Summary of Contents for Yokomo MASTER DRIFT MD 2.0
Page 2
走行してして下さい。 ① スピー ドコン トローラのスイッチをOFFにします。 ② バッテリーの接続を外します。 ③ 送信機のスイッチをOFFにし、 アンテナを縮めます。 Thank you for purchasing this Yokomo product. This high performance competition kit has been proudly manufactured by Yokomo - World Champion R/C car manufacturer. Proper assembly of this product will provide fun, safe enjoyment. PRECAUTIONS FOR SAFE ENJOYMENT OF YOUR R/C CAR For children under the age of 13, parental guidance is recommended when running. ■ ASSEMBLY PRECAUTIONS ■ ■ PRECAUTIONS BEFORE RUNNING ■ ■ BATTERY USAGE ■ ● Do not assemble around small children. The ● Yokomo R/C cars are built for competition use, and (Carefully read the instruction included with the batteries) parts can be dangerous if accidentally some models may exceed speeds of 40km per hour. ● When charging batteries, make sure that the swallowed. Practice common sense and run the car in open safe surrounding area is void of anything highly flammable. places, or R/C car tracks. ● Check the contents carefully before Also avoid charging in high-temperature locations. assembly. Please contact Customer Support ● Do not run the car on public roads with high amounts ...
Page 4
1. ギヤデフの組み立て Gear Diff Assembly Y2-503GHA / ZC-BH28TPA M2x8 タッピングビス BH Tapping Screw Y2-503GHA / ZC-BH28TPA M2x8 タッピングビス BH Tapping Screw ① ③ シリコンオイル #5,000 Silicon Oil Y2-501GGA ガスケット Gasket ガスケットや O リングには ④ ② ブラックグリス等を塗布する とシール性が向上します。 ①→②、 ③→④と対角線 Coating the gasket with に均等に締め込みます。 black grease will help Tighten equally in the provide a better seal. order of ①→② then ③→④. ★推奨アイテム CS-SLGA Y2-500GSAA シールグリス●860 ギヤデフ Gear Diff デフオイルを入れてご使用ください。 Please use it with differential oil.
Page 5
3. ギヤボックスの組み立て Gear Box Assembly MD-302BL R バルクヘッドリンク R Bulkhead Link MD-302AR R バルクヘッド・R R Bulkhead・R ZC-BH256A M2.5x6 ボタンヘッド BHS Screw BB-105-2A 5x10 ベアリング Bearing このページで使用するパーツ Parts used on this page ビス袋から必要に応じてお選びください。 Please choose from the screw bags as needed. ZC-BH256A M2.5x6 ボタンヘッド ×2 BHS Screw BB-105-2A ZC-BH36-A 5x10 ベアリング Y2-304SD2 M3x6 ボタンヘッド ×4 Bearing モーターマウント BHS Screw Motor Mount ZC-BH318A M3x18 ボタンヘッド ×3 BHS Screw ZC-BH318A 袋 #2 の内容 M3x18 ボタンヘッド...
Page 6
4. スパーギヤの取り付け Spur Gear Installation このページで使用するパーツ ZC-BH36-A Parts used on this page M3x6 ボタンヘッド BHS Screw Y4-630A ZC-SS34A スパーギヤハブ M3x4 セットスクリュー ×1 Spur Gear Hub Set Screw ZC-BH36-A SG-A4880A M3x6 ボタンヘッド×4 スパーギヤ 80T BHS Screw Spur Gear 袋 #2 の内容 ② Bag #2 Contents 平らな面 Flat side ① SG-A4880A スパーギヤ 80T ×1 Spur Gear Y2-631A ドライブピン Y4-630A Drive Pin スパーギヤハブ ×1 Spur Gear Hub ZC-SS34A M3x4 セットスクリュー ...
Page 7
6.ESC プレートの取り付け ESC Plate Installation MD-RET ESC トレイ ESC Tray ZC-F36-A M3x6 サラビス FHS Screw このページで使用するパーツ Parts used on this page ZC-F36-A M3x6 サラビス ×4 FHS Screw 袋 #3 の内容 Bag #3 Contents MD-RET ESC プレート ×1 ESC Tray 7. リヤサスアームマウントの組立て Rear Suspension Arm Mount Assembly ZC-BH38-A M3x8 ボタンヘッド 1° 0.5° 0° BHS Screw B11-B50A サスボール 取付位置によりトー角が変更できます。 Sus Ball MD-301AL The toe angle changes depending ...
