can be read when
required. Keep these instructions to assist in future servicing.
REV 1.0
Advertisement
Table of Contents
Related Manuals for Super Handy GUT153
Summary of Contents for Super Handy GUT153
- Page 1 Standing Desk Frame Operator’s Manual WARNING: Read carefully and understand all INSTRUCTIONS before operating. Failure to follow the safety rules and other basic safe ty precautions may result in serious personal injury. Save these instructions in a safe place and on hand so that they can be read when required.
-
Page 2: Safety Symbols
Read Operator’s Manual in its entirety. To reduce the risk of injury, user must read and understand operator’s manual before using this product. Safety Alert. Precautions that involve your safety. TECHNICAL SHEET SKU# GUT153 Input Voltage 110V AC, 60Hz Duty Cycle 10%, MAX. 2min. continuous motor cycling, 18min. off... -
Page 3: Parts List
PARTS LIST... - Page 4 A→Column × 2 B→Foot × 2 C→Foot pad × 4 D→L Steel × 2 E→Structural part × 2 F→Hook × 1 G→C Steel × 2 J→Power adapter × 1 K→Controller × 1 L→Power cord M→Connect Line × 1 O→Wheels × 4 P1→M6 ×...
-
Page 5: Tools Needed
TOOLS NEEDED M6 Allen Key (Included) Electric Drill (Not Included) Phillips Screw Driver (Not Included) ASSEMBLY Parts Needed Step 1: Install supporting frames. (See Fig.2) The table is not included in packaging. Adjusting the frame width according your table size. E→Structural part ×... - Page 6 Parts Needed Step 3: Install fixing plates at both sides. (See Fig.4) P2→M6×16 × 8 Fig.4 Parts Needed Step 4: Install desk foot and foot pads. (See Fig.5) Alternative B→Foot × 2 C→Foot pad × 4 P3→M6 × 35 × 8 O→Wheels ×...
- Page 7 Parts Needed Step 5: Install controller. (See Fig.6, Fig.7) K→Controller× 1 Fig.6 Q→ST4.2×19 × 2 Screw Driver Fig.7...
- Page 8 Parts Needed Parts Needed Step 8: Connect wires. (See Fig.8) Step 6: Connect wires. K→Controller× 1 A→Column × 2 A→Column × 2 J→Power adapter × 1 POWER POWER M→Connect Line× 1 Fig.8 S→Power cord× 1 Parts Needed Parts Needed Install Hook. (See Fig.9) Step 7: F→Hook ×...
-
Page 9: Operation
OPERATION 1. Control panel Fig.13 Fig.14 Topside (Fig.13) Backside (Fig.14) ꓥ: UP Key M1: Motor connector 1 V: DOWN Key DC: Power input connector S: SET Key M2: Motor connector 2 1: Memory height 1 2: Memory height 2 3: Memory height 3 2. -
Page 10: Troubleshooting
6. Reset your Standing Desk Memory Your Standing Desk can be reset back to the default factory setting by pressing and holding down both "ꓥ” and “ꓦ" keys for 10 seconds. Once a long buzzer sounds, the parameters are restored back to factory default settings, and the controller displays "RST". - Page 12 Great Circle USA Support Line: 1-866-493-0524 Email: help@greatcircleus.com www.greatcircleus.com www.greatcircleca.com Scan me to get more new products. Size: 210x285mm 157克双铜 REV 05/15/23...
Need help?
Do you have a question about the GUT153 and is the answer not in the manual?
Questions and answers
Superhandy standing desk stuck at bottom. display reads RST no matter which keys I hit. Held up and down buttons and still only RST. unplugged and got nothing.
To fix the Super Handy standing desk GUT153 that is stuck at the bottom and displays "RST," follow these steps:
1. Press and hold both the "ꓥ" (up) and "ꓦ" (down) keys for 10 seconds.
2. Wait until a long buzzer sounds, indicating the parameters have been restored to factory default settings.
3. The controller will display "RST."
4. Perform the calibration process as described in the manual.
This should reset the desk and allow it to function properly.
