- Page 1 LCD Monitor VTA700 / VTA900...
-
Page 2: For Your Records
United States and/or other countries. Corporate names and trademarks are the property of their respective companies. Disclaimer: ViewSonic Corporation shall not be liable for technical or editorial errors or omissions contained herein; nor for incidental or consequential damages resulting from furnishing this material, or the performance or use of this product. -
Page 3: Table Of Contents
Contents Introduction... 2 Features ...2 For Your Safety ...2 Installation ... 4 Unpacking the Display...4 Locations and Functions of Controls ...4 Making the Connections ...5 Using Your Display ... 7 Turning the Display On and Off ...7 Tilting the Display...8 Setting the Video Mode...8 Setting the Refresh Rate...8 Minimizing Power Consumption ...9... -
Page 4: Introduction
Introduction This latest LCD monitor has a n active matrix TFT (thin film transistor) liquid crystal display module. It is designed for use with any Windows compact-sized design provides great space savings on your computer desk. Features Important features include: Automatic configuration to the PC video settings with maximum SXGA resolution. - Page 5 The display does not operate correctly when the operating instructions are followed. The display has been dropped or the cabinet has been damaged. *Only for use with supplied adapter, in case of loss or damage contact for a replacement. ViewSonic...
-
Page 6: Installation
Installation Please follow the instructions in this chapter to install your LCD Monitor. Note: Before connecting your display, first read through the instructions in this chapter and the safety precautions in the previous chapter. Unpacking the Display When you are unpacking the display, make sure that you have the following items:... -
Page 7: Making The Connections
The functions of the three control buttons which are located at the lower left side of the front panel of your display. Their functions are described as below: Button Select Up ( ) Down ( ) Making the Connections Before connecting any cables, make sure that the computer and display are turn off. To connect the power and video signal cables: 1. - Page 8 4. Plug the analog video signal cable into the Analog Video Input port on the back of the display (as shown above). 5. Connect the other end of the video cable into your computer’s video port. (Please check your computer’s documentation if you’re not sure where the port is located.) Note: For best display performance, it is strongly recommended that you use Auto Setup to automatically configure your display’s settings.
-
Page 9: Using Your Display
Using Your Display This chapter contains information about using your LCD Monitor. Turning the Display On and Off Use the power button located at the lower right side of the front panel of the display to turn the display on and off. When the display is on, the light (LED) near the Power button is illuminated. The light is green when both the display and PC are active and amber when the display is in a reduced power mode. -
Page 10: Tilting The Display
On standard CRT displays, we recommend that you should use the highest possible refresh rate supported by your PC at the current screen resolution. This is necessary to avoid screen flickering and to minimize eyestrain. However, with your LCD Monitor, flicker is not an issue. It is flick-free at all supported refresh rates. -
Page 11: Minimizing Power Consumption
The table in “Video Mode” on page 29 shows the image refresh rates supported by the display at different screen resolution. Although your LCD monitor supports up to 75 Hz for analog video input, we recommend that you use 60 Hz refresh rate for best performance. - Page 12 Note: If the screen is still dirty, you can dampen the cloth with several drops of distilled water. Make sure the LCD panel is completely dry before you turn the display back on. 4. Plug in the display. 5. Turn on your PC and display.
-
Page 13: Adjusting Your Display
Adjusting Your Display This chapter contains information about how to changing display settings for your LCD Monitor. It is designed with an OSD menu to help you easily adjust to its optimum performance. Note: You must perform auto setup before making any adjustment. -
Page 14: Selecting Items In The Osd Menu
Item Auto Adjusting the “Auto Setup”. See “Adjusting Auto Setup” on page 14. Open the “Management” submenu where you can select Brightness, Contrast or the image position for further adjustment. See Adjustment in the Management “Management” Submenu” on page 15. Open the “Clock/Phase”... - Page 15 2. The ‘Auto’ icon should be highlighted already. 3. Use ‘Select’ button to select and execute the Auto Setup function. After the execution of the Auto Setup function, it will show-up the follow message: If the image looks correct, choose Yes. If the image requires further adjustment, choose No, it will shown up ‘Phase’...
- Page 16 3. Use ‘Select’ key to enter the “Management” Submenu. It will show up four items for your further adjustment. If ‘Brightness’ is selected, you may use ‘Up ( )’ or ‘Down ( )’ buttons to adjust the setting of brightness. The fullness of the graphic bar as well as the numerical value at the right corner is also changed accordingly.