Page 8
8. リヤサスアームの取り付け Rear Suspension Arm Installation MD-008SM リヤアームショックマウント Suspension Arm Shock Mount このページで使用するパーツ Parts used on this page ZC-BH256A MD-008RRC M2.5x6 ボタンヘッド ×4 リヤサスアーム R BHS Screw Rear Suspension Arm R 袋 #4 の内容 MD-008RLC Bag #4 Contents ZC-BH256A リヤサスアームL M2.5x6 ボタンヘッド Rear Suspension Arm L BHS Screw MD-008RLC リヤサスアームL ×1 Rear Suspension Arm L ① ① MD-008RRC リヤサスアーム R ×1 Rear Suspension Arm R ② 溝にはめ込む Attach to the groove. ZC-411A E リング・4 ㎜ MD-008SM E-ring リヤアームショックマウント ×2...
Page 9
10. リヤハブキャリアの取り付け Rear Hub Carrier Installation MD-008RH リヤサスピンホルダー Rear Suspension Pin Holder ④ SD-008SA スペーサー・グレー Spacer ・ Gray ② ③ BD-009AA アウターサスアームピン Outer Suspension Arm Pin ① ◆左側も同様に組立てます。 ◆ Assemble the left side in the same manner. ZC-BH256A M2.5x6 ボタンヘッド BHS Screw このページで使用するパーツ Parts used on this page ZC-BH256A M2.5x6 ボタンヘッド ×4 BHS Screw 袋 #5 の内容 Bag #5 Contents MD-008RH リヤサスピンホルダー ×2 Rear Suspension Pin Holder SD-008SA スペーサー・グレー ×4 Spacer ・ Gray BD-009AA アウターサスアームピン ×2 六角レンチ(1.5mm)...
Page 10
11. リヤ アッパーロッドの取り付け Rear Upper Rod Installation 片方が逆ネジになっています。 One side is reverse threaded. SD-TB27A 27㎜ターンバックル 27㎜ Turnbuckle Y2-207A ◆左側も同様に組立てます。 ◆ ボールエンドキャップ L Ball Cup Assemble the left side in the same manner. リヤアッパーロッド ×2 (27㎜ターンバックル ) Rear Upper Rod ×2 (27㎜ Turnbuckle) 14 ㎜ ※向きに注意 Note position B8-206LHA ロッドエンドボール L Ball Stud L ZC-A3620BA 2mm アルミスペーサー ・ 黒 2mm Aluminum Spacer ・ Black ※向きに注意 ZC-A3630BA Note position 3mm アルミスペーサー ・ 黒 3mm Aluminum Spacer ...
Page 11
12. スライドラックの組立て Slide Rack Assembly ZC-A3630BA 3mm アルミスペーサー ・ 黒 3mm Aluminum Spacer ・ Black ※向きに注意※ 溝を内方に固定します。 Note the position. Fix the groove inwards. Y2-202SCA ストッパー カム MD-202-1 Stopper Cam ラックレール Rack Rail B8-206SHSA ロッドエンドボール・首短 Rod End Ball・Short Neck BB-1140-2 4×11 ベアリング Bearing ZC-A3620BA B8-206SHSA 2mm アルミスペーサー ・ 黒 ロッドエンドボール・首短 ZC-A4610BA 2mm Aluminum Spacer ・ Black Rod End Ball・Short Neck φ4×φ6×1mm シム Shim B8-206SHA ロッドエンドボール...
Page 12
13. フロントバルクヘッドの組立て Front Bulkhead Assembly ZC-BH36-A M3x6 ボタンヘッド BHS Screw MD-302FMA フロント バルクヘッド -A Front Bulkhead-A B7-SS10A サスマウントスペーサー ・ 1.0 Sus-Mount Spacer ・ 1.0 B7-SS05A このページで使用するパーツ サスマウントスペーサー ・ 0.5 Parts used on this page Sus-Mount Spacer ・ 0.5 ZC-SS310A M3x10 セットスクリュー ×2 Set Screw ZC-BH310A ZC-BH36-A M3x10 ボタンヘッド M3x6 ボタンヘッド ×1 BHS Screw BHS Screw ZC-BH38-A M3x8 ボタンヘッド ×2 BHS Screw Y4-S8A ショックエンドボール...
