Specifications Overview; Key Features; Input And Compatibility; Power And Controls - ViewSonic VP2030b Specifications

VP2030b
20.1" THINEDGE
ViewSonic Corporation's QMS & EMS have been registered to
ISO 9001 & ISO 14001, respectively, by the British Standards Institution.
ViewSonic Corporation • 381 Brea Canyon Road, Walnut, CA 91789
Customer Service and Technical Support: (800) 688-6688 • Sales: (888) 881-8781 • SalesInfo@ViewSonic.com • ViewSonic.com
**Adapter may be required. Analog adapter available from ViewSonic. Specifications subject to change without notice. Selection, offers and programs may vary by country; see your ViewSonic representative for complete
details. Windows Vista and the Windows logo are trademarks or registered trademarks of Microsoft Corporation in the United States and/or other countries. Corporate names, trademarks stated herein are the property of
their respective companies. Copyright © 2007 ViewSonic Corporation. All rights reserved. [13354-00B-01/07] VP2030b-1
For more product information, visit us on the web at ViewSonic.com
LCD WITH 8MS CLEARMOTIV
™
LCD
VIDEO INPUT
COMPATIBILITY
CONNECTOR
POWER
CONTROLS
OPERATING
CONDITIONS
DIMENSIONS
(W x H x D)
WEIGHT
REGULATIONS
RECYCLE/DISPOSAL
POWER MANAGEMENT
PACKAGE CONTENTS
WARRANTY
HD BROADCAST-QUALITY VIDEO
®
Type 20.1" color TFT active matrix UXGA LCD
Display Area 16.1" horizontal x 12.1" vertical; 20.1" diagonal
Optimum Resolution 1600x1200
Contrast Ratio 1000:1 (typ)
Viewing Angles 170° horizontal, 170° vertical @ contrast ratio > 10:1
Response Time 8ms gray-to-gray (avg); 16ms black-white-black (typ)
Light Source Long life, 50,000 hrs. (typ)
Brightness 300 cd/m2 (typ)
Panel Surface Anti-glare
Analog/Digital RGB analog (75 ohms, 0.7/1.0 Vp-p)/DVI (TMDS, 100 ohms)
Frequency F h : 24~92kHz, F v : 50~85Hz
Sync H/V separated (TTL), composite sync on green
PC VGA up to 1600x1200 non-interlaced
Mac ® ** Power Mac™ G3/G4/G5 up to 1600x1200; PerfectSuite
pivot function not support by ViewSonic
Analog/Digital 15-pin mini D-sub/DVI-I (digital and analog capable)
USB V2.0, 1-up/4-down
Power Internal power; 3-pin AC plug
Voltage AC 100–240V, 50/60Hz (auto switch)
Consumption 52W (typ)
Basic Power, 2, up, down, 1
OnView ® Auto image adjust, contrast, brightness, input select (analog,
digital), ViewMatch
5400K, 5000K, user color - RGB), information (resolution, H.
frequency, V. frequency, pixel clock, model number, serial
number), manual image adjust (PIP, PIP position, PIP swap, H.
size, H. position, V. position, fine tune, sharpness, scaling), setup
menu (language, resolution notice, OSD position, input priority,
OSD timeout, OSD background, OSD pivot), memory recall
Temperature 32–104°F (0–40°C)
Humidity 10–90% (non-condensing)
Physical (mm) 468mm x 403mm x 315mm
Physical (in.) 18.4" x 15.9" x 12.4"
Net 19.8 lb. (9.0 kg)
Gross 26.4 lb. (12.0 kg)
UL, cUL, FCC-B (ICES), CB, CE, TCO '99, ICES-003B,
ISO13406-2, TUV/GS, TUV ERGO (covers ISO13406-2 & MPR II),
TUV-S, NOM, GOST-R, HYGIENIC, CCC, BSMI, PSB, C-TICK,
KTL/MIC, SASO, WEEE, RoHS
The lamp in this product contains mercury. Please dispose of
in accordance with local, state and federal laws.
Meets TCO'99 and standards
LCD display, power cable, 15-pin VGA video cable, DVI cable,
USB cable, Quick Start Guide, ViewSonic Wizard CD,
PerfectSuite
™
Three-year limited warranty on parts, labor and backlight.
® color adjust (sRGB, 9300K, 7500K, 6500K,
CD
™ and