- Page 17 If ‘H. position’ is selected, you may use ‘Up ( )’ or ‘Down ( )’ buttons to adjust the setting of the horizontal position of the image. The fullness of the graphic bar as well as the numerical value at the right corner is also changed accordingly. If ‘V.
- Page 18 Adjusting the “Clock/Phase” Submenu To adjust the “Clock/Phase” submenu you should follow the steps below: 1. Bring-up the OSD “Main Menu”. 2. Use ‘Up ( )’ (or ‘Down ( )’) to move forward (or backward) to the clock/phase icon and highlight it.
- Page 19 If ‘Exit’ is selected, it will exit the “Clock/Phase” submenu and go back to the “Main Menu”. Adjusting the “Color” Submenu To do adjustment in the “Color” submenu you should follow the steps below: 1. Bring-up the OSD “Main Menu”. 2.
- Page 20 Note: As you choose an item, your screen immediately updates to reflect this setting. If ‘Black Level Adjust’ is selected, it will bring-up “Back Level Adjust” submenu. You can adjust its setting by ‘Up ( )’ and ‘Down ( )’ buttons. If ‘RGB Adjust’...
- Page 21 Adjusting the “OSD Display” submenu To adjust the OSD H and V, positions you should follow the steps below: 1. Bring-up the OSD “Main Menu”. 2. Use ‘Up ( )’ (or ‘Down ( )’) to move forward (or backward) to the OSD display icon and highlight it.
- Page 22 If ‘Exit’ is selected, it will exit the “OSD Display” submenu and go back to the “Main Menu”. Adjusting the Factory Recall To recall factory settings back you should follow the steps below: 1. Bring-up the OSD “Main Menu”. 2. Use ‘Up ( )’ (or ‘Down ( )’) to move forward (or backward) to the factory recall icon and highlight it.
- Page 23 Selecting Language for Your Preference To select one of the five languages for your preference you should follow the steps below: 1. Bring-up the OSD “Main Menu”. 2. Use ‘Up ( )’ (or ‘Down ( )’) to move forward (or backward) to the languages icon and highlight it.
-
Page 24: Using The Direct Keys
Using the Direct Keys There are two direct keys that function while OSD “Main Menu” is inactivated. One of the two direct keys is for Auto Setup and the other is for bringing-up OSD Brightness menu. Auto Setup by Direct Key Use Auto Setup whenever you apply a new video mode or change the refresh rate. - Page 25 If the image requires further adjustment, choose No, it will shown up ‘Phase’ bar for your further adjustment by manual. Then you can adjust the phase by ‘Up ( )’ or ‘Down ( )’ buttons. When all text appears well focused and there is no instability in the image, press the ‘Select’ key to end the adjustment and close the OSD menu.
-
Page 26: Troubleshooting
Troubleshooting This chapter contains information about how to troubleshoot your LCD Monitor. If you have tried all of the items listed below, please contact a qualified service personnel. A. My display doesn’t work, even though the computer appears to work. -
Page 27: Customer Support
PC’s setting to a correct one. Customer Support Before contacting ViewSonic Customer Support, check the Troubleshooting section for possible solutions to any setup problems. For Customer Support or product service, you will need to provide the product serial number... -
Page 28: Technical Information
5º ~ 40ºC at altitude 0 ~ 2000m 5º ~ 30ºC at altitude 2000 ~ 3000m 20% ~ 85% RH, non-condensing 3000m Max. -20º ~ 60ºC 5% ~ 95% RH 10,000m Max. 1280 x 1024 @ 75 Hz VTA900 Full Range, , 75ohm... -
Page 29: Video Modes
The display is capable of going beyond these recommended modes. Unknown Video Modes Like all other monitors, the your LCD monitor is designed to work with standard video modes. However, not all video/graphic cards use only standard display modes. Your LCD monitor uses state-of-the-art technology, which is designed to synchronize to any display mode. -
Page 30: Regulatory Information
Regulatory Information Agency Approvals UL1950 FCC Class B MPRII Energy Star FCC Statement: FCC Notice – Part 15 This device complies with Part 15 of FCC rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference. (2) This device must accept any interference received. -
Page 31: Limited Warranty
If a product proves to be defective in material or workmanship during the warranty period, ViewSonic will, at its sole option, repair or replace the product with a like product. Replacement product or parts may include remanufactured or refurbished parts or components.
