D M 0 9 1 2 S
DM0912S
Touchless Toilet Waste Unit
DM0912S
GENERAL DESCRIPTION
+
19-21 cm roll towel
+
Toilet waste unit is made with 304 stainless steel 0.80 mm.
+
Operates with 4 batteries (D).
+
Electricity with 220V socket.
+
Stainless steel key.
+
Adjustable sheet lenght.
+
Easy to assemble.
+
Security lock system.
+
Counter wall option.
+
23 lt bin capacity with lock.
COMPONENTS AND MATERIAL
+
DM0912S- Stainless Steel 304 satine finish
INSTALLATION
+
First measure out where the touchless dispenser
will be placed, mark six holes and drill into the wall.
+
Insert the provided wall plugs and screw in the top
two screws, leaving a slight gap
for the dispenser to slot onto.
+
Slot the dispenser onto the
two previously fixed screws
and then screw final screws.
+
Once the dispenser
is secure, insert the paper
back into the dispenser
by using the adjustable
handles inside.
T E C H N I C A L D A T A S H E E T
1 / 2
25 mm
25 mm
320 mm
370 mm
Advertisement
Table of Contents
Summary of Contents for DAYCO DM0912S
- Page 1 Security lock system. Counter wall option. 23 lt bin capacity with lock. COMPONENTS AND MATERIAL DM0912S- Stainless Steel 304 satine finish INSTALLATION First measure out where the touchless dispenser will be placed, mark six holes and drill into the wall.
- Page 2 GROSS PALLET CODE DIMEN. DIMEN. WEIGHT QUANTITY QUANTITY DIMEN. WEIGHT DM0912S 30 L 130x31x16 cm 137x44x30 cm 16,7 kg 80x120x160 cm 150 kg T E C H N I C A L D A T A S H E E T...