Page 13
14. フロント サスアームの取り付け Front Suspension Arm Installation MD-0022 このページで使用するパーツ メイン シャシー ×1 Main Chassis Parts used on this page ※ボールエンド L は袋 #5 に入っています。 The ball ends are included in bag #5. ZC-F36-A M3x6 サラビス FHS Screw Y2-207A ボールエンドキャップ L×2 Ball Cup D-156-30AA ※向きに注意 MD-0022 ロアアームアダプター・30mm Note position メイン シャシー ×1 Lower Arm Adapter Main Chassis MD-008FL サスアームシャフトホルダー L Sus Arm Shaft Holder L ※向きに注意 ZC-SS34A Note position M3x4 セットスクリュー ×2 Y2-207A Set Screw ボールエンドキャップ...
Page 14
15. ベルクランク アームの組立て BB-105-2A ZC-A3625BA Bell Crank Arm Assembly 5x10 ベアリング 2.5mm アルミスペーサー ・ 黒 Bearing 2.5mm Aluminum Spacer ・ Black このページで使用するパーツ MD-202A Parts used on this page ベルクランク アーム ×1 Bell Crank Arm ※ボールエンド S は袋 #5 に入っています。 The ball ends are included in bag #5. B8-206MHA ZC-A3625BA ロッドエンドボール M 2.5mm アルミスペーサー ・ 黒 Ball Stud M 2.5mm Aluminum Spacer ・ Black Y2-207A ボールエンドキャップ S×2 Ball Cup B8-206MHA ロッドエンドボール...
Page 15
ZC-BH38-A M3x8 ボタンヘッド Servo Horn BHS Screw 刻印 メーカー 付属のサーボホーンには刻印が入っています。 Z4-200 ZC-BH310A Mark Manufacturer 使用するメーカーに合わせてお選び下さい。 サーボマウント ×2 M3x10 ボタンヘッド The included servo horns are marked フタバ / ヨコモ Servo Mount BHS Screw Futaba/Yokomo with a letter designating servo compatibility. サーボホーン取付けビスは使用する ハイテック Select the servo horn matching the サーボ付属のビスをご使用ください。 Hitec servo being used. The servo horn mounting screws B8-206SHSA サンワ /KO/JR ロッドエンドボール・首短 ×1 are not included, please use the Sanwa/KO/JR Rod End Ball・Short Neck screws in currently use. 18. サーボの取り付け ...
Page 16
19. ステアリング ロッドの取り付け Steering Rod Installation このページで使用するパーツ Parts used on this page ※ボールエンド L は袋 #5 に入っています。 The ball ends are included in bag #5. ステアリングロッド ×2 (20 ㎜ターンバックル ) Steering Rod ×2 (20 ㎜ Turnbuckle) Y2-207A Y2-207A ボールエンドキャップ M×4 ボールエンドキャップ M Ball Cup Ball Cup SD-TB20A 袋 #10 の内容 20 ㎜ターンバックル Bag #10 Contents 20 ㎜ Turnbuckle 片方が逆ネジになっています。 One side is reverse threaded. 10.2㎜ SD-TB20A ◆右側も同様に組立てます。 ◆ 20 ㎜ターンバックル ×2 Assemble the right side in the same manner.
Page 17
21. フロント バルクヘッドの取り付け Front Bulkhead Installation ◆右側も同様に組立てます。 ◆ Assemble the right side in the same manner. このページで使用するパーツ Parts used on this page ZC-BH254A M2.5x4 ボタンヘッド ×2 BHS Screw ZC-BH38-A ZC-BH254A ZC-BH38-A M3x8 ボタンヘッド M2.5x4 ボタンヘッド M3x8 ボタンヘッド ×2 BHS Screw BHS Screw BHS Screw 22. ベルクランク アッパー アダプターの取り付け ZC-BH36-A M3x6 ボタンヘッド Bell Crank Upper Adapter Installation BHS Screw ZC-BH310A M3x10 ボタンヘッド BHS Screw Y2-200U ベルクランク アッパー アダプター Bell Crank Upper Adapter このページで使用するパーツ Parts used on this page ZC-BH36-A M3x6 ボタンヘッド ×2 BHS Screw ZC-BH310A M3x10 ボタンヘッド ×1 BHS Screw 袋...
Page 18
23. ステアリング ブロックの取り付け B8-206SHA Steering Block Installation ロッドエンドボール S Ball Stud S Y2-010F-A このページで使用するパーツ フロントアクスル Front Axle Parts used on this page BB-105-2A ※ステアリングブロックは袋 #5 に入っています。 BB-105-2A 5x10 ベアリング The steering blocks are included in bag #5. 5x10 ベアリング Bearing Bearing Y2-415FR ステアリングブロック L Y2-415FR Steering Block L ステアリング ブロックL&R 各 1 Steering Block L&R 1Ea ※向きに注意 ZC-A3615BA Note position 1.5mm アルミスペーサー・黒 1.5mm Aluminum Spacer ・ Black ZC-C25NA M2x5 キャップスクリュー ×2 B8-206SHA SH Screw ロッドエンドボール...
