Summary of Contents for MECH MIND IPC ADV Series
- Page 1 Mech-Mind IPC ADV User Manual...
-
Page 2: Table Of Contents
Table of Contents Preface................. ... -
Page 3: Preface
Mech-Mind IPC ADV User Manual Preface This user manual applies to the industrial PCs (IPCs) of the Mech-Mind IPC ADV model. The IPCs of the Mech-Mind IPC ADV model can be purchased with the following order numbers: • IPCW-i5-16G-512G-1660S-EU • IPCW-i5-16G-512G-1660S-US •... -
Page 4: Safety Instructions
• The precautions outlined in this section shall be strictly observed. Failure to follow these precautions may result in damage to the Mech-Mind IPC ADV series. 1.1. General Safety Precautions Follow the safety precautions outlined below: •... -
Page 5: Certification
Mech-Mind IPC ADV User Manual 2. Certification The Mech-Mind IPC ADV series is compliant with the following standards and assessment requirements. Please note that the registration statuses may be updated. If you need more information, please contact the local agents. - Page 6 Mech-Mind IPC ADV User Manual This equipment has been assembled with components that comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
-
Page 7: Technical Specifications
Mech-Mind IPC ADV User Manual 3. Technical Specifications Model Mech-Mind IPC ADV Configuration Intel Core i5-12400 2.5GHz (6 cores) Chipset Intel® H610 Memory 16 GB SO-DIMM DDR4 3200MHz (supports up to 64 GB) GPU card GeForce® GTX 1660S Storage 512 GB SSD Operating system Windows 10 IoT Enterprise LTSC 2021 Wireless network... - Page 8 Mech-Mind IPC ADV User Manual Model Mech-Mind IPC ADV Operating temperature: -30°C to 70°C; humidity: 5% to 95%; non- Storage environment condensing Safety & Certification Certification CE/FCC Warranty Warranty period One year © 2023 Mech-Mind Robotics Technologies Ltd.
-
Page 9: Product Overview
GeForce® GTX 1660S GPU card, and supports operating in -10°C to 60°C. 4.2. Product Views 4.2.1. Front View The following figure shows the front panel of the Mech-Mind IPC ADV series and the interfaces on Description Description POWER LED... -
Page 10: Mechanical Dimensions & Mounting Holes
Mech-Mind IPC ADV User Manual Description Description POWER switch Power connector 2 x RS232/422/485 1 x DP port 1 x Intel I219LM GbE, 1 x Intel I225v 2.5 1 x HDMI port 2 x USB 3.2 GEN1 2 x USB 3.2 GEN2 4 x USB 2.0 1 x iDPM slot 4.3. -
Page 11: Installation
If some of the components listed in the checklist below are missing, please do not proceed with NOTE the installation and contact Mech-Mind Technical Support. The Mech-Mind IPC ADV series is shipped with the following components: Item Quantity Schematic diagram... -
Page 12: Installation Precautions
Electric shock and personal injury might occur if the rear panel of the Mech-Mind IPC ADV series is opened while the power cord is still connected to an electrical outlet. - Page 13 Mech-Mind IPC ADV User Manual 3. Align the mounting holes in the front of the handlers with the mounting holes on a rack. 4. Use eight screws to secure the system to the rack. © 2023 Mech-Mind Robotics Technologies Ltd.
-
Page 14: External Interface Description
Mech-Mind IPC ADV User Manual 6. External Interface Description 6.1. Power Connector There is one power connector on the rear panel. The power connector is a 3-pin terminal that can directly connect to a power supply through the power cord. The supported power input voltages are 100 V to 240 V. -
Page 15: Digital I/O Connector
Mech-Mind IPC ADV User Manual Each Ethernet port on the IPC has two status light-emitting diodes (LEDs), one green and one yellow. The yellow LED indicates the link status or the activity of the port and the green LED indicates the connection speed of the port. The following table shows the LED status of the I225V 2.5 GbE Ethernet port. - Page 16 Mech-Mind IPC ADV User Manual Pin No. RS232 RS422 RS485 TXD422+ TXD485+ RXD422+ RXD422- © 2023 Mech-Mind Robotics Technologies Ltd.
-
Page 17: Maintenance And Cleaning
When maintaining or cleaning the Mech-Mind IPC ADV series, please follow the guidelines below. 7.1. Cleaning Precautions Prior to cleaning any part or component of the Mech-Mind IPC ADV series, please read the details below. • The interior of the Mech-Mind IPC ADV series does not require cleaning. Keep fluids away from the Mech-Mind IPC ADV series interior. -
Page 18: Troubleshooting
Mech-Mind IPC ADV User Manual 8. Troubleshooting Symptom Solution Please follow the steps below to re-install the operating system. 1. Please go to “Production Interface→ Maintenance → Blue screen appeared frequently on Backup management”, create a backup of the current solution, and copy it to your storage medium. -
Page 19: Support
Mech-Mind IPC ADV User Manual 9. Obtain Support If you need technical support, please contact Mech-Mind Technical Support in any of the following means: • Email: service@mech-mind.net • Community: community.mech-mind.com © 2023 Mech-Mind Robotics Technologies Ltd. -
Page 20: Appendix A: Error Beep Codes During Start
Mech-Mind IPC ADV User Manual Appendix A: Error Beep Codes During Start A.1. PEI Beep Codes Number of Beeps Description Memory not Installed. Memory was installed twice. (InstallPeiMemory routine in PEI Core called twice) Recovery started. DXEIPL was not found. DXE Core Firmware Volume was not found. -
Page 21: Appendix B: Hazardous Material Disclosure
Mech-Mind IPC ADV User Manual Appendix B: Hazardous Material Disclosure The details provided in this appendix are to ensure that the product is compliant with the RoHS II Directive (2015/863/EU). The table below acknowledges the presence of small quantities of certain substances in the product and applies to RoHS II Directive (2015/863/EU).
