Bath Royale Round BR500 Installation Instructions Manual

Bath Royale Round BR500 Installation Instructions Manual

Executive toilet seat with slow close & quick release

Advertisement

Quick Links

Tools Required:

Phillips Head Screwdriver
Tape Measure or Ruler
Installation is not difficult, but it is VERY DIFFERENT from other seats. Please follow these
instructions step-by-step. (Video available at BathRoyale.com).
MISSING PARTS? Please do not return your seat. Call (704) 589-1009 or email
NOTE: Toilet bowls without access to nuts under seat require top mount anchors sold
separately at BathRoyale.com
info@BathRoyale.com for replacement parts.

Parts List

Questions? Visit BathRoyale.com or call (704) 589-1009
Models: BR500 Round / BR501 Elongated
Toilet seat with lid (1)
Note: Seat must be installed for Slow Close
to work.
Mounting base covers (2)
Note: Stainless steel covers are available
at BathRoyale.com
Stainless steel screws (2)
Stainless steel mounting bases with post
and silicone rubber seal on bottom (2)
Gray split wing nuts (2)
Note: DO NOT turn wing nuts (see page 2)
Executive Toilet Seat with
Slow Close & Quick Release
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Round BR500 and is the answer not in the manual?

Questions and answers

Summary of Contents for Bath Royale Round BR500

  • Page 1 Installation Instructions Models: BR500 Round / BR501 Elongated Tools Required: Executive Toilet Seat with Phillips Head Screwdriver Slow Close & Quick Release Tape Measure or Ruler Installation is not difficult, but it is VERY DIFFERENT from other seats. Please follow these instructions step-by-step.
  • Page 2 Installation Instructions Important: Mounting surface of toilet must be flat, clean and dry with no chemical residue. To prepare mounting surface, we recommend using Windex® (or any glass cleaner) around the mounting holes of the toilet to get the mounting surface squeaky clean. 1.
  • Page 3 Tap forward and let the seat and lid close by themselves. Tip: It is OK to push the seat and lid closed. Unlike other Slow-Close seats, Bath Royale® seats can be force-closed repeatedly, without damaging the Slow-Close mechanism. Closing too slow? Push it closed.
  • Page 4 Installation Instructions 6. Adjust Seat With the lid closed, align seat with bowl by moving the seat and mounting bases together. Tip: Lift mounting bases to unstick from bowl (loosen screws if necessary). We recommend installing the seat overhanging the front of the bowl by ¼...
  • Page 5 Installation Instructions 9. Place mounting base covers on mounting bases. 10. Replace seat. Align holes with mounting posts and carefully lower seat onto posts. Tip: Push down and jiggle, making sure both posts are completely inserted. (If difficult, re-check alignment of posts and holes). Tip: Practice removing seat (Step 8) and replacing seat (Step 10).
  • Page 6 88530-D 10.08.2020 © 2020 Marcobelle Company. All Rights Reserved...