Page 19
24. バンパーの取り付け Bumper Installation ZC-F36-A M3x6 サラビス FHS Screw MD-302S F シャシースペーサー MD-0012 F Chassis Spacer バンパー ×1 Bumper MD-302S F シャシースペーサー F Chassis Spacer このページで使用するパーツ Parts used on this page ZC-F36-A M3x6 サラビス ×4 FHS Screw 袋 #11 の内容 Bag #11 Contents MD-302S F シャシースペーサー ×2 F Chassis Spacer ZC-F36-A M3x6 サラビス MD-0012 FHS Screw バンパー ×1 Bumper 25. アッパー デッキ マウントの取り付け Upper Deck Mount Installation ZC-BH36-A M3x6 ボタンヘッド...
26. バッテリーホルダーの取り付け ZC-BH310A Battery Holder Installation M3×10 ボタンヘッド BHS Screw ZC-BH36-A M3x6 ボタンヘッド BHS Screw ZC-N25P MD-118-2 M2.5 ナット MD-118-4 バッテリーホルダー A バッテリーホルダーC Battery Holder A Battery Holder C ZC-F36-A MD-118-1 M3x6 サラビス YS-7BA BH スペーサー FHS Screw O リング BH Spacer O Ring MD-118-8 バッテリーストッパー Battery Stopper MD-118-6 BH ポスト BH Post MD-002BP バッテリープレート ...
Page 21
27. リヤ アセンブリーの取り付け Rear Assembly Installation ZC-F36-A M3x6 サラビス FHS Screw このページで使用するパーツ Parts used on this page ZC-F36-A M3x6 サラビス ×4 FHS Screw 28. アッパー デッキの取り付け Upper Deck Installation ZC-S37A φ3×φ7×0.5mm ワッシャー ZC-BH36-A Washer M3x6 ボタンヘッド BHS Screw BB-63-2A 3x6 ベアリング Bearing ZC-S310A φ3 ワッシャー Washer ZC-BH36-A M3x6 ボタンヘッド BHS Screw MD-003P アッパー デッキ ポスト Upper Deck Post MD-0032 アッパー デッキ Upper Deck このページで使用するパーツ Parts used on this page ZC-BH36-A M3x6 ボタンヘッド ×4 BHS Screw ZC-S37A ZC-F36-A φ3×φ7×0.5mm ...
Page 22
29. フロント&リヤショックの組み立て Front & Rear Shock Assembly Y2-S144A ショックピストン Y4-S4A Shock Piston ショックボディ Shock Body Y4-S4C アジャストナット Adjusting Nut このページで使用するパーツ Y4-S5A Y4-S5A Parts used on this page ショックシャフト E リング・2mm Shock Shaft E Ring YS-7HG2 YS-200B O リング(ブルー) ショックオイル #200 ×1 O Ring ( Blue ) Shock Oil Y4-S4C B7-S2BA O リング・ φ13 O リングカラー O Ring O Ring Collar 袋 #14 の内容 Bag #14 Contents Y4-S4C O リングキャップ ...
Page 23
30. フロント&リヤショックの取り付け ●FRONT● Front & Rear Shock Installation フロントショック Assy Front Shock Assembly ZC-206SHSA ロッドエンドボール S Ball Stud S フロントショック Assy Front Shock Assembly ZC-206SHSA ロッドエンドボール S Ball Stud S ●REAR● ZC-206SHSA ロッドエンドボール S Ball Stud S リヤショック Assy ZC-206SHSA Rear Shock Assembly ロッドエンドボール S 袋 #14 の内容 Ball Stud S Bag #14 Contents ZC-206SHSA ロッドエンドボール S ×4 六角レンチ(2.0mm) Ball Stud S Allen Key ( 2.0mm )
Page 24
31. 受信機、スピードコントローラーの取り付け Receiver,ESC Installation 受信機、スピードコントローラー、両面テープ (別途ご用意下さい。 ) Receiver and speed controller, Double-Sided Tape (Sold separately.) ZR-200GA アンテナパイプ Antenna Tube ZC-203BA 両面テープ Double-Sided Tape (別途ご用意下さい。) (Sold separately.) B9-204A アンテナマウント Antenna mount ZC-F36-A M3x6 サラビス FHS Screw ZC-203BA 両面テープ Double-Sided Tape (別途ご用意下さい。) (Sold separately.) このページで使用するパーツ Parts used on this page ZC-F36-A M3x6 サラビス ×1 FHS Screw 袋 #9の内容 Bag #9 Contents B9-204A アンテナマウント ×1 Antenna mount 袋 #15の内容 Bag #15 Contents ZR-200GA アンテナパイプ ×1...
