Summary of Contents for Sailmon MAX MINI
- Page 1 QUICK START GUIDE BODY Version 1.0 - December 2022 PIRED PIRED UNTOLD UNTOLD SHARE YOUR STORY. SAIL WITH US MAX MINI QUICK START GUIDE...
- Page 2 WELCOME TO THE #SAILMONSTER COMMUNITY! CONGRATS ON YOUR MAX MINI! ARE YOU READY TO MAXIMIZE YOUR SAILING EXPERIENCE? COMPLETE THE STEPS IN THIS QUICK START GUIDE, GET ON THE WATER AND START SHARING STORIES! #SHAREYOURSTORY SAILMON MAX MINI QUICK START GUIDE...
-
Page 3: Table Of Contents
1. WHAT’S IN THE BOX? 2. UNDERSTAND YOUR DEVICE Buttons Symbols 3. FIRST STEPS OF INSTALLATION 1. Connect 2. Update 3. LIVE 4. Calibrate 5. Mount 6. Sail 4. SAILMON APP 5. CHARGING 6. SUPPORT MAX MINI QUICK START GUIDE... -
Page 4: What's In The Box
1. WHAT’S IN THE BOX? SAILMON MAX MINI INDUCTIVE CHARGER AND CABLE SOFT CARRYING BAG Go to our shop (shop.sailmon.com) to find adapters for all continents and the MAX mini bracket to mount your unit to your boat. MAX MINI QUICK START GUIDE... -
Page 5: Understand Your Device
BUTTONS Hold the MAX mini in your hands with the symbols on top. There are two buttons on the bottom of the device. RIGHT BOTTOM BUTTON On: Press and wait until all lights are on. -
Page 6: Symbols
SYMBOLS Hold the MAX mini in your hands with the symbols on top. There are four different symbols (plus the side symbol in the left bottom corner) which can be 2 or 3 colours with different meanings. SIGNAL 1 SIGNAL 2... -
Page 7: First Steps Of Installation
2. FIRST STEPS OF INSTALLATION We understand you want to hit the water with MAX mini as soon as possible, but it’s essential to follow the next instructions to get your device ready. CONNECT Step 1: LIVE Step 2: UPDATE... -
Page 8: Sailmon App
2. Your MAX mini is connected to your personal Sailmon App account and the internet via the SIM card is active. 3. You go sailing with your MAX mini turned on. The data will be sent live to the Sailmon App, ready to be viewed as the action takes place on the water. - Page 9 STEP 1A: DOWNLOAD THE SAILMON APP Let’s make the connection happen! First things first. Download the Sailmon App in App Store or Google Play. STEP 1B: CREATE AN ACCOUNT Set up your personal account by following the on-screen instructions. Do you already have an account? Then simply log in.
- Page 10 STEP 1C: TURN ON MAX MINI Press the right button. The on/off symbol will turn green. MAX mini needs some time to get all connections ready. Wait until all symbols shows a colour. GENERAL Symbols MAX MINI QUICK START GUIDE...
- Page 11 3. Tap on Connect a Device 4. Tap on MAX mini under Register a new device 5. Take your phone and scan the QR-code on the back of your MAX mini. After a successful scan, your MAX mini will be shown.
- Page 12 LIVE MAX mini includes LTE-M internet connectivity due to the integrated SIM card*. Therefore, your trip can be viewed live on the Sailmon App. The first three months are free. After that, a one-year subscription is needed to use the live functionality.
- Page 13 MAX mini improves over time through automatic over-the-air software updates. Check on a regular basis if an update is available. It is important that your MAX mini is connected to the internet via the integrated SIM card or Bluetooth. 1. Press the left button 2.
- Page 14 STEP 4: CALIBRATE It’s important to calibrate the MAX mini every time you hit the water. This will ensure accurate data. Calibration needs to be done right before you mount your unit to your boat. MAX MINI QUICK START GUIDE...
- Page 15 MOUNT MAX MINI TO YOUR BOAT To get accurate compass data, you’ll need to mount MAX mini to a fixed place on your boat with a special mount (order it via our webshop). It’s not required to mount MAX mini. However, the compass won’t work if you wear the unit, for example, in your pocket.
- Page 16 STEP 6 SAILING MAX MINI QUICK START GUIDE...
- Page 17 5. SAILMON APP MAX mini is all about the connectivity to the Sailmon App. We kindly ask you to download our Sailmon App manual (https://sailmon.com/ maxminimanual) to get the most out of your unit. Below you’ll find a short explanation of the data.
-
Page 18: Charging
HOW TO CHARGE YOUR MAX MINI 1. Connect the cable with the charging pad and an adapter 2. Place MAX mini with the Sailmon logo on top on the charging pad 3. Your unit will turn off while charging. The charging pad will turn blue 4. -
Page 19: Support
7. SUPPORT Do you have questions after reading the Quick Start Guide? 1. Go to sailmon.com/max/support for more information, video tutorials and troubleshooting. 2. No answers to your questions? Submit a ticket. Our customer service agents are happy to assist you - from Monday to Friday, 09:00 - 17:00 (CET). - Page 20 ENJOY YOUR MAX MINI AND #SHAREYOURSTORY USE #SAILWITHUS AND TAG @SAILMON INSTRUMENTS TO GET FEATURED ON OUR SOCIALS. MAX MINI QUICK START GUIDE...
- Page 21 Simplified EU Declaration of Conformity: We, Sailmon, declare under our sole responsibility that the product MAX, to which this declaration relates, is in conformity with 2014/90/EU. We further declare that the product meets the essential requirement of the above Directives.
- Page 22 HELLINGWEG 9-B 2583 DZ DEN HAAG THE NETHERLANDS INFO@SAILMON.COM +31 (0)70 20 075 33 WWW.SAILMON.COM INSP INSP BY U BY U MAX MINI QUICK START GUIDE...
