Pulsar XT Manual

2019-2023 ram 5.7l
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
2019-2023 Ram 5.7L

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the XT and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Pulsar XT

  • Page 1 2019-2023 Ram 5.7L...

  • Page 2: Table Of Contents

    This product requires a Mobile App to function correctly. Scan this QR code or visit the link below to find download options for your smartphone. You can also find other useful information and instructions about the Pulsar XT on our website. https://www.holley.com/products/tuners_and_programmers/inline_tuning_modules/pulsar_xt/...

  • Page 3: Read Me

    Read Me Safety Warning & Caution Throughout this User Manual you will see important messages regarding your safety or the protection of your vehicle. These messages are designated by the words WARNING, CAUTION, or NOTICE. WARNING A WARNING indicates a hazardous situation which, if not avoided, will result in death or serious injury.

  • Page 4: Safety Guidelines

    Safety Guidelines WARNING Before using device, read and understand the user manual, including these additional safety instructions. Failure to do so could result in DEATH or SERIOUS INJURY. • Do not exceed legal speed limits on public roadways. Violating traffic laws is dangerous and could result in injury or vehicle damage or both.

  • Page 5: Fcc & Industry Canada Compliance

    FCC & Industry Canada Compliance MODEL: Parallax FCC ID: 2AA9B05 IC: 12208A-05 This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

  • Page 6: Installation Of Pulsar Xt 19-23 Ram 5.7L

    Installation of Pulsar XT 19-23 Ram 1500 Materials Accelerator Pedal Position Sensor Pulsar XT Harness (APP) Pulsar XT Connector Connector 12V Power Wire Velcro 10A Fuse Link Zip Ties Pulsar XT Module Required Tools 7mm & 10mm Sockets/Wrench Pick Tool...

  • Page 7: Pulsar Xt Installation

    Pulsar XT Installation STEP 1 - To prevent causing trouble codes, disconnect the negative terminal on the battery using a 10mm socket and socket wrench.
  • Page 8 Pulsar XT Installation Cont’d STEP 2 - Remove the two 7mm bolts on the bottom of the lower dash panel.
  • Page 9 Pulsar XT Installation Cont’d STEP 3 - Pull the lower dash panel while out being careful not to break the plastic clips. See image for plastic clip locations. STEP 4 - To make the CAN junction box more accessible, use a trim tool to carefully work around the 6 clips on the lighting switch panel.
  • Page 10 Pulsar XT Installation Cont’d STEP 5 - Route the CAN connector to the junction box located on the driver’s side of the dashboard. Plug into any open port of the green junction box. Junction Harness UNDER VIEW UNDER VIEW Junction...
  • Page 11 Pulsar XT Installation Cont’d STEP 7 - Connect the 10-amp leaded fuse to the 12V Power Wire on the Pulsar XT harness, then remove the factory 10-amp fuse from F33 (The fuse numbers will be labeled above each fuse). Then install the leaded fuse into fuse location F33 making sure to...
  • Page 12 Connect both sides into the Pulsar XT harness. STEP 9 - Connect the Pulsar XT module into the Pulsar XT Connector and mount it behind the lower dash panel and secure it to the dashboard brace.

  • Page 13: Pedal Sensitivity Levels

    Pedal Sensitivity Levels Steering Wheel Controls With cruise control off, the Pulsar XT is controlled using the Cruise Control buttons. Steering Wheel Controls Function RES+ Level Up SET- Level Down CANCEL View Level Pedal Sensitivity Levels Setup Dash Option A...
  • Page 14 Exit STEP 4 - Scroll through the MUSIC OFF available options Center and select the Audio option. Trip B Distance (The Pulsar XT Audio device utilizes Menu Title your radio’s Press OK to Select communication to Exit signals to...

  • Page 15: Changing Pedal Sensitivity Level

    Pedal Sensitivity Levels Setup Cont’d Dash Option A STEP 1 - To change the pedal sensitivty level, use the RES+ and SET- buttons while cruise 105.9 KNRS Speedometer control is off. The level will briefly appear then Vehicle Info Fuel Economy disappear in the 8878.5mi radio station slot.

  • Page 16: Faqs

    Fix 1: Double check all Pulsar XT connections, and make sure all connections are fully making contact. Fix 2: If codes are still coming up, use the Pulsar XT app to read and clear codes, and then drive the vehicle to see if they come back up.
  • Page 17 PAGE INTENTIONALLY LEFT BLANK...
  • Page 18 PAGE INTENTIONALLY LEFT BLANK...
  • Page 19 PAGE INTENTIONALLY LEFT BLANK...
  • Page 20 For additional questions not found in the user guide, call: Holley Technical Support: (888)-360-3343 Mon - Fri 8:00 am - 5:00 pm MST, Sat 8:00 am - 2:00 pm MST To expedite your support call, please have your Vehicle Information, Part Number, and Serial Number ready prior to calling Technical Support.