Page 25
32. フロント ボディマウントの取り付け(ポスト式) Front Body Mount Installation(Post type) ボディマウントは使用するボディの高さに合わせて調整してください。 Adjust the position of the body mount according to the body use グレーの部分をカットしてください。 Please remove the gray shaded area. Y4-016A ボディマウント Body Mount Y4-016A ボディポスト Body Post このページで使用するパーツ Parts used on this page ZC-F310A M3x10 サラキャップ ×2 FHS Screw 袋 #15 の内容 Bag #15 Contents Y4-016A ZC-F310A ボディポスト ×2 M3x10 サラキャップ Body Post FHS Screw 32. フロント ボディマウントの 取り付け 別途ご用意下さい。 ZC-F36-A (プレート式) Sold separately. M3x6 サラビス FHS Screw Front Body Mount Installation MD-016MG (Plate type) フロント ボディマウント ステー ...
Page 26
33. マグネット式ボディ マウントの取り付け Magnet Type,Body Mount Installation ※部品構成/取り付け等は袋内の説明書を見て下さい。 Please see the instruction manual inside the bag for parts configuration/installation etc. Y2-016MGFA フロント マグネットボディマウント ●FRONT● Front magnet body mount 袋 #16 の内容 Bag #16 Contents カット カット ●REAR● Y2-016MGRA 袋 #17 の内容 リヤ マグネットボディマウント Bag #17 Contents Rear magnet body mount 六角レンチ(2.0mm) Allen Key ( 2.0mm )
34. モーターの取り付け Motor Installation モーター ( 別途ご用意下さい。) Motor ( Sold Separately. ) ZC-BH36-A M3x6 ボタンヘッド ZC-S37A BHS Screw ワッシャー Washer ギヤの噛み合わせは 0.3mm 程度ガタつくように合わせます。 ガタが多すぎるとギヤが破損しやすくなるためご注意下さい。 また、この間隔が狭すぎると異音が生じたり、駆動が重くなる ため調整は慎重に行ってください。 Adjust the meshing of the gears so that there is 平らな面 approximately 0.3mm of play in between the teeth. Be Flat side careful, as too much play will cause the gears to strip. Please adjust the gear mesh carefully, as insufficient clearance between the teeth will cause excessive gear noise, as well as causing a drag in the drivetrain. ZC-SS33A M3x3 セットスクリュー Set Screw ピニオンギヤ (別途ご用意下さい。 ) Pinion Gear (Sold separately.) ピニオンギヤをスパーギヤの歯幅に合わせて固定します。 Position the pinion gear so that the teeth line up with the spur gear, then secure it tightly. ☆ピニオンギヤは 19T 〜 38T まで装着できます。 Capable of fitting pinion gears from 19T to 38T.
Page 28
35. バッテリーの搭載 Battery Installation ※本製品はショートサイズ・Li-Po バッテリー ( 薄型 ) 専用になります。 For shorty Li-Po ( 1S-size ) battery use only. ② ① ショートサイズ ( 薄型 ) Li-Po バッテリー(別途ご用意下さい。) Short size (1S-size) Li-Po battery (Sold separately.)
Page 29
36.タイヤの組み立て、取り付け Tires Assembly, Wheel Installation ※タイヤ、ホイル、固定用テープは付属しておりません。 ※ 別途ご用意ください。 Tire and wheel, mounting tapes.( Sold separately ) ZR-DRT タイヤの内径はテーパーになっ タイヤ固定用テープ ています。 Tire Mounting Tape 内径の大きい方 ( 点のある側 ) から ホイルを押し込んで組み込みます。 Note that the tire has a tapered 丸い点 inner diameter. When mounting, push in the tire from the side with the larger diameter opening. 固定用テープをホイル ホイール 中央に貼ります。 Wheel Apply the mounting tape along the center of the wheel. ZR-DRA ( アスファルト向け ) TR-DRC( カーペット、 P タイル向け ) ドリフトタイヤ Drift Tire SD-011A M4 ナイロンナット...
