PJD6220-3D
120Hz DLP ® Projector
Optional Accessories
>Replacement lamp
>Universal ceiling mount kit
>Wireless G presentation gateway
>2nd & 3rd year extended warranty PRJ-EE-03-03
Projection Distance Screen Size (for 4:3 aspect
16:10 Screen ratio diagonal length)
m feet Wide (inches) Tele (inches)
1.2 3.94 30.08
2 6.56 49.96
3 9.84 74.94
5 16.4 124.9
10 32.81 249.8
Sales: (888) 881-8781 . SalesInfo@ViewSonic.com . ViewSonic.com
*Running eco-mode exclusively can extend lamp life. See ViewSonic.com for full Express Exchange details. Specifications subject to change without notice. Selection, offers and programs may vary by country; see your
ViewSonic representative for complete details. Corporate names, trademarks stated herein are the property of their respective companies. Copyright © 2009 ViewSonic Corporation. All rights reserved [14260-00B-12/08]
PJD6220-3D-1
For more product information, visit us on the web at ViewSonic.com
DISPLAY
AUDIO
INPUT SIGNAL
COMPATIBILITY
CONNECTOR
RLC-034
WMK-005
WPG-150
POWER
LANGUAGE
CONTROLS
27.34
45.57
68.35
113.92
227.83
OPERATING
CONDITION
NOISE LEVEL
DIMENSIONS
(W x D x H)
WEIGHT
REGULATIONS
PACKAGE CONTENTS
WARRANTY
Type 0.55" Digital Micromirror Device (DLP™)
Resolution XGA 1024×768 (Native) / SXGA+ 1440×1050 (compressed)
Lens 1.1× Manual optical zoom / Manual optical focus
Keystone Vertical +/-30
Size 30"-300" / 0.8m-7.6m
Throw Distance 1.2m-10m / 4.0ft-32.8ft / 47.2"-393.7"
Throw Ratio 1.97:1-2.16:1
Lamp 180 watt (RLC-034)
Lamp Life 3500 / 4000 (hours)
(Normal / Eco Mode)
Brightness 2,200 lumens
Contrast Ratio 2000:1 (typ)
Aspect Ratio 4:3 (native) & 16:9
Color Gamut 85% NTSC (CIE 1931)
Speaker 2 × 5W
Computer and video NTSC M (3.58 MHz), NTSC 4.43MHz, PAL (B, D, G, H, I, M, N, 60), SECAM (B,
D, G, K, K1, L), SD 480i and 576i, ED 480p and 576p, HD 720p and 1080i
Frequency Fh: 15-100 KHz, Fv: 43-120 Hz
PC VGA to SXGA+ 1440×1050
Mac Up to 1152×864 (may require Mac Adapter)
RGB Input 2 × 15-pin mini D-sub
RGB Output 1 × 15-pin mini D-sub
Composite Input 1 × RCA jack
S-Video Input 1 × 4-pin mini-DIN
Audio Input 1 × 3.5mm mini jack
Audio Output 1 × 3.5mm mini jack
Control 1 × RS-232 (6 Pin D-sub)
USB 1 × USB Type B (mouse and firmware upgrade only)
Network Control RJ-45
Voltage 100~240VAC(Auto Switching), 50/60Hz (universal)
Consumption 265W (Typical) / 225W (ECO) <9W (Stand-by)
English, French, Deutsch/German, Spanish, Italian, Portuguese, Russian,
Japanese, Korean, Traditional chinese, Simplified Chinese
Basic Standby/On, input, menu
OSD Picture: Brightness, contrast, color setting, keystone, aspect ratio, image,
white intensity, gamma, 3D sync, 3D sync invert
Computer image: Frequency, tracking, h position, v position
Video image: Color, sharpness, tint
Sound: Volume, mute
Setting: Menu position, projection, signal type, lamp counter, lamp counter
reset, power saving, auto source, eco mode, high altitude, OSD timeout
Option: Blank screen, start-up screen, screen capture, password, dcr,
closed caption, network control, brilliant color
Network config: Dhcp, IP address, subnet mask, gateway
Factory default
Temperature 32ºF-104ºF (0ºC-40ºC)
Humidity 10% - 80% (non-condensing)
Altitude 0 ~10,000 ft (3,048 m)
Normal / Eco Mode 36dB / 34dB
Physical 8.93 × 8.77 × 4.3 (in) / 271 × 223 × 110 (mm)
Packaging 14.5 × 9.6 × 11.6 (in) / 369 × 244 × 296 (mm)
Net 6.55 lb (2.97 kg )
CB, UL/cUL, FCC-B, ICES-003, IRAM, NOM, CE, TUV/GS, GOST-R,
Hygienic, SASO, UKrSEPRO, CCC, C-tick, EK
ViewSonic projector, Power cable, VGA cable, Remote control with batteries,
Composite cable, S-video cable, Soft carrying case, Lens cap, Quick Start
Guide, ViewSonic Wizard CD (with User Guide), VGA-component adapter
3-year limited warranty on parts, 1-year limited warranty on lamp, 1st year
Express Exchange
Model No.VS11949
®
service.
