Summary of Contents for HSA SYSTEMS HS-2000
- Page 1 SIMATIC HMI) Huasheng Automation ____________________ HS-2000 Multi-channel pulse controller Usage Guide Version 01/2021...
- Page 2 Safety technology tips For your personal safety and to avoid damage to your property, you must pay attention to the tips in this manual. Tips for personal safety are indicated by a warning triangle, while tips related to property damage only are without a warning triangle.
- Page 3 Qualified Professional Installation and driving of ancillary equipment or systems related to this document is only permitted. Commissioning and operation of equipment or systems is only permitted to be performed by qualified professionals. Qualified professionals for the purposes of the safety technical tips in this document are persons qualified to perform the operation, grounding and marking of equipment, systems and circuits in accordance with the safety technical standards.
- Page 4 Use of manual This manual applies to the 16-channel AC and DC versions of the HS-2000 multi- channel pulse controller, the 220AC input version (order number: 6HSA-2000-220/24- 16) and the 24VDC input version (order number: 6HSA-2000-24/24-16), as well as the...
-
Page 5: Table Of Contents
Catalog 1 Overview................................ 1-1 2 Shipping............................... ..2-1 3 Installation..............................3-1 4 Electrical connections..........................4-1 5 Communication function description....................5-1 6 Parameter setting............................6-1 7 Structural and Electrical Specifications ....................7-1 A Appendix................................A-1... -
Page 6: Overview
Ash cleaning of each chamber in turn, from the first chamber to the start of the next ash cleaning for an ash cleaning. HS-2000 controller is widely used in dust removal and ash cleaning system in kiln, cement vertical kiln, mining, pharmaceutical, food and other industries. And other applications using multi-point cycle control system. -
Page 7: Shipping
1.2 The working principle and parameters of the instrument Pulse width：Duration of each drive voltage； Pulse interval: the interval time between the output two adjacent drive voltages； Pulse lifting interval: the time to wait for the completion of the action of the poppet valve (lifting interval), and also the time to wait for the poppet valve to close after the output of the pulse valve in the same chamber；... -
Page 8: Installation
The HS-2000 multi-channel pulse controller is designed for easy installation. The HS-2000 can be mounted on a panel or standard rail, and the HS-2000 can be mounted horizontally or vertically. the small size of the HS-2000 allows users to make efficient use of space. - Page 9 Allow enough clearance for cooling and wiring The HS-2000 is designed to be cooled by natural convection. To ensure proper cooling, a clearance of at least 25 mm must be left above and below the unit. In addition, a minimum depth of 25 mm should be left between the front of the module and the inner wall of the cabinet.
-
Page 10: Electrical Connections
Electrical connection 4.1Wiring Diagram The operation enable terminal can be connected to a differential pressure sensor for automatic differential pressure control of ash cleaning. If the sensor is not used, the enable terminal can be shorted or the operation can be controlled by other dry contact. The function of each point varies depending on the configuration of the parameters：... - Page 11 Beware Since the controller comes with its own power supply, the common terminals of multiple controllers cannot be connected together. The output of each control can only form a loop with its own common terminal, otherwise the power supply may be damaged. For example, as shown in the diagram above, the common of 1-16 must be connected to the host, common 2 of 17-32 to expansion #1, common 3 of 33-48 to expansion #2, and so on.
- Page 12 Function Description 5.1 This machine provides 2 communication modes: cascade communication and RS485 slave communication mode. Cascade communication is suitable for self-assembling several pulse controllers into a network to achieve a large number of outputs without a host computer software or PLC. The wiring diagram for cascade communication is described in Section 3 above: One of the addresses is set to "0"...
- Page 13 Number of poppet valves. The number of group pulses. Current operating status. The current number of output channels. Start from 0. Current room number. Start from 0. The number of output channels in the current room. Start from 0. Countdown counter in ms 20,21 Control instruction (hexadecimal).
- Page 14 LfNum Number of poppet 0~512 valves OpNum Total number of output 1~9999 channels (cascade) GpNum Number of group pulses 1~20 ChNum Number of output 1~16 channels of this module StVlv Point output 1~16 FltRst Error clearing Restore Factory parameter reset Quit Quit (without saving changes)
- Page 15 Beware：Please configure the parametersby disconnecting the enable！！！ When theenable port is on, the HS-2000 will power up andthen output according to the "factory default"! 5.2 Alarm List Alarm name Description Causes and Countermeasures Cxxxx Overcurrent exists in the Check output wiring for short...
-
Page 16: Parameter Setting
Parameter Setting 6.1.Buttonactionfunctiondefinition: Action Longpress(>3seconds) Shortpresstherotarybutton Clockwiserotation Counterclockwise ontherotarybutton rotation Functions Enter parameter Enter input mode Ascending Descending settingmode selection selection Shiftthecursorforward parameters parameters Exit input mode cursor Minus 1 cursor positiondata positiondata 6.2.Setting method 6.2.1Modus Node Address：X X X... - Page 17 Rotate the button clockwise to adjust the larger number, and counterclockwise to adjust the smaller number； Short press the button, the cursor shifts to the single digit and flashes； Rotate the button clockwise to adjust the larger number, and counterclockwise to adjust the smaller number；...
- Page 18 Same as 6.2.2 6.2.8 Lifting pulse interval X X . X X S Same as 6.2.6 6.2.9 Cycle interval X X X X 0S Long press the button and release it to enter the parameter setting interface, displaying parameter No. 1 MdAdd； Turn the button clockwise or counterclockwise until parameter CyInv #9 is displayed；...
- Page 19 6.3Communicationprotocols Communication parameters are baud rate 9600bps; 8 data bits, no parity. 485 read register command: Function code 0x03 Address（1B） Function code（1B） Register Address（2B） Number of read regi s ters（2B） CRC High Byte（1B) CRC low byte(1B) 485 Read Register Response：Function code0x03 Address（1B）...
-
Page 20: Structural And Electrical Specifications
12.5 mm in diameter. 7.2 Structure Diagram 7.3 General specifications and characteristics No. of Output Output Order number Product Name Voltage Current channels voltage current 6HSA-2000-220/24-16 110-240V AC 24V DC 0.75 HS-2000 multi- channel pulse 6HSA-2000-220/24-12 110-240V AC 24V DC 0.75... - Page 21 20-28V 6HSA-2000-24/24-12 20-28V DC 0.75 7.4 Port Definition： Note: 12-channel module without X5 interface 7.5 Usage Environment： Operating temperature: -20 ℃ to 55 ℃, 95% humidity, below 1000 meters above sea level HS-2000 multi-channel pulse controller Operating instructions, version 01/2021...
