- Page 1 SPC-100 USER MANUAL Rev.01...
-
Page 2: Product Overview
IAQ (Indoor Air Quality) monitoring and control device for home and industrial Home and industrial air conditioner 1-3. Specifications Model SPC-100 Operating Voltage 12Vdc ±10% (DC Adapter plug: inner diameter 2.1, outer diameter 5.5PIE) Current consumption Max. 350mA @ 12Vdc... -
Page 3: Equipment Settings
Product Function and How To Use Operating configuration KEY Name Description UP KEY Move up and increase value DOWN KEY Move down and decrease value MENU KEY Enter configuration mode ENTER KEY Enter Configuration Mode Sensor Display Settings ➊ Configuration Mode Particle size range setting displayed on the initial screen ➊... - Page 4 Product Function and How To Use Sensor Display Settings Configuration Mode Sensor Display Settings Sensor Display Settings Left Upper 0.3 um Equipment Settings Right Upper 0.5 um Sensor Alarm Settings Left Lower 1.0 um Wi-Fi Settings Right Lower 2.5 um Click the ENTER button to enter Particle size range setting Sensor Dispalys Settings.
- Page 5 Product Function and How To Use Sensor Alarm Settings Configuration Mode Sensor Alarm Settings Sensor Display Settings 0.3 um Upper Limit Equipment Settings 0.3 um Lower Limit Sensor Alarm Settings 0.5 um Upper Limit Wi-Fi Settings 0.5 um Lower Limi Set an alarm for each Particle Size Range.
- Page 6 Product Connector Specifications Connector Specifications Communication Connector Power Connector RJ-45 8p8c (Dual) 2.0PIE DC JACK (12V) Communication Connector Pin Map Specification Pin Assigned RS485- RS485+...
-
Page 7: Product Appearance
Product Appearance Product Dimensions <UP> Communication Connector D/L Connector Power Connector Wi-Fi Antenna Dust Outlet Vent Hole Dust Inlet < Left Side > <Front> <Right Side> Status LED <DOWN> <Rear>... - Page 8 Products handling precaution There is a risk of electric shock to this product, so do not open the product while power is applied. Be sure to install this product on a fixed location such as a rack or panel. ...
- Page 9 FCC Instructions FCC Compliance Statement This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. FCC Interference Statement This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules.
- Page 10 We do not guarantee the performance of this device in case of disassembling, operating without complying with instructions in this document. Contact your IGS representative to obtain the latest forecast, schedule and specifications. Or It may be obtained by calling +82-2-6299-7536~7 or by visiting http://www.igstech.kr...
