  • Page 1 CB U Misting S ystem U S E R MA N U A L...
  • Page 3: Table Of Contents

    TABLE OF CONTENTS 1. INTRODUCTION ............2. FUNCTION & SPECIFICATION ......... 3. NOZZLE SPEC. & APPLICATION ........4. ACCESSORIES ..............5. OPERATIONAL INFORMATION & SPEC ......6. BUBU MISTING SYSTEM FLOW CHART ......7. HOW QUICK CONNECTORS WORK ........ 8. INSTALLATION - A.
  • Page 4: Introduction

    As the fine mist droplets vaporize, 1cc of water is able to absorb 539 kJ of energy, thus effectively decreases environmental temperature. BUBU unites misting mechanics and outstanding Puricom components. It is compact, only 1/8 the size of traditional misting systems. It is environmentally friendly, quiet and power saving.
  • Page 5: Function & Specification

    FUNCTION 1. Temperature cooling The instant vaporization of fine water particles absorbs huge amount of latent heat and achieves rapid cooling. 2. Environment humidifying Humidity control helps reduce static electricity and other uncomfortable environmental conditions. 3. Advertising and special effects Misting system is an effective method for creating desirable atmosphere setting and stage effects.
  • Page 6: Nozzle Spec. & Application

    NOZZLE SPEC. & APPLICATION No.1 A050400005 0.15mm/0.006” Interior spaces Restaurants Kindergarten Playground Fruit and Veg. Greenhouse Exhibitions PRODUCT DESCRIPTION pump indicator outlet power switch inlet power cord REAR VIEW FRONT VIEW...
  • Page 7: Accessories

    ACCESSORIES Nail cable clips Tube cutter PE tubing - black,1/4" (1 packet) Drain valve Metal nozzle Diverter valve 5.1cm Wall-mount diagram Screws for wall PVC plastic plug mounting for wall mounting ) Optional accessories - Not included: - Dust, Sand and Hardness reduction prefilter. F L O W DIRT &...
  • Page 8: Operational Information & Spec

    OPERATIONAL INFORMATION Make sure power supply conforms with product specification. Do not place the unit in direct sunlight or damp environments. Do not use hot water ( > 40 ℃) with the system. Regular maintenance is prerequisite to ensure product reaches expected lifespan.
  • Page 9: Bubu Misting System Flow Chart

    BUBU MISTING SYSTEM FLOW CHART ※ Installation Index (Unit A -E)
  • Page 10: How Quick Connectors Work

    HOW QUICK CONNECTORS WORK To disconnect To connect Collet (Do not remove) Insert tubing Remove safety clip Push collet in Pull tube out 1. To remove tubing from the connector: Remove the safety clip from under the collet, push in the collet, and pull the tube out. 2.
  • Page 11: Installation

    INSTALLATION (Also refer to p. 6) A. Diverter Valve Assembly screw on push up 1. Screw the diverter valve onto the optional universal connector with chain - not included. The diverter valve can be directly connected to faucet. 2. Push up and lock chain. 3.
  • Page 12: Optional Prefilter Installation

    B. Optional Prefilter Installation Drill a 6mm hole for each bracket 2. Hammer in PVC plugs. 3. Screw the brackets onto the PVC plugs. Wind seal tape on the elbow connectors. Note to wind seal tape in the direction of thread. Screw the elbow connectors onto the IN and OUT of prefilter.
  • Page 13: Unit Body Installation

    C. Unit Body Installation Use the wall-mount diagram to mark installation position. Drill 6mm holes. 3. Hammer in PVC plugs. Use a screwdriver to screw the screw into the PVC plug. The screw protrusion must be uniform 10mm) to avoid damage to unit body.
  • Page 14 5. Hang the BUBU unit body. 6. Connect the outlet PE tube from the prefilter to the inlet of the unit body. 7. Connect a PE tube to the outlet of the unit body. 8. Install a tee connector on the outlet nylon tube of the unit body. 9.
  • Page 15: Time Control Box Installation

    D. Timer Control Box Installation (for optional) 1. Drill 6mm holes. 2. Hammer in PVC plugs. 3. Use a screwdriver to screw the screw into the PVC plug. The screw protru- sion must be uniform ( 10mm) to avoid damage to time control box. Connect the power cords of BUBU unit body and time control box.
  • Page 16: Start-Up

    START-UP 1. Turn on the diverter valve. 2. Plug in power. ◦ 3. Turn on time control box and BUBU unit body power - 4. Set spray/interval time. See p.13 for spray/ interval time setting. 5. Enjoy BUBU misting system. 6.
  • Page 17: Spray Nozzle Technical Information

    SPRAY NOZZLE TECHNICAL INFORMATION A. Spray Nozzle Quantity V.S. Outlet Water Pressure (Inlet water pressure 20psi) Nozzle(pcs) 165 165 160 160 160 160 160 160 155 155 155 Nozzles ( pcs ) B. Outlet Water Pressure V.S. Nozzle Flow Rate (Unit: cc/min., Inlet water pressure 20psi) Outlet water pressure ( PSI )
  • Page 18: Troubleshooting

    TROUBLESHOOTING Problem Inspection Point Solution Clean or Replace 1.Check for blockage in No water or very nozzles and tubes. nozzle and / or tubing. little water coming 2.Check pump output water See solution for out of nozzle “Insufficient pump outlet pressure.
