MV LINE BORA Installation Instructions

WARNING: the insect screen is provided with a low bottom rail; the 16 mm roller wheel under the handlebar is compatible with that bottom rail.
If you need to use Bora without the floor rail, it's necessary to replace the default roller wheel with the 20mm roller wheel (optional,
provided by request), when not expressly ordered with the flyscreen. Please follow replacement instructions carefully.
A
Remove both the screws from the
chain eyelet.
All the pictures represent the
internal view.
1
Insert the upper bayonet in the groove
of the upper rail.
NB: the bayonet fasten the profile,
so the insect screen will open on the
opposite side.
4
Fix the upper rail to the wall drilling
two holes.
INSTALLATION INSTRUCTIONS
HOW TO REMOVE AND REPLACE THE LOWER ROLLER WHEEL FOR BOTTOM RAIL
B
Unfasten the support and remove
the roller wheel.
We suggest this insect screen to be assembled by qualified staff only in compliance with the followings instructions.
Please use only screws or plugs suited for the specific wall where the screen should be installed. Assure that jambs are
parellel and right-angled; in case of out-of-squared jambs, please make them regular before to grant a parallel and right-
angled surface to the screen's profiles.
2
1
2
Insert the brushes in the upper rail.
WARNING: insert the brush nr. 3 in the internal side of the
rail, and the brush nr. 1 outside.
5
Place the upper bayonettes close to
the cap (the red pawl stands as a tem-
plate) then lock the grubscrews.
BORA
16mm
C
Replace the roller wheel.
1 2
15 17
5 9
3
20mm
D
Replace the support in the chain
eyelet and fix it.
3
19
5
3
Hook the caps to the upper
rail.
6
Hook the caps to the upper end of
both the side profiles.
A
A
B
B
C
C
