aurum AEC-931BSD Instructions Manual

High power led motion light with video camera

Hide thumbs

Table Of Contents

HIGH POWER LED MOTION LIGHT WITH VIDEO CAMERA

Table of contents

1. Contents of package

2. Smartguard™ Motion Light with Video Camera

3. Installation

4. Technical Specifications

Contents of packaging

⚫

Smartguard™ Motion Light with Video Camera

⚫

User Manual

⚫

Accessory bag

⚫

1 Allen key

○ 1

Smartguard

○ 3

○ 4

Screws

x 2

INSTRUCTION

○ 5

Plastic Masonry plugs

x 2

AEC-931BSD

○ 2

User Manual

○ 6

L bar

(Optional)

○ 7

Clamp

Micro SD Card

(Optional)

Table of Contents

Need help?

Do you have a question about the AEC-931BSD and is the answer not in the manual?

Questions and answers

Summary of Contents for aurum AEC-931BSD

Page 1 AEC-931BSD HIGH POWER LED MOTION LIGHT WITH VIDEO CAMERA INSTRUCTION Table of contents 1. Contents of package 2. Smartguard™ Motion Light with Video Camera 3. Installation 4. Technical Specifications Contents of packaging ⚫ Smartguard™ Motion Light with Video Camera ⚫...
Page 2 Smartguard™ Motion Light with Video Camera overview High power LED PIR lens Camera lens Step 1. Insert/remove Micro SD Card : ◼ Unscrew the waterproofed cover using provided Allen key , then insert the Micro SD card until it automatically locks into place. ◼...
Page 3 Step2. Installing the Smartguard™ Motion Light with Video Camera IMPORTANT IF IN ANY DOUBT ABOUT THE INSTALLATION OF THIS PRODUCT, CONSULT A QUALIFIED ELECTRICIAN - This product must be grounded - Do not mount the unit against inflammable surfaces - The motion detector will not operate correctly if it is installed: ...
Page 4 Please allow 1 minute warm-up time after switching on. * Push the RESET button after switching on. Remove plastic lens cover from camera after installation Step 3. Adjusting the Settings ◼ Time control：Turn the time control knob to”+” side toincrease the illumination time (7 minutes max.), turn the control knob to “－“...
Page 5 ◼ LED indicator：for indicating the function status of the unit by different color LED lights. 1) Red： Micro SD Card is not inserted into the Micro SD slot or the system is malfunctioning. 2) Green： The unit is recording 3) LED off: stand by（Micro SD Card is inserted into the slot）, when off/record button is pressed ：...
Page 6 ⚫ Reset button：Please press Reset button in case of system malfunction Technical Specifications 1. Features and specification： ◼ PIR detection angle 160 Deg and detection range up to 10M ◼ Records 20 seconds image recording for image stream：15fps at 1920*1080 Pixels ◼...
