Summary of Contents for ZEN ROVE
- Page 1 ROVE Aroma Atomiser with Nano-mist technology Create Zen on the Go®...
-
Page 2: Table Of Contents
B. TECHNICAL SPECIFICATION C. OPERATING INSTRUCTIONS D. FEATURES E. MAINTENANCE F. TROUBLESHOOTING G. WARRANTY Congratulations on purchasing your MADE BY ZEN® Rove Aroma Atomiser. Please keep this manual to help you get the most out of your Rove and for maintenance. -
Page 3: About The Rove
Easy to use, super sleek and portable. Perfect for any space that needs a powerful burst of scent and aromatherapy. Rove is ideal for use with pure essential oils to achieve the perfect wellbeing moment. Rechargeable, up to... - Page 4 B - TECHNICAL SPECIFICATIONS Model Name: Rove Aroma Atomiser Model No: EW10005A Product Size: Φ69 x 120mm 1 2 0 m i n m i n m i n Voltage: DC 5V (3.7V Lithium Ion Battery) Power: 5W Adaptor: 5V/1A USB...
- Page 5 You can also use the cable provided with a 5V/1A USB adaptor, which must be purchased separately. 2. The Rove Aroma Atomiser is not suitable to be charged in a vehicle. Please note the Rove operates with a 3.7V lithium-ion rechargeable battery, many vehicles operate at 12V, which will damage the product.
- Page 6 16. Keep away from open flames, extended exposure may create risk of explosion. Store at room temperature. Do not use this product when temperature is too high or too low, <10˚C >40˚C. 17. Always check with your airline before travelling with Rove on an aircraft.
-
Page 7: Operating Instructions
Alternatively, decant the essential or fragrance oil directly into the empty oil bottle provided. Note the Rove is compatible with 5ml, 10ml and 15ml oil bottles, simply change the oil pipette to the correct length depending on the bottle size. The oil pipette should remain in a straight vertical position and not bend inside the bottle (additional oil pipettes provided). - Page 8 30min 60min 90min or refill the Rove during operation. If any oil is drained into the air pump through incorrect use, this will damage the air pump and cause permanent damage to the product.
- Page 9 > Press again for 90 minute timer > Press again to switch off the timer setting, the Rove will continue to scent at the chosen intensity Auto shut off after 30 minutes level until switched off. Auto shut off after...
- Page 10 CHARGING button will flash repeatedly to indicate the Rove needs to be charged. Please note when using the timer setting, the button will not flash, the Rove will simply switch off when the battery is fully discharged. 1. Plug the cable into the USB socket before connecting to the 5V/1A USB power point or 5V/1A adaptor (not included).
-
Page 11: Features
D - FEATURES The Rove Aroma Atomiser provides a revolutionary way to fragrance your surroundings. Nano-mist technology releases potent particles of beautiful scent direct from the oil bottle without the need for water or heat. Powerful scenting for effortless aromatherapy and wellbeing. -
Page 12: Maintenance
E - MAINTENANCE Please ensure the Rove is switched off and not connected to the power source. 1. Release the diffusion head by firmly pressing the oil bottle upwards from the base. 2. Unscrew the oil bottle and decant any remaining oil from the bottle. - Page 13 4. Unscrew the oil bottle and pour out any remaining alcohol. Wipe the diffusion head and oil pipette with a clean, soft cloth and leave to dry. CHANGING ATOMISATION CORE Remove the diffusion head and oil bottle following maintenance steps 1 & 2. 1.
- Page 14 4. Replace with new atomisation core, using the replacement tool. We suggest you clean the Rove after using a full oil bottle or when changing to a new scent as this will prevent scent contamination. If the oil bottle still contains oil, please decant before adding the alcohol as per instructions in the maintenance section.
-
Page 15: Troubleshooting
F - TROUBLESHOOTING Problem Possible Cause Solution Unit will not Plug the USB cable into a 5V/1A power source switch on to charge the unit. Or use a 5V/1A power The unit needs to be adaptor to plug into mains power source. The charged power button will flash to indicate the unit is charging... -
Page 16: Warranty
Electronic waste needs to be separated from other waste to be recycled properly. When the Rove Aroma Atomiser reaches the end of its working life, please deposit at an appropriate collection point for recycling of electrical products.
